EOL

Mobile Mini Dome Network Camera

High quality imaging with 3 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB WDR technology

View Less

Data Sheet

Available models:

DS-2XM6736G0-IS/ND(2.8mm)

DS-2XM6736G0-IM/ND(2.8mm)

DS-2XM6736G0-IM/ND(2.0mm)

DS-2XM6736G0-I(D)(S)(M)(/ND)

EOL

Specification
Resources
Accessories

Data Sheet

Kamera
Image Sensor1/3″ Progressive Scan CMOS
Min. IlluminationColor: 0.018 Lux @ (F1.6, AGC ON)
Shutter Speed1/3 s to 1/100,000 s
Slow ShutterYes
Angle AdjustmentPan: -30° to +30°, Tilt: 0° to 75°, Rotate: 0° to 360°
Digital Noise Reduction3D DNR
WDR120 dB
Day & NightIR Cut Filter

Lens
Auto-IrisNo
Aperture2 mm, F2.25, 2.8/4/6 mm, F2.0, 8 mm, F1.6,
FOV2 mm, horizontal FOV 122.6°, vertical FOV 71.7°, diagonal FOV 139.9° 2.8 mm, horizontal FOV 100.6°, vertical FOV 55.1°, diagonal FOV 117.4° 4 mm, horizontal FOV 75.3°, vertical FOV 41.4°, diagonal FOV 88.2° 6 mm, horizontal FOV 51.6°, vertical FOV 28.8°, diagonal FOV 59.5° 8 mm, horizontal FOV 37.5°, vertical FOV 20.7°, diagonal FOV 43.3°
Lens MountM12
Focal length2.0/2.8/4/6/8 mm fixed lens

Video
Max. Resolution1920 × 1080
Main Stream50Hz:25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub Stream50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240)
Video CompressionMain stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
H.264 TypeMain Profile/High Profile
H.265 TypeMain Profile
Video Bit Rate32 Kbps to 16 Mbps
SVCH.264 and H.265 encoding

Audio
Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/MP3
Audio Bit Rate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/8Kbps-320Kbps(MP3)
Environment Noise FilteringYes
Audio Sampling Rate8kHz/16kHz/32kHz/44.1kHz/48kHz

Smart Feature-Set
Smart EventLine crossing detection, up to 1 line configurable Intrusion detection, up to 1 region configurable Unattended baggage detection, up to 1 region configurable Object removal detection, up to 1 region configurable Face detection: detects faces and upload images
Basic EventMotion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Region of Interest1 fixed region for main stream and sub stream
Linkage MethodUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture

Image EnhancementBLC, HLC, 3D DNR
Image SettingRotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser
Day/Night SwitchDay/Night/Auto/Schedule

Network
Network StoragemicroSD/SDHC/SDXC card (up to 128 GB), local storage and NAS (NFS,SMB/CIFS), ANR Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
APIONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Simultaneous Live ViewUp to 6 channels
User/HostUp to 32 users,3 levels: Administrator, Operator and User
ClientiVMS-4200, Hik-Connect, Hik-Central
Web BrowserPlug-in required live view: IE8+, Chrome 41.0-44, Mozilla Firefox30.0-51, Safari8.0-11 Plug-in free live view: Chrome 45+, Mozilla Firefox52+

Interface
Communication Interface1 RJ45 10M/100M Ethernet port
Audio1 built-in mic, mono sound
Alarm1 input, 1 output (12 VDC, 30 mA)
Reset ButtonYes
On-board storageBuilt-in micro SD/SDHC/SDXC slot, up to 128 GB

Compression Standard
H.264+Main stream support.
H.265+Main stream support.

