Thermal & Optical Bi-spectrum Network Sphere Positioning System

Perimeter protection based on intelligent human/vehivle/vessel classification algorithm: line crossing, intrusion, region entrance and exit
1280 × 1024 resolution 12 μm, VOx UFPA, NETD ＜35 mK (25 °C, F# = 1.0)
Image processing technology: Liner, histogram, and self-adaptive thermal AGC mode, DDE, 3D DNR
Fire detection and smoke detection algorithm
Smart wiper, automatically turns on when it rains
High quality detector with 10 years guarantee
NEMA-4X Standard, Anti-corrosion coating

View Less

Data Sheet

Available models:

DS-2TD95C8-150ZE4FL/W

Spezifikation
Resources
Zubehör

Data Sheet

Thermalmodul
BildsensorVOx Uncooled Focal Plane Arrays
Auflösung der Kamera1280 × 1024
Pixel Pitch12 μm
Spectral Range8 μm to 14 μm
NETDLess than 35 mK (@ 25 °C,F# = 1.0)
Brennweite30 to 150 mm
Fokus-ModusSemi-auto & Manual
IFOV0.40 to 0.08 mrad
BlendeF0.85 to F1.2
Blickwinkel28.7° × 23.2° (H × V) to 5.9° × 4.7° (H × V)
Min. Fokussierentfernung3 m
Digitaler Zoom×2, ×4, ×8

Optisches Modul
Bildsensor1/1.8" Progressive Scan CMOS
Auflösung der Kamera2688 × 1520, 4 MP
Min. BeleuchtungColor: 0.005 Lux @ (F3.5, AGC ON), B/W: 0.0005 Lux @ (F3.5, AGC ON)
Blickwinkel31.2° × 17.8° (H × V) to 0.5° × 0.3° (H × V)
Brennweite10 to 800 mm, 80x
Aperture (Range)F3.0 to F11.5
Fokus-ModusSemi-auto & Manual
Digitaler Zoom×2, ×4, ×8, ×16
Verschlusszeit1 s to 1/30,000 s
WDR120 dB
Optical DefogYes

Image Effect
Picture in PictureDisplay partial image of thermal channel on the full screen of optical channel
Target ColorationSupported in white hot and black hot mode
Image StabilizationThermal channel: Built-in gyroscope to improve EIS performance(conflicted with intelligent function)； Optical channel：Optical Image Stabilization (OIS)

PTZ
BewegungsbereichPan: 360° Continuous Rotate; Tilt: From -45° to + 45° (auto flip)
Pan SpeedConfigurable, From 0.01°/s to 120°/s, Preset Speed: 120°/s
Tilt SpeedConfigurable, From 0.01°/s to 80°/s, Preset Speed: 80°/s
ProportionalzoomYes
Presets300 in total, 273 are configurable.
Wächterrundgang8; Up to 256 Presets Per Patrol
Muster-Rundgang4; More Than 10 Minutes Per Pattern
Power Off MemoryYes
ParkPreset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
PT StatusTurn On/Turn Off
Geplante AufgabePreset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Doom Reboot/Doom Adjust/Aux Output

Strahler
IR-ReichweiteLaser 3,000 m
IR-Intensität und WinkelAutomatically adjusted

Intelligente Funktion
Normales Ereignismotion detection;video tampering alarm;alarm input and output;audio exception detection;scene change detection
VCASupport 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 10 scenes and 8 VCA rules for each scene
BranderkennungDynamic fire point detection, up to 10 fire points detectable.
Smoke DetectionUp to 12km detection ability with 5m*5m smoke

Video and Audio
HauptstromOptical channel 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 960, 1280 × 720) Thermal channel 25 fps (1920 × 1080, 1280 × 1024, 1280 × 960, 1280 × 720, 704 × 576, 640 × 512, 384 × 288)
Sub-StreamOptical channel 50 Hz: 25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 576, 352 × 288) Thermal channel 25 fps (704 × 576, 640 × 512, 384 × 288)
Video-KomprimierungMain stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG
Audio-KomprimierungG .711u/G.711a/G.722.1/MP2L2/G.726/PCM/AAC

Netzwerk
ProtokolleIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Netzwerk-SpeicherungMicroSD/SDHC/SDXC card (up to 256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
APIISAPI, HIKVISION SDK, Open Network Video Interface (Profile S, Profile G, Profile T)
Gleichzeitige Live-AnsichtUp to 20 channels
Benutzer- / Host-LevelUp to 32 users, 3 levels: Administrator, Operator, User
SicherheitUser authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
ClientiVMS-4200, Hik-Connect, Hik-Central
WebbrowserLive view (plug-in allowed) : Internet Explorer 11 Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 + Local service : Chrome 57.0+, Firefox 52.0 +

Schnittstelle
Alarm-Eingang2-ch inputs (0 to 5 VDC)
Alarm-Ausgang2-ch relay outputs, alarm response actions configurable
AlarmaktionPreset/Patrol Scan/Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage
Audio-Eingang1, 3.5 mm Mic in/Line in interface. Line input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10%
Audio-AusgangLinear Level; Impedance: 600 Ω
Kommunikationsschnittstelle1, RJ45 10 M/100 M/1000 M Self-adaptive Ethernet interface. 1, RS-485 interface
Analog Output1.0 V [p-p]/75 Ω, BNC for thermal channel

Allgemein
Menu Language32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Spannungsversorgung48 VDC ± 20%, 4-pin Aviation Connector
Leistungsaufnahme180 W; Max. 460 W with deicing heating
Working Temperature/HumidityFrom -40°C to 70°C (-40°F to 158°F); Humidity: 90% ± 3% (no condensation)
WischerManual & Scheduled & Smart Wiper
SchutzklasseIP67 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
Abmessungen578.3 mm × 571 mm × 955.7 mm (22.8 " × 22.5 " × 37.6 ")
Approx. 100kg (220.5 lb)

