Bullet Underwater Network Camera

316L stainless steel enclosure, protecting cameras to be used in corrosive environments, providing reliability and longevity compared to standard cameras
IP68: the camera can be used under water up to 50 meters
H.265+/H.265/H.264+/H.264 encoding: efficient compression technology saves storage space and reduces bandwidth requirements
DarkFighter technology enables the capture of high quality color images in even the dimmest lighting environments
True WDR technology provides clear imaging even with strong back lighting

View Less

Available models:

DS-2XC6225G0-L(2.0mm)

DS-2XC6225G0-L(2.8mm)

DS-2XC6225G0-L(4.0mm)

DS-2XC6225G0-L

EOL

Specification
Resources
Accessories

Camera
Image Sensor1/2.8″ Progressive Scan CMOS
Max. Resolution1920 × 1080
Min. IlluminationColor: 0.001 Lux @ (F1.2, AGC ON), 0.003 Lux @ (F2.0, AGC ON) B/W: 0.0001 Lux @ (F1.2, AGC ON), 0.0003 Lux @ (F2.0, AGC ON)
Shutter Time1 s to 1/100,000 s
Day & NightElectronic

Lens
Lens TypeFixed focal lens, 2.0/2.8/4.0 mm
Focal Length & FOV2.0 mm @ F2.0, horizontal FOV 127.6°, vertical FOV 77°, diagonal FOV 151° 2.8 mm @ F1.6, horizontal FOV 103°, vertical FOV 58.5°, diagonal FOV 127° 4 mm @ F1.6, horizontal FOV 82°, vertical FOV 46°, diagonal FOV 103°
Lens MountM12
Aperture2.0 mm @ F2.0, 2.8 mm @ F1.6, 4 mm @ F1.6

Illuminator
Supplement Light TypeWhite Light
Supplement Light RangeUp to 10 m

Video
Main Stream50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240, 320 × 240)
Third Stream50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240, 320 × 240)
Video Compression Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
Video Bit Rate32 Kbps to 16 Mbps
H.264 TypeBaseline Profile/Main Profile/High Profile
H.265 TypeMain profile
Scalable Video Coding (SVC)H.264 encoding
Region of Interest (ROI)4 fixed regions for each stream
Target CroppingYes

Network
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
Simultaneous Live ViewUp to 20 channels
APIONVIF (PROFILE S, PROFILE G), ISAPI
User/HostUp to 32 users 3 levels: Administrator, Operator and User
Network StorageMicro SD/SDHC/SDXC card (128 G), local storage and NAS (NFS,SMB/CIFS), ANR
ClientiVMS-4200, iVMS-4500, iVMS-5200, Hik-connect
Web BrowserIE 8+, Chrome 31.0 - 44, Firefox 30.0 - 51, Safari 8.0+

Image SettingsRotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
Day/Night SwitchDay/Night
Wide Dynamic Range (WDR)120 dB
Image EnhancementBLC, HLC, 3D DNR, Defog, EIS
Picture OverlayLOGO picture can be overlaid on video with 128 × 128 24bit bmp format

Interface
Ethernet Interface1 RJ45 10 M/100 M Ethernet port
On-Board StorageBuilt-in micro SD/SDHC/SDXC slot, up to 128 GB *You are recommended to purchase memory card together with the product if needed. After ordering, the memory card will be installed to product during manufacturing.

Event
Basic Event Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart EventLine crossing detection, intrusion detection, region entrance detection, region exiting detection

General
Power36 V DC ± 20%, 0.6 A, max. 14.5 W, two-core terminal block, PoE: (802.3.at, class 3, 42.5V-57V), 0.45A to 0.3A, 17W
Dimension210 mm × 200 mm × 205 mm (8.3″ × 7.9″ × 8.1″)
Package Dimension700 mm × 530 mm × 340 mm (27.6″ × 20.9″ × 13.4″)
Weight11.83 kg (26.08 lb.)
With Package Weight15.285 kg (33.70 lb.)
Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
General FunctionAnti-flicker, three streams, heartbeat, password protection, privacy mask, watermark, IP address filter, mirror
Cable Length50 m (included)

Approval
ProtectionIP68

Camera

Image Sensor

1/2.8″ Progressive Scan CMOS

Max. Resolution

1920 × 1080

Min. Illumination

Color: 0.001 Lux @ (F1.2, AGC ON), 0.003 Lux @ (F2.0, AGC ON) B/W: 0.0001 Lux @ (F1.2, AGC ON), 0.0003 Lux @ (F2.0, AGC ON)

Shutter Time

1 s to 1/100,000 s

Day & Night

Electronic

Lens

Lens Type

Fixed focal lens, 2.0/2.8/4.0 mm

Focal Length & FOV

2.0 mm @ F2.0, horizontal FOV 127.6°, vertical FOV 77°, diagonal FOV 151° 2.8 mm @ F1.6, horizontal FOV 103°, vertical FOV 58.5°, diagonal FOV 127° 4 mm @ F1.6, horizontal FOV 82°, vertical FOV 46°, diagonal FOV 103°

Lens Mount

M12

Aperture

2.0 mm @ F2.0, 2.8 mm @ F1.6, 4 mm @ F1.6

Illuminator

Supplement Light Type

White Light

Supplement Light Range

Up to 10 m

Video

Main Stream

50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720)

Sub-Stream

50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240, 320 × 240)

Third Stream

Video Compression

Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264

Video Bit Rate

32 Kbps to 16 Mbps

H.264 Type

Baseline Profile/Main Profile/High Profile

H.265 Type

Main profile

Scalable Video Coding (SVC)

H.264 encoding

Region of Interest (ROI)

4 fixed regions for each stream

Target Cropping

Yes

Network

Protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour

Simultaneous Live View

Up to 20 channels

API

ONVIF (PROFILE S, PROFILE G), ISAPI

User/Host

Up to 32 users 3 levels: Administrator, Operator and User

Network Storage

Micro SD/SDHC/SDXC card (128 G), local storage and NAS (NFS,SMB/CIFS), ANR

Client

iVMS-4200, iVMS-4500, iVMS-5200, Hik-connect

Web Browser

IE 8+, Chrome 31.0 - 44, Firefox 30.0 - 51, Safari 8.0+


Image Settings

Rotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser

Day/Night Switch

Day/Night

Wide Dynamic Range (WDR)

120 dB

Image Enhancement

BLC, HLC, 3D DNR, Defog, EIS

Picture Overlay

LOGO picture can be overlaid on video with 128 × 128 24bit bmp format

Interface

Ethernet Interface

1 RJ45 10 M/100 M Ethernet port

On-Board Storage

Built-in micro SD/SDHC/SDXC slot, up to 128 GB *You are recommended to purchase memory card together with the product if needed. After ordering, the memory card will be installed to product during manufacturing.

Event

Basic Event

Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)

Smart Event

Line crossing detection, intrusion detection, region entrance detection, region exiting detection

General

Power

36 V DC ± 20%, 0.6 A, max. 14.5 W, two-core terminal block, PoE: (802.3.at, class 3, 42.5V-57V), 0.45A to 0.3A, 17W

Dimension

210 mm × 200 mm × 205 mm (8.3″ × 7.9″ × 8.1″)

Package Dimension

700 mm × 530 mm × 340 mm (27.6″ × 20.9″ × 13.4″)

Weight

11.83 kg (26.08 lb.)

With Package Weight

15.285 kg (33.70 lb.)

Startup and Operating Conditions

-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)

General Function

Anti-flicker, three streams, heartbeat, password protection, privacy mask, watermark, IP address filter, mirror

Cable Length

50 m (included)

Approval

Protection

IP68