General
General FunctionAnti-flicker, 3 streams, heartbeat, mirror, privacy mask
Power Supply-IDS:24 VDC is recommended, support 8 to 36 VDC, Φ 5.5 mm coaxial power plug -IS/ND: PoE: 802.3af, Class 3 -IDM: 24 VDC is recommended, support 8 to 36 VDC, two-core molex -IM/ND: PoE: 802.3af, Class 3
Power Consumption and Current-IDS: 24 VDC, 0.3 A, max. 7.5 W -IS/ND: PoE: (802.3af, 36V to 57V), 0.30 A to 0.20 A, max: 7.5W -IDM: 24 VDC, 0.3 A, max. 7.5 W -IM/ND: PoE: (802.3af, 36V to 57V), 0.30 A to 0.20 A, max: 7.5W
MaterialMetal
DimensionsCamera: Φ 110 mm × 57.4 mm (4.3″ × 2.26″), with base: Φ 110 mm × 69.4 mm (4.3″ × 2.7″) With package: 252 mm × 160 mm × 95 mm (9.9″ × 6.3″ × 3.7″)
WeightCamera: Approx. 460 g (1 lb.) With package: 900 g (2 lb)
Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F), humidity less than 95% or less (non-condensing)
Protection LevelIP67, IK10

Kamera

Image Sensor

1/3″ Progressive Scan CMOS

Min. Illumination

Color: 0.018 Lux @ (F1.6, AGC ON)

Shutter Speed

1/3 s to 1/100,000 s

Slow Shutter

Yes

Angle Adjustment

Pan: -30° to +30°, Tilt: 0° to 75°, Rotate: 0° to 360°

Digital Noise Reduction

3D DNR

WDR

120 dB

Day & Night

IR Cut Filter

Lens

Auto-Iris

Aperture

2 mm, F2.25, 2.8/4/6 mm, F2.0, 8 mm, F1.6,

FOV

2 mm, horizontal FOV 122.6°, vertical FOV 71.7°, diagonal FOV 139.9° 2.8 mm, horizontal FOV 100.6°, vertical FOV 55.1°, diagonal FOV 117.4° 4 mm, horizontal FOV 75.3°, vertical FOV 41.4°, diagonal FOV 88.2° 6 mm, horizontal FOV 51.6°, vertical FOV 28.8°, diagonal FOV 59.5° 8 mm, horizontal FOV 37.5°, vertical FOV 20.7°, diagonal FOV 43.3°

Lens Mount

M12

Focal length

2.0/2.8/4/6/8 mm fixed lens

Video

Max. Resolution

1920 × 1080

Main Stream

50Hz:25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)

Sub Stream

50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)

Third Stream

50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240)

Video Compression

Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264

H.264 Type

Main Profile/High Profile

H.265 Type

Main Profile

Video Bit Rate

32 Kbps to 16 Mbps

SVC

H.264 and H.265 encoding

Audio

Audio Compression

G.711/G.722.1/G.726/MP2L2/PCM/MP3

Audio Bit Rate

64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/8Kbps-320Kbps(MP3)

Environment Noise Filtering

Yes

Audio Sampling Rate

8kHz/16kHz/32kHz/44.1kHz/48kHz

Smart Feature-Set

Smart Event

Line crossing detection, up to 1 line configurable Intrusion detection, up to 1 region configurable Unattended baggage detection, up to 1 region configurable Object removal detection, up to 1 region configurable Face detection: detects faces and upload images

Basic Event

Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)

Region of Interest

1 fixed region for main stream and sub stream

Linkage Method

Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture


Image Enhancement

BLC, HLC, 3D DNR

Image Setting

Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser

Day/Night Switch

Day/Night/Auto/Schedule

Network

Network Storage

microSD/SDHC/SDXC card (up to 128 GB), local storage and NAS (NFS,SMB/CIFS), ANR Together with high-end Hikvision memory card, memory card encryption and health detection are supported.

Protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS

API

ONVIF (PROFILE S, PROFILE G), ISAPI, SDK

Simultaneous Live View

Up to 6 channels

User/Host

Up to 32 users,3 levels: Administrator, Operator and User

Client

iVMS-4200, Hik-Connect, Hik-Central

Web Browser

Plug-in required live view: IE8+, Chrome 41.0-44, Mozilla Firefox30.0-51, Safari8.0-11 Plug-in free live view: Chrome 45+, Mozilla Firefox52+

Interface

Communication Interface

1 RJ45 10M/100M Ethernet port

Audio

1 built-in mic, mono sound

Alarm

1 input, 1 output (12 VDC, 30 mA)

Reset Button

Yes

On-board storage

Built-in micro SD/SDHC/SDXC slot, up to 128 GB

Compression Standard

H.264+

Main stream support.

