8-ch 1080p Lite 1U H.265 eSSD DVR

Powered by M-SATA eSSD technology
Deep learning based human and vehicle targets classification of Motion Detection 2.0
Scene-adaptive bitrate control video compression
Low power consumption
Up to 1080p Lite@15 fps encoding capability
Audio via coaxial cable

View Less

Data Sheet

Available models:

DS-E08HGHI-XD

Especificación
Resources
Accesorios

Data Sheet

Detección de movimiento 2.0
Human/Vehicle AnalysisDeep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported;

Video and Audio
Entrada de vídeo IP2-ch Up to 5 MP resolution Support H.265+/H.265 IP cameras
Entrada de video analógico8-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI Input1080p25, 1080p30, 720p25, 720p30
AHD Input1080p25, 1080p30, 720p25, 720p30
HDCVI Input1080p25, 1080p30, 720p25, 720p30
CVBS InputSupport
HDMI Output1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
VGA Output1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video Output ModeHDMI/VGA simultaneous output
Entrada de Audio8-ch via coaxial cable
Salida de audio1-ch via HDMI
Reproducción síncrona8-ch

Recording
Compresión de vídeoH.265 Pro/H.265
Resolución de codificación1080p Lite/720p/720p Lite/WD1/4CIF/CIF/QVGA
Frame RateMain stream: 1080p Lite/720p/720p Lite/WD1/4CIF@15 fps Note: 1080p Lite/720p is 15 fps by default Sub-stream: CIF/QVGA@15 fps
Vídeo bitrateAccording to the actual scene, scene-adaptive bitrate control technology would automatically allocates appropriate bitrate to ensure the stability of recording period.
Stream TypeVideo, Video & Audio Note: In order to protect privacy, the device will only record video (without audio) by default. If you want to record audio, you shall manually enable audio recording. For operation details, refer to the user manual.
Compresión de audioG.711u
Audio Bitrate64 Kbps

Red
Total Bandwidth72 Mbps Incoming bandwidth: 8 Mbps
Conexión remota32
Protocolo de redTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS
Interfaz de red1, RJ45 10/100 Mbps self-adaptive Ethernet interface

Auxiliary Interface
CapacidadBuilt-in 1024 GB eSSD (960 GB available) Note: M-SATA interface, capable of plugging and upgrading capacity. The device can store about 4 weeks videos for 8-ch analog cameras (default parameters), this estimation is for reference only.
Interfaz USBRear panel: 2 × USB 2.0
Alarma E/SN/A

General
Fuente de alimentación12 VDC, 1 A
Consumo≤ 6.2 W (with eSSD)
Temperatura de trabajo-10 °C to 45 °C (14 °F to 113 °F)
Condiciones de Humedad10% to 90%
Dimensión (W × D × H)152 × 113 × 46 mm(6.0 × 4.4 × 1.8 inch)
≤ 0.5 kg (with eSSD, 1.1 lb.)

Detección de movimiento 2.0

Human/Vehicle Analysis

Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported;

Video and Audio

Entrada de vídeo IP

2-ch Up to 5 MP resolution Support H.265+/H.265 IP cameras

Entrada de video analógico

8-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

HDTVI Input

1080p25, 1080p30, 720p25, 720p30

AHD Input

1080p25, 1080p30, 720p25, 720p30

HDCVI Input

1080p25, 1080p30, 720p25, 720p30

CVBS Input

Support

HDMI Output

1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz

VGA Output

1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz

Video Output Mode

HDMI/VGA simultaneous output

Entrada de Audio

8-ch via coaxial cable

Salida de audio

1-ch via HDMI

Reproducción síncrona

8-ch

Recording

Compresión de vídeo

H.265 Pro/H.265

Resolución de codificación

1080p Lite/720p/720p Lite/WD1/4CIF/CIF/QVGA

Frame Rate

Main stream: 1080p Lite/720p/720p Lite/WD1/4CIF@15 fps Note: 1080p Lite/720p is 15 fps by default Sub-stream: CIF/QVGA@15 fps

Vídeo bitrate

According to the actual scene, scene-adaptive bitrate control technology would automatically allocates appropriate bitrate to ensure the stability of recording period.

Stream Type

Video, Video & Audio Note: In order to protect privacy, the device will only record video (without audio) by default. If you want to record audio, you shall manually enable audio recording. For operation details, refer to the user manual.

Compresión de audio

G.711u

Audio Bitrate

64 Kbps

Red

Total Bandwidth

72 Mbps Incoming bandwidth: 8 Mbps

Conexión remota

Protocolo de red

TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS

Interfaz de red

1, RJ45 10/100 Mbps self-adaptive Ethernet interface

Auxiliary Interface

Capacidad

Built-in 1024 GB eSSD (960 GB available) Note: M-SATA interface, capable of plugging and upgrading capacity. The device can store about 4 weeks videos for 8-ch analog cameras (default parameters), this estimation is for reference only.

Interfaz USB

Rear panel: 2 × USB 2.0

Alarma E/S

N/A

General

Fuente de alimentación

12 VDC, 1 A

Consumo

≤ 6.2 W (with eSSD)

Temperatura de trabajo

-10 °C to 45 °C (14 °F to 113 °F)

Condiciones de Humedad

10% to 90%

Dimensión (W × D × H)

152 × 113 × 46 mm(6.0 × 4.4 × 1.8 inch)

≤ 0.5 kg (with eSSD, 1.1 lb.)

Detección de movimiento 2.0

Human/Vehicle AnalysisDeep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported;

Video and Audio

Entrada de vídeo IP2-ch Up to 5 MP resolution Support H.265+/H.265 IP cameras
Entrada de video analógico8-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI Input1080p25, 1080p30, 720p25, 720p30
AHD Input1080p25, 1080p30, 720p25, 720p30
HDCVI Input1080p25, 1080p30, 720p25, 720p30
CVBS InputSupport
HDMI Output1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
VGA Output1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video Output ModeHDMI/VGA simultaneous output
Entrada de Audio8-ch via coaxial cable
Salida de audio1-ch via HDMI
Reproducción síncrona8-ch

Recording

Compresión de vídeoH.265 Pro/H.265
Resolución de codificación1080p Lite/720p/720p Lite/WD1/4CIF/CIF/QVGA
Frame RateMain stream: 1080p Lite/720p/720p Lite/WD1/4CIF@15 fps Note: 1080p Lite/720p is 15 fps by default Sub-stream: CIF/QVGA@15 fps
Vídeo bitrateAccording to the actual scene, scene-adaptive bitrate control technology would automatically allocates appropriate bitrate to ensure the stability of recording period.
Stream TypeVideo, Video & Audio Note: In order to protect privacy, the device will only record video (without audio) by default. If you want to record audio, you shall manually enable audio recording. For operation details, refer to the user manual.
Compresión de audioG.711u
Audio Bitrate64 Kbps

Red

Total Bandwidth72 Mbps Incoming bandwidth: 8 Mbps
Conexión remota32
Protocolo de redTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS
Interfaz de red1, RJ45 10/100 Mbps self-adaptive Ethernet interface

Auxiliary Interface

CapacidadBuilt-in 1024 GB eSSD (960 GB available) Note: M-SATA interface, capable of plugging and upgrading capacity. The device can store about 4 weeks videos for 8-ch analog cameras (default parameters), this estimation is for reference only.
Interfaz USBRear panel: 2 × USB 2.0
Alarma E/SN/A

General
