16MP 360° Panoramic & PTZ Camera

  • 360° splicing image: the image presented includes all scenes covered by the camera
  • Target filtering: based on deep learning algorithms, targets can be classified into human, vehicle and others to reduce false alarms
  • A built-in heater provides ultra-low temperature start-up to -40℃
  • Built-in IR light: IR range of 200 meters provides good visibility in low or even zero-light environments
View Less
View more
Thông số sản phẩm
Sales Inquiry

Available models:

DS-2DP1636-D(4mm)
DS-2DP1636
EOL
Thông số sản phẩm

Specification

  • Decoding
  • Audio compressionG.711ulaw/G.711alaw/G.722/G.726/MP2L2/PCM
  • Network
  • ProtocolsIPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTP,TCP,UDP,IGMP,ICMP,
  • Interface
  • On-board storageBuilt-in Micro SD/SDHC /SDXC card slot, up to 128GB, manual/alarm recording
  • Audio I/O1/1
  • Alarm I/O7 alarm inputs (0-5v DC), 2 alarm output, Support alarm linkage
  • RS-485Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive
  • Fiber Cable1 10M/100M/1000M FC interface, TX1310 / RX1550nm wavelength, 20 km transmission distance
  • Panoramic Camera
  • Image Sensor1/1.9’’ Progressive Scan CMOS
  • Min. IlluminationColor: 0.004Lux @ (F1.8, AGC ON), B/W: 0.0004Lux @ (F1.8, AGC ON)
  • Lensf4.0mm/ F1.8
  • Field of ViewHorizontal angle of view: 360°, Vertical angle of view: 180°
  • Video CompressionH.264(Baseline, Main, High Profile)/MJPEG
  • Main Stream Resolution50Hz: 25fps 2×(2400×3840, 1792×2880, 1600×2560, 1200×1920) 60Hz: 25fps 2×(2400×3840, 1792×2880, 1600×2560, 1200×1920)
  • Sub-Stream Resolution50Hz: 25fps 2×(320×512, 480×720) 60Hz: 25fps 2×(320×512, 480×720)
  • Third Stream Resolution50Hz: 25fps 2×(2400×3840, 1200×1920) 60Hz: 25fps 2×(2400×3840, 1200×1920)
  • General
  • Power SupplyDC 36V, MAX. 110W (Heater: 44W)
  • DimensionsΦ274.9 × 250.3
  • Weight4.5kg
  • Protection LevelIP66 standard, TVS 6,000V lightning protection, surge protection and voltage transient protection
  • Working Temperature-40 °C – 65 °C
  • Working HumidityHumidity 90% or less
  • MountingWall mount: DS-1603ZJ; Long-arm Pendant mount: DS-1668ZJ (20); Pendant Mount: DS-1668ZJ
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specification

Decoding
Audio compression
G.711ulaw/G.711alaw/G.722/G.726/MP2L2/PCM
Network
Protocols
IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTP,TCP,UDP,IGMP,ICMP,
Interface
On-board storage
Built-in Micro SD/SDHC /SDXC card slot, up to 128GB, manual/alarm recording
Audio I/O
1/1
Alarm I/O
7 alarm inputs (0-5v DC), 2 alarm output, Support alarm linkage
RS-485
Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive
Fiber Cable
1 10M/100M/1000M FC interface, TX1310 / RX1550nm wavelength, 20 km transmission distance
Panoramic Camera
Image Sensor
1/1.9’’ Progressive Scan CMOS
Min. Illumination
Color: 0.004Lux @ (F1.8, AGC ON), B/W: 0.0004Lux @ (F1.8, AGC ON)
Lens
f4.0mm/ F1.8
Field of View
Horizontal angle of view: 360°, Vertical angle of view: 180°
Video Compression
H.264(Baseline, Main, High Profile)/MJPEG
Main Stream Resolution
50Hz: 25fps 2×(2400×3840, 1792×2880, 1600×2560, 1200×1920) 60Hz: 25fps 2×(2400×3840, 1792×2880, 1600×2560, 1200×1920)
Sub-Stream Resolution
50Hz: 25fps 2×(320×512, 480×720) 60Hz: 25fps 2×(320×512, 480×720)
Third Stream Resolution
50Hz: 25fps 2×(2400×3840, 1200×1920) 60Hz: 25fps 2×(2400×3840, 1200×1920)
General
Power Supply
DC 36V, MAX. 110W (Heater: 44W)
Dimensions
Φ274.9 × 250.3
Weight
4.5kg
Protection Level
IP66 standard, TVS 6,000V lightning protection, surge protection and voltage transient protection
Working Temperature
-40 °C – 65 °C
Working Humidity
Humidity 90% or less
Mounting
Wall mount: DS-1603ZJ; Long-arm Pendant mount: DS-1668ZJ (20); Pendant Mount: DS-1668ZJ
For better user experience, we highly recommend you to update your device to the latest firmware asap.
Specification
Decoding
  • Audio compressionG.711ulaw/G.711alaw/G.722/G.726/MP2L2/PCM
Network
  • ProtocolsIPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTP,TCP,UDP,IGMP,ICMP,
Interface
  • On-board storageBuilt-in Micro SD/SDHC /SDXC card slot, up to 128GB, manual/alarm recording
  • Audio I/O1/1
  • Alarm I/O7 alarm inputs (0-5v DC), 2 alarm output, Support alarm linkage
  • RS-485Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive
  • Fiber Cable1 10M/100M/1000M FC interface, TX1310 / RX1550nm wavelength, 20 km transmission distance
Panoramic Camera
  • Image Sensor1/1.9’’ Progressive Scan CMOS
  • Min. IlluminationColor: 0.004Lux @ (F1.8, AGC ON), B/W: 0.0004Lux @ (F1.8, AGC ON)
  • Lensf4.0mm/ F1.8
  • Field of ViewHorizontal angle of view: 360°, Vertical angle of view: 180°
  • Video CompressionH.264(Baseline, Main, High Profile)/MJPEG
  • Main Stream Resolution50Hz: 25fps 2×(2400×3840, 1792×2880, 1600×2560, 1200×1920) 60Hz: 25fps 2×(2400×3840, 1792×2880, 1600×2560, 1200×1920)
  • Sub-Stream Resolution50Hz: 25fps 2×(320×512, 480×720) 60Hz: 25fps 2×(320×512, 480×720)
  • Third Stream Resolution50Hz: 25fps 2×(2400×3840, 1200×1920) 60Hz: 25fps 2×(2400×3840, 1200×1920)
General
  • Power SupplyDC 36V, MAX. 110W (Heater: 44W)
  • DimensionsΦ274.9 × 250.3
  • Weight4.5kg
  • Protection LevelIP66 standard, TVS 6,000V lightning protection, surge protection and voltage transient protection
  • Working Temperature-40 °C – 65 °C
  • Working HumidityHumidity 90% or less
  • MountingWall mount: DS-1603ZJ; Long-arm Pendant mount: DS-1668ZJ (20); Pendant Mount: DS-1668ZJ
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.