H.265+

Main stream support.

General

General Function

Anti-flicker, 3 streams, heartbeat, mirror, privacy mask

Power Supply

-IDS:24 VDC is recommended, support 8 to 36 VDC, Φ 5.5 mm coaxial power plug -IS/ND: PoE: 802.3af, Class 3 -IDM: 24 VDC is recommended, support 8 to 36 VDC, two-core molex -IM/ND: PoE: 802.3af, Class 3

Power Consumption and Current

-IDS: 24 VDC, 0.3 A, max. 7.5 W -IS/ND: PoE: (802.3af, 36V to 57V), 0.30 A to 0.20 A, max: 7.5W -IDM: 24 VDC, 0.3 A, max. 7.5 W -IM/ND: PoE: (802.3af, 36V to 57V), 0.30 A to 0.20 A, max: 7.5W

Material

Metal

Dimensions

Camera: Φ 110 mm × 57.4 mm (4.3″ × 2.26″), with base: Φ 110 mm × 69.4 mm (4.3″ × 2.7″) With package: 252 mm × 160 mm × 95 mm (9.9″ × 6.3″ × 3.7″)

Weight

Camera: Approx. 460 g (1 lb.) With package: 900 g (2 lb)

Operating Conditions

-30 °C to 60 °C (-22 °F to 140 °F), humidity less than 95% or less (non-condensing)

Protection Level

IP67, IK10

Kamera

Image Sensor1/3″ Progressive Scan CMOS
Min. IlluminationColor: 0.018 Lux @ (F1.6, AGC ON)
Shutter Speed1/3 s to 1/100,000 s
Slow ShutterYes
Angle AdjustmentPan: -30° to +30°, Tilt: 0° to 75°, Rotate: 0° to 360°
Digital Noise Reduction3D DNR
WDR120 dB
Day & NightIR Cut Filter

Lens

Auto-IrisNo
Aperture2 mm, F2.25, 2.8/4/6 mm, F2.0, 8 mm, F1.6,
FOV2 mm, horizontal FOV 122.6°, vertical FOV 71.7°, diagonal FOV 139.9° 2.8 mm, horizontal FOV 100.6°, vertical FOV 55.1°, diagonal FOV 117.4° 4 mm, horizontal FOV 75.3°, vertical FOV 41.4°, diagonal FOV 88.2° 6 mm, horizontal FOV 51.6°, vertical FOV 28.8°, diagonal FOV 59.5° 8 mm, horizontal FOV 37.5°, vertical FOV 20.7°, diagonal FOV 43.3°
Lens MountM12
Focal length2.0/2.8/4/6/8 mm fixed lens

Video

Max. Resolution1920 × 1080
Main Stream50Hz:25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub Stream50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240)
Video CompressionMain stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
H.264 TypeMain Profile/High Profile
H.265 TypeMain Profile
Video Bit Rate32 Kbps to 16 Mbps
SVCH.264 and H.265 encoding

Audio

Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/MP3
Audio Bit Rate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/8Kbps-320Kbps(MP3)
Environment Noise FilteringYes
Audio Sampling Rate8kHz/16kHz/32kHz/44.1kHz/48kHz

Smart Feature-Set

Smart EventLine crossing detection, up to 1 line configurable Intrusion detection, up to 1 region configurable Unattended baggage detection, up to 1 region configurable Object removal detection, up to 1 region configurable Face detection: detects faces and upload images
Basic EventMotion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Region of Interest1 fixed region for main stream and sub stream
Linkage MethodUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture


Image EnhancementBLC, HLC, 3D DNR
Image SettingRotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser
Day/Night SwitchDay/Night/Auto/Schedule

