Built-in AVR
Super fast charging
Wide input voltage range
Overload protection
Short circuit protection
Surge protection
USB port for remote control
LCD display

View Less

Ficha Técnica

Modelos disponibles:

DS-UPS2000-x

DS-UPS2000

Especificación
Resources
Accesorios

Ficha Técnica

alimentación
UPS Capacity 2000 VA / 1200 W

Entrada
Input Voltage Range 85 VAC to 150 VAC
Input Frequency 50/60 Hz self-adaptive
Plug Type Type B (NEMA 5-15)

Salida
Rango de voltaje de salida 110 VAC to 125 VAC
Output Frequency 60 Hz ± 0.5 Hz
Transfer Time ≤ 10 ms
Waveform PWM
Outlet Type Type B (NEMA 5-15)
Outlet Number 6

batería
Tipo de batería 12 V/9 Ah *2 pcs, lead-acid battery
Recharge Time 6-8 hours recover to 90% capacity
Typical Backup Time Run time at 100w: 70 min Run time at 300w: 17 min Run time at 600w: 5 min

Interfaz
Communicate Ports USB

Protección
Full Protection Surge protection, Overload protection, Discharge protection, Short circuit protection

indicador
pantalla LCD Screen Input Voltage, Output Voltage, Battery capacity, load level
Alarma Charging Mode (DC mode): Sounding every 8 seconds Low Battery: Sounding every second Overloading Mode: Sounding every 0.5 seconds Fault: Continuously sounding

General
Temperatura de funcionamiento 0 °C to 40 °C (32 °F to 104 °F）
Condiciones de humedad 30% to 90% (non-condensing)
Dimensión 345 mm × 122 mm × 192 mm (13.58" × 4.80" × 7.56")
Approx. 11 kg (24.3 lb)

alimentación

UPS Capacity

2000 VA / 1200 W

Entrada

Input Voltage Range

140 VAC to 290 VAC

Input Frequency

50/60 Hz self-adaptive

Plug Type

AU TYPE I;TYPE H;Type B (NEMA 5-15);UK TYPE G;TYPE L (10A);Schuko

Salida

Rango de voltaje de salida

210 VAC to 235 VAC

Output Frequency

50/60 Hz ± 0.5 Hz self-adaptive

Transfer Time

≤ 10 ms

Waveform

PWM

Outlet Type

AU TYPE I;TYPE H;Type B (NEMA 5-15);Universal;TYPE L (10/16A);Schuko

Outlet Number

2;6;4

batería

Tipo de batería

12 V/9 Ah *2 pcs, lead-acid battery

Recharge Time

6-8 hours recover to 90% capacity

Typical Backup Time

Run time at 100w: 70 min Run time at 300w: 17 min Run time at 600w: 5 min

Interfaz

Communicate Ports

USB

Protección

Full Protection

Surge protection, Overload protection, Discharge protection, Short circuit protection

indicador

pantalla

LCD Screen Input Voltage, Output Voltage, Battery capacity, load level

Alarma

Charging Mode (DC mode): Sounding every 8 seconds Low Battery: Sounding every second Overloading Mode: Sounding every 0.5 seconds Fault: Continuously sounding

General

Temperatura de funcionamiento

0 °C to 40 °C (32 °F to 104 °F）

Condiciones de humedad

30% to 90% (non-condensing)

Dimensión

345 mm × 122 mm × 192 mm (13.58" × 4.80" × 7.56")

Approx. 11 kg (24.3 lb)
