2MP 1/2.8 Mobile Bullet Camera

  • High quality imaging with 2 MP resolution
  • 2.8/4/6 mm fixed lens
  • Clear imaging against strong back light due to 120 dB WDR technology
  • Efficient H.265+ compression technology
  • Water and dust resistant (IP67)

Available models:

DS-2XM6222G0-IM/ND(2.8mm)(AE)
DS-2XM6222G0-IM/ND(4mm)(AE)
DS-2XM6222G0-IM/ND(6mm)(AE)
DS-2XM6222G0-ID(2.8mm)(AE)
DS-2XM6222G0-ID(4mm)(AE)
DS-2XM6222G0-ID(6mm)(AE)

Specification

  • กล้อง
  • Image Sensor1/2.8″ Progressive Scan CMOS
  • Min. Illumination0.01 Lux @(F1.2, AGC ON), 0 Lux with IR
  • Shutter Speed 1/3 s to 1/100,000 s
  • Slow ShutterNo
  • Wide Dynamic Range120 dB
  • Day & NightIR Cut Filter
  • Angle AdjustmentPan: -20°-20°, tilt -15°-25°
  • Lens
  • Focal Length & FOV2.8 mm: horizontal FOV 102°, vertical FOV 54°, diagonal FOV 118° 4 mm: horizontal FOV 81°, vertical FOV 43°, diagonal FOV 91° 6 mm: horizontal FOV 49°, vertical FOV 27°, diagonal FOV 57°
  • Lens MountM12
  • ApertureF1.6,
  • Video
  • Max. Resolution1920 × 1080
  • Main Stream50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
  • Sub-Stream50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240) 60Hz: 30fps (704 × 576, 640 × 480, 352 × 288, 320 × 240)
  • Third Streamno
  • Video Compression Main Stream: H.265/H.264 Sub-Stream: H.265/H.264
  • Video Bit Rate256 Kbps to 8 Mbps
  • H.264 TypeBaseLine Profile/Main Profile/High Profile
  • H.265 TypeMain Profile
  • Scalable Video Coding (SVC)H.264 and H.265 encoding
  • Network
  • ProtocolsTCP/IP, ICMP, HTTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, SNMP, QoS, FTP,SMTP,HTTPS
  • Simultaneous Live ViewUp to 8 channels
  • APIONVIF (PROFILE S, PROFILE G), ISAPI, SDK
  • User/HostUp to 32 users,3 levels: Administrator, Operator and User
  • Network StoragemicroSD/SDHC/SDXC card (up to 128 GB),
  • Clientno
  • Web BrowserPlug-in required live view: IE10;
  • Image
  • Image Settingssaturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
  • Day/Night SwitchDay/Night/Auto/Schedule
  • Image EnhancementBLC, 3D DNR,
  • DNR 3D DNR
  • Interface
  • Ethernet InterfaceWithout -M: 1 RJ45 10M/100M self-adaptive Ethernet port -M: 1 four-core M12 aviation plug
  • On-Board Storage Built-in micro SD/SDHC/SDXC slot, up to 128 GB
  • Alarm no
  • Reset KeyYes
  • Event
  • Basic Event Motion detection, video tampering alarm
  • Smart Eventno
  • LinkageUpload to FTP, notify surveillance center, send email, trigger recording,
  • General
  • Camera Dimension78.8 × 81.6 × 64 mm (3.1" × 3.2" × 2.5")
  • Camera WeightApprox. 330 g (0.7 lb.)
  • Startup and Operating Conditions -30 °C to 75 °C (-22 °F to 167°F), humidity less than 95% or less (non-condensing)
  • General Function Anti-flicker, heartbeat, mirror,
  • Power Consumption and Current0.14 A to 0.09 A, max. 5.2 W
  • Power Supply-ID: 9-36V, Ø5.5 mm coaxial power plug -IM/ND: PoE: 802.3af(36 V to 57 V), Class 3

Specification

Firmware
Applied to:
DS-2XM6222G0-IM/ND(2.8mm)(AE)
DS-2XM6222G0-IM/ND(4mm)(AE)
DS-2XM6222G0-IM/ND(6mm)(AE)
DS-2XM6222G0-ID(2.8mm)(AE)
DS-2XM6222G0-ID(4mm)(AE)
DS-2XM6222G0-ID(6mm)(AE)
*For better user experience, we highly recommend you to update your device to the latest firmware asap.