Network

Network StoragemicroSD/SDHC/SDXC card (up to 128 GB), local storage and NAS (NFS,SMB/CIFS), ANR Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
APIONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Simultaneous Live ViewUp to 6 channels
User/HostUp to 32 users,3 levels: Administrator, Operator and User
ClientiVMS-4200, Hik-Connect, Hik-Central
Web BrowserPlug-in required live view: IE8+, Chrome 41.0-44, Mozilla Firefox30.0-51, Safari8.0-11 Plug-in free live view: Chrome 45+, Mozilla Firefox52+

Interface

Communication Interface1 RJ45 10M/100M Ethernet port
Audio1 built-in mic, mono sound
Alarm1 input, 1 output (12 VDC, 30 mA)
Reset ButtonYes
On-board storageBuilt-in micro SD/SDHC/SDXC slot, up to 128 GB

Compression Standard

H.264+Main stream support.
H.265+Main stream support.

General

General FunctionAnti-flicker, 3 streams, heartbeat, mirror, privacy mask
Power Supply-IDS:24 VDC is recommended, support 8 to 36 VDC, Φ 5.5 mm coaxial power plug -IS/ND: PoE: 802.3af, Class 3 -IDM: 24 VDC is recommended, support 8 to 36 VDC, two-core molex -IM/ND: PoE: 802.3af, Class 3
Power Consumption and Current-IDS: 24 VDC, 0.3 A, max. 7.5 W -IS/ND: PoE: (802.3af, 36V to 57V), 0.30 A to 0.20 A, max: 7.5W -IDM: 24 VDC, 0.3 A, max. 7.5 W -IM/ND: PoE: (802.3af, 36V to 57V), 0.30 A to 0.20 A, max: 7.5W
MaterialMetal
DimensionsCamera: Φ 110 mm × 57.4 mm (4.3″ × 2.26″), with base: Φ 110 mm × 69.4 mm (4.3″ × 2.7″) With package: 252 mm × 160 mm × 95 mm (9.9″ × 6.3″ × 3.7″)
WeightCamera: Approx. 460 g (1 lb.) With package: 900 g (2 lb)
Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F), humidity less than 95% or less (non-condensing)
Protection LevelIP67, IK10

Technical documents

Data Sheet

Firmware

For better user experience, we highly recommend you to update your device to the latest firmware asap.

Firmware

For better user experience, we highly recommend you to update your device to the latest firmware asap.

Firmware_V5.6.2_190701

【Release Note】Mobile IPC V5.6.2_190701

Applied to:

DS-2XM6736G0-IM/ND(2.8mm)

DS-2XM6736G0-IM/ND(2.0mm)

DS-2XM6736G0-I(D)(S)(M)(/ND)

EOL

Specification
Resources
Accessories

Data Sheet

Kamera
Image Sensor1/3″ Progressive Scan CMOS
Min. IlluminationColor: 0.018 Lux @ (F1.6, AGC ON)
Shutter Speed1/3 s to 1/100,000 s
Slow ShutterYes
Angle AdjustmentPan: -30° to +30°, Tilt: 0° to 75°, Rotate: 0° to 360°
Digital Noise Reduction3D DNR
WDR120 dB
Day & NightIR Cut Filter

Lens
Auto-IrisNo
Aperture2 mm, F2.25, 2.8/4/6 mm, F2.0, 8 mm, F1.6,
FOV2 mm, horizontal FOV 122.6°, vertical FOV 71.7°, diagonal FOV 139.9° 2.8 mm, horizontal FOV 100.6°, vertical FOV 55.1°, diagonal FOV 117.4° 4 mm, horizontal FOV 75.3°, vertical FOV 41.4°, diagonal FOV 88.2° 6 mm, horizontal FOV 51.6°, vertical FOV 28.8°, diagonal FOV 59.5° 8 mm, horizontal FOV 37.5°, vertical FOV 20.7°, diagonal FOV 43.3°
Lens MountM12
Focal length2.0/2.8/4/6/8 mm fixed lens

Video
Max. Resolution1920 × 1080
Main Stream50Hz:25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub Stream50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240)
Video CompressionMain stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
H.264 TypeMain Profile/High Profile
H.265 TypeMain Profile
Video Bit Rate32 Kbps to 16 Mbps
SVCH.264 and H.265 encoding