Erkennungsbereichstabelle / Smart-Funktionsbereich
VCA-Bereich Menschen1050 m
VCA-Bereich Fahrzeuge3150 m

Thermalmodul

Bildsensor

VOx Uncooled Focal Plane Arrays

Auflösung der Kamera

1280 × 1024

Pixel Pitch

12 μm

Spectral Range

8 μm to 14 μm

NETD

Less than 35 mK (@ 25 °C,F# = 1.0)

Brennweite

30 to 150 mm

Fokus-Modus

Semi-auto & Manual

IFOV

0.40 to 0.08 mrad

Blende

F0.85 to F1.2

Blickwinkel

28.7° × 23.2° (H × V) to 5.9° × 4.7° (H × V)

Min. Fokussierentfernung

3 m

Digitaler Zoom

×2, ×4, ×8

Optisches Modul

Bildsensor

1/1.8" Progressive Scan CMOS

Auflösung der Kamera

2688 × 1520, 4 MP

Min. Beleuchtung

Color: 0.005 Lux @ (F3.5, AGC ON), B/W: 0.0005 Lux @ (F3.5, AGC ON)

Blickwinkel

31.2° × 17.8° (H × V) to 0.5° × 0.3° (H × V)

Brennweite

10 to 800 mm, 80x

Aperture (Range)

F3.0 to F11.5

Fokus-Modus

Semi-auto & Manual

Digitaler Zoom

×2, ×4, ×8, ×16

Verschlusszeit

1 s to 1/30,000 s

WDR

120 dB

Optical Defog

Yes

Image Effect

Picture in Picture

Display partial image of thermal channel on the full screen of optical channel

Target Coloration

Supported in white hot and black hot mode

Image Stabilization

Thermal channel: Built-in gyroscope to improve EIS performance(conflicted with intelligent function)； Optical channel：Optical Image Stabilization (OIS)

PTZ

Bewegungsbereich

Pan: 360° Continuous Rotate; Tilt: From -45° to + 45° (auto flip)

Pan Speed

Configurable, From 0.01°/s to 120°/s, Preset Speed: 120°/s

Tilt Speed

Configurable, From 0.01°/s to 80°/s, Preset Speed: 80°/s

Proportionalzoom

Yes

Presets

300 in total, 273 are configurable.

Wächterrundgang

8; Up to 256 Presets Per Patrol

Muster-Rundgang

4; More Than 10 Minutes Per Pattern

Power Off Memory

Yes

Park

Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan

PT Status

Turn On/Turn Off

Geplante Aufgabe

Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Doom Reboot/Doom Adjust/Aux Output

Strahler

IR-Reichweite

Laser 3,000 m

IR-Intensität und Winkel

Automatically adjusted

Intelligente Funktion

Normales Ereignis

motion detection;video tampering alarm;alarm input and output;audio exception detection;scene change detection

VCA

Support 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 10 scenes and 8 VCA rules for each scene

Branderkennung

Dynamic fire point detection, up to 10 fire points detectable.

Smoke Detection

Up to 12km detection ability with 5m*5m smoke

Video and Audio

Hauptstrom

Optical channel 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 960, 1280 × 720) Thermal channel 25 fps (1920 × 1080, 1280 × 1024, 1280 × 960, 1280 × 720, 704 × 576, 640 × 512, 384 × 288)

Sub-Stream

Optical channel 50 Hz: 25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 576, 352 × 288) Thermal channel 25 fps (704 × 576, 640 × 512, 384 × 288)

Video-Komprimierung

Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG

Audio-Komprimierung

G .711u/G.711a/G.722.1/MP2L2/G.726/PCM/AAC

Netzwerk

Protokolle

IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE

Netzwerk-Speicherung

MicroSD/SDHC/SDXC card (up to 256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)

API

ISAPI, HIKVISION SDK, Open Network Video Interface (Profile S, Profile G, Profile T)

Gleichzeitige Live-Ansicht

Up to 20 channels

Benutzer- / Host-Level

Up to 32 users, 3 levels: Administrator, Operator, User

Sicherheit

User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering

Client

iVMS-4200, Hik-Connect, Hik-Central

Webbrowser

Live view (plug-in allowed) : Internet Explorer 11 Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 + Local service : Chrome 57.0+, Firefox 52.0 +

Schnittstelle

Alarm-Eingang

2-ch inputs (0 to 5 VDC)

Alarm-Ausgang

2-ch relay outputs, alarm response actions configurable

Alarmaktion

Preset/Patrol Scan/Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage

Audio-Eingang

1, 3.5 mm Mic in/Line in interface. Line input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10%

Audio-Ausgang

Linear Level; Impedance: 600 Ω

Kommunikationsschnittstelle

1, RJ45 10 M/100 M/1000 M Self-adaptive Ethernet interface. 1, RS-485 interface

Analog Output

1.0 V [p-p]/75 Ω, BNC for thermal channel

Allgemein

Menu Language

32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)

Spannungsversorgung

48 VDC ± 20%, 4-pin Aviation Connector

Leistungsaufnahme

180 W; Max. 460 W with deicing heating

Working Temperature/Humidity

From -40°C to 70°C (-40°F to 158°F); Humidity: 90% ± 3% (no condensation)

Wischer

Manual & Scheduled & Smart Wiper

Schutzklasse

IP67 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection

Abmessungen

578.3 mm × 571 mm × 955.7 mm (22.8 " × 22.5 " × 37.6 ")

Approx. 100kg (220.5 lb)

Erkennungsbereichstabelle / Smart-Funktionsbereich

VCA-Bereich Menschen

1050 m

VCA-Bereich Fahrzeuge

3150 m
