DS-2CE70DF3T-PTS

2MP ColorVu Indoor Audio Fixed PT Camera

  • High quality imaging with 2 MP, 1920 × 1080 resolution
  • 24/7 color imaging with F1.0 aperture
  • Clear imaging against strong back light due to 130 dB true WDR technology
  • 3D DNR technology delivers clean and sharp images
  • Fixed focal lens, 2.8, and 3.6 mm optional
  • Up to 20 m white light distance for bright night images
  • High quality audio with audio over coaxial cable, built-in microphone
View Less
View more

Available models:

DS-2CE70DF3T-PTS(2.8mm)
DS-2CE70DF3T-PTS(3.6mm)

Specification

  • กล้อง
  • Image Sensor2 MP CMOS
  • Max. Resolution1920 (H) × 1080 (V)
  • Min. Illumination0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
  • Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
  • Day & Night24/7 Color Imaging
  • Angle AdjustmentPan: 0 to 350°, tilt: 0 to 75° *DO NOT adjust the angle of the main body or enclosure manually.
  • Signal SystemPAL/NTSC
  • Slow ShutterMax. 16 times
  • Lens
  • Lens TypeFixed focal lens, 2.8 and 3.6 mm optional
  • Focal Length & FOV2.8 mm, horizontal FOV: 106°, vertical FOV: 57°, diagonal FOV: 126° 3.6 mm, horizontal FOV: 83°, vertical FOV: 44°, diagonal FOV: 99°
  • Lens MountM12
  • Illuminator
  • Supplement Light TypeWhite Light
  • Supplement Light RangeUp to 20 m
  • Smart Supplement LightYes
  • Image
  • Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
  • Image SettingsBrightness;Contrast;Mirror;Sharpness;Anti-Banding;Saturation;AGC
  • Frame RateTVI: 1080P@25 fps/30 fps
  • Day/Night ModeColor
  • Wide Dynamic Range (WDR)≥130 dB
  • Image EnhancementBLC;HLC;Global;HLS
  • Privacy Mask4 programmable privacy masks
  • Noise Reduction3D DNR/2D DNR
  • White BalanceAuto/Manual
  • White LightAuto/Off
  • Interface
  • Video Output1 HD analog output
  • AlarmSolid Light Alarm (White Light)
  • Built-in MicrophoneYes
  • Event
  • Motion Detection4 programmable motion areas
  • General
  • Power12 VDC ± 25%, max. 7.4 W *You are recommended to use one power adapter to supply the power for one camera.
  • MaterialPlastic
  • DimensionØ123.7 × 110.8 (4.9" × 4.4")
  • WeightApprox. 290 g (0.6 lb.)
  • Operating Condition-10 °C to 40 °C (14 °F to 104 °F). Humidity 90% or less (non-condensing)
  • CommunicationHIKVISION-C
  • LanguageEnglish

Specification

Specification
กล้อง
  • Image Sensor2 MP CMOS
  • Max. Resolution1920 (H) × 1080 (V)
  • Min. Illumination0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
  • Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
  • Day & Night24/7 Color Imaging
  • Angle AdjustmentPan: 0 to 350°, tilt: 0 to 75° *DO NOT adjust the angle of the main body or enclosure manually.
  • Signal SystemPAL/NTSC
  • Slow ShutterMax. 16 times
Lens
  • Lens TypeFixed focal lens, 2.8 and 3.6 mm optional
  • Focal Length & FOV2.8 mm, horizontal FOV: 106°, vertical FOV: 57°, diagonal FOV: 126° 3.6 mm, horizontal FOV: 83°, vertical FOV: 44°, diagonal FOV: 99°
  • Lens MountM12
Illuminator
  • Supplement Light TypeWhite Light
  • Supplement Light RangeUp to 20 m
  • Smart Supplement LightYes
  • Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
  • Image SettingsBrightness;Contrast;Mirror;Sharpness;Anti-Banding;Saturation;AGC
  • Frame RateTVI: 1080P@25 fps/30 fps
  • Day/Night ModeColor
  • Wide Dynamic Range (WDR)≥130 dB
  • Image EnhancementBLC;HLC;Global;HLS
  • Privacy Mask4 programmable privacy masks
  • Noise Reduction3D DNR/2D DNR
  • White BalanceAuto/Manual
  • White LightAuto/Off
Interface
  • Video Output1 HD analog output
  • AlarmSolid Light Alarm (White Light)
  • Built-in MicrophoneYes
Event
  • Motion Detection4 programmable motion areas
General
  • Power12 VDC ± 25%, max. 7.4 W *You are recommended to use one power adapter to supply the power for one camera.
  • MaterialPlastic
  • DimensionØ123.7 × 110.8 (4.9" × 4.4")
  • WeightApprox. 290 g (0.6 lb.)
  • Operating Condition-10 °C to 40 °C (14 °F to 104 °F). Humidity 90% or less (non-condensing)
  • CommunicationHIKVISION-C
  • LanguageEnglish