Audio
Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/MP3
Audio Bit Rate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/8Kbps-320Kbps(MP3)
Environment Noise FilteringYes
Audio Sampling Rate8kHz/16kHz/32kHz/44.1kHz/48kHz

Smart Feature-Set
Smart EventLine crossing detection, up to 1 line configurable Intrusion detection, up to 1 region configurable Unattended baggage detection, up to 1 region configurable Object removal detection, up to 1 region configurable Face detection: detects faces and upload images
Basic EventMotion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Region of Interest1 fixed region for main stream and sub stream
Linkage MethodUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture

Image EnhancementBLC, HLC, 3D DNR
Image SettingRotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser
Day/Night SwitchDay/Night/Auto/Schedule

Network
Network StoragemicroSD/SDHC/SDXC card (up to 128 GB), local storage and NAS (NFS,SMB/CIFS), ANR Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
APIONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Simultaneous Live ViewUp to 6 channels
User/HostUp to 32 users,3 levels: Administrator, Operator and User
ClientiVMS-4200, Hik-Connect, Hik-Central
Web BrowserPlug-in required live view: IE8+, Chrome 41.0-44, Mozilla Firefox30.0-51, Safari8.0-11 Plug-in free live view: Chrome 45+, Mozilla Firefox52+

Interface
Communication Interface1 RJ45 10M/100M Ethernet port
Audio1 built-in mic, mono sound
Alarm1 input, 1 output (12 VDC, 30 mA)
Reset ButtonYes
On-board storageBuilt-in micro SD/SDHC/SDXC slot, up to 128 GB

Compression Standard
H.264+Main stream support.
H.265+Main stream support.

General
General FunctionAnti-flicker, 3 streams, heartbeat, mirror, privacy mask
Power Supply-IDS:24 VDC is recommended, support 8 to 36 VDC, Φ 5.5 mm coaxial power plug -IS/ND: PoE: 802.3af, Class 3 -IDM: 24 VDC is recommended, support 8 to 36 VDC, two-core molex -IM/ND: PoE: 802.3af, Class 3
Power Consumption and Current-IDS: 24 VDC, 0.3 A, max. 7.5 W -IS/ND: PoE: (802.3af, 36V to 57V), 0.30 A to 0.20 A, max: 7.5W -IDM: 24 VDC, 0.3 A, max. 7.5 W -IM/ND: PoE: (802.3af, 36V to 57V), 0.30 A to 0.20 A, max: 7.5W
MaterialMetal
DimensionsCamera: Φ 110 mm × 57.4 mm (4.3″ × 2.26″), with base: Φ 110 mm × 69.4 mm (4.3″ × 2.7″) With package: 252 mm × 160 mm × 95 mm (9.9″ × 6.3″ × 3.7″)
WeightCamera: Approx. 460 g (1 lb.) With package: 900 g (2 lb)
Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F), humidity less than 95% or less (non-condensing)
Protection LevelIP67, IK10

Kamera

Image Sensor

1/3″ Progressive Scan CMOS

Min. Illumination

Color: 0.018 Lux @ (F1.6, AGC ON)

Shutter Speed

1/3 s to 1/100,000 s

Slow Shutter

Yes

Angle Adjustment

Pan: -30° to +30°, Tilt: 0° to 75°, Rotate: 0° to 360°

Digital Noise Reduction

3D DNR

WDR

120 dB

Day & Night

IR Cut Filter

Lens

Auto-Iris

Aperture

2 mm, F2.25, 2.8/4/6 mm, F2.0, 8 mm, F1.6,

FOV

Lens Mount

M12

Focal length

2.0/2.8/4/6/8 mm fixed lens

Video

Max. Resolution

1920 × 1080

Main Stream

50Hz:25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)

Sub Stream

50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)

Third Stream

50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240)

Video Compression

Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264

H.264 Type

Main Profile/High Profile

H.265 Type

Main Profile

Video Bit Rate

32 Kbps to 16 Mbps

SVC

H.264 and H.265 encoding

Audio

Audio Compression

G.711/G.722.1/G.726/MP2L2/PCM/MP3

Audio Bit Rate

64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/8Kbps-320Kbps(MP3)

Environment Noise Filtering

Yes

Audio Sampling Rate

8kHz/16kHz/32kHz/44.1kHz/48kHz

Smart Feature-Set

Smart Event

Basic Event

Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)

Region of Interest

1 fixed region for main stream and sub stream

Linkage Method

Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture


Image Enhancement

BLC, HLC, 3D DNR

Image Setting

Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser

Day/Night Switch

Day/Night/Auto/Schedule

Network

Network Storage

microSD/SDHC/SDXC card (up to 128 GB), local storage and NAS (NFS,SMB/CIFS), ANR Together with high-end Hikvision memory card, memory card encryption and health detection are supported.

Protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS

API

ONVIF (PROFILE S, PROFILE G), ISAPI, SDK

Simultaneous Live View

Up to 6 channels

User/Host

Up to 32 users,3 levels: Administrator, Operator and User

Client

iVMS-4200, Hik-Connect, Hik-Central

Web Browser

Plug-in required live view: IE8+, Chrome 41.0-44, Mozilla Firefox30.0-51, Safari8.0-11 Plug-in free live view: Chrome 45+, Mozilla Firefox52+

Interface

Communication Interface

1 RJ45 10M/100M Ethernet port

Audio

1 built-in mic, mono sound

Alarm

1 input, 1 output (12 VDC, 30 mA)

Reset Button

Yes

On-board storage

Built-in micro SD/SDHC/SDXC slot, up to 128 GB

Compression Standard

H.264+

Main stream support.

H.265+

Main stream support.

General

General Function

Anti-flicker, 3 streams, heartbeat, mirror, privacy mask

Power Supply

Power Consumption and Current

-IDS: 24 VDC, 0.3 A, max. 7.5 W -IS/ND: PoE: (802.3af, 36V to 57V), 0.30 A to 0.20 A, max: 7.5W -IDM: 24 VDC, 0.3 A, max. 7.5 W -IM/ND: PoE: (802.3af, 36V to 57V), 0.30 A to 0.20 A, max: 7.5W

Material

Metal

Dimensions

Camera: Φ 110 mm × 57.4 mm (4.3″ × 2.26″), with base: Φ 110 mm × 69.4 mm (4.3″ × 2.7″) With package: 252 mm × 160 mm × 95 mm (9.9″ × 6.3″ × 3.7″)

Weight

Camera: Approx. 460 g (1 lb.) With package: 900 g (2 lb)

Operating Conditions

-30 °C to 60 °C (-22 °F to 140 °F), humidity less than 95% or less (non-condensing)

Protection Level

IP67, IK10

Kamera

Image Sensor1/3″ Progressive Scan CMOS
Min. IlluminationColor: 0.018 Lux @ (F1.6, AGC ON)
Shutter Speed1/3 s to 1/100,000 s
Slow ShutterYes
Angle AdjustmentPan: -30° to +30°, Tilt: 0° to 75°, Rotate: 0° to 360°
Digital Noise Reduction3D DNR
WDR120 dB
Day & NightIR Cut Filter

Lens

Auto-IrisNo
Aperture2 mm, F2.25, 2.8/4/6 mm, F2.0, 8 mm, F1.6,
FOV2 mm, horizontal FOV 122.6°, vertical FOV 71.7°, diagonal FOV 139.9° 2.8 mm, horizontal FOV 100.6°, vertical FOV 55.1°, diagonal FOV 117.4° 4 mm, horizontal FOV 75.3°, vertical FOV 41.4°, diagonal FOV 88.2° 6 mm, horizontal FOV 51.6°, vertical FOV 28.8°, diagonal FOV 59.5° 8 mm, horizontal FOV 37.5°, vertical FOV 20.7°, diagonal FOV 43.3°
Lens MountM12
Focal length2.0/2.8/4/6/8 mm fixed lens

Video

Max. Resolution1920 × 1080
Main Stream50Hz:25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub Stream50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240)
Video CompressionMain stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
H.264 TypeMain Profile/High Profile
H.265 TypeMain Profile
Video Bit Rate32 Kbps to 16 Mbps
SVCH.264 and H.265 encoding

Audio

Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/MP3
Audio Bit Rate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/8Kbps-320Kbps(MP3)
Environment Noise FilteringYes
Audio Sampling Rate8kHz/16kHz/32kHz/44.1kHz/48kHz

Smart Feature-Set

Smart EventLine crossing detection, up to 1 line configurable Intrusion detection, up to 1 region configurable Unattended baggage detection, up to 1 region configurable Object removal detection, up to 1 region configurable Face detection: detects faces and upload images
Basic EventMotion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Region of Interest1 fixed region for main stream and sub stream
Linkage MethodUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture


Image EnhancementBLC, HLC, 3D DNR
Image SettingRotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser
Day/Night SwitchDay/Night/Auto/Schedule

Network

Network StoragemicroSD/SDHC/SDXC card (up to 128 GB), local storage and NAS (NFS,SMB/CIFS), ANR Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
APIONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Simultaneous Live ViewUp to 6 channels
User/HostUp to 32 users,3 levels: Administrator, Operator and User
ClientiVMS-4200, Hik-Connect, Hik-Central
Web BrowserPlug-in required live view: IE8+, Chrome 41.0-44, Mozilla Firefox30.0-51, Safari8.0-11 Plug-in free live view: Chrome 45+, Mozilla Firefox52+

Interface

Communication Interface1 RJ45 10M/100M Ethernet port
Audio1 built-in mic, mono sound
Alarm1 input, 1 output (12 VDC, 30 mA)
Reset ButtonYes
On-board storageBuilt-in micro SD/SDHC/SDXC slot, up to 128 GB

Compression Standard

H.264+Main stream support.
H.265+Main stream support.

General

General FunctionAnti-flicker, 3 streams, heartbeat, mirror, privacy mask
Power Supply-IDS:24 VDC is recommended, support 8 to 36 VDC, Φ 5.5 mm coaxial power plug -IS/ND: PoE: 802.3af, Class 3 -IDM: 24 VDC is recommended, support 8 to 36 VDC, two-core molex -IM/ND: PoE: 802.3af, Class 3
Power Consumption and Current-IDS: 24 VDC, 0.3 A, max. 7.5 W -IS/ND: PoE: (802.3af, 36V to 57V), 0.30 A to 0.20 A, max: 7.5W -IDM: 24 VDC, 0.3 A, max. 7.5 W -IM/ND: PoE: (802.3af, 36V to 57V), 0.30 A to 0.20 A, max: 7.5W
MaterialMetal
DimensionsCamera: Φ 110 mm × 57.4 mm (4.3″ × 2.26″), with base: Φ 110 mm × 69.4 mm (4.3″ × 2.7″) With package: 252 mm × 160 mm × 95 mm (9.9″ × 6.3″ × 3.7″)
WeightCamera: Approx. 460 g (1 lb.) With package: 900 g (2 lb)
Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F), humidity less than 95% or less (non-condensing)
Protection LevelIP67, IK10

Technical documents

Data Sheet

Firmware

For better user experience, we highly recommend you to update your device to the latest firmware asap.

Firmware

For better user experience, we highly recommend you to update your device to the latest firmware asap.

Firmware_V5.6.2_190701

【Release Note】Mobile IPC V5.6.2_190701

Applied to:

DS-2XM6736G0-IM/ND(2.8mm)

DS-2XM6736G0-IM/ND(2.0mm)

DS-2XM6736G0-I(D)(S)(M)(/ND)

Mobile Mini Dome Network Camera

Specification

Kamera

Lens

Video

Audio

Smart Feature-Set


Network

Interface

Compression Standard

General

Specification

Resources

Technical documents

Firmware

Firmware

Specification

Kamera

Lens

Video

Audio

Smart Feature-Set


Network

Interface

Compression Standard

General

Specification

Resources

Technical documents

Firmware

Firmware

Get a better browsing experience
