Pixel Configuration
Surface mounted trinity LED
Encapsulation Brand
Kinglight copper wire
Driver IC
MBI5153
Housing Included
Yes
Power Supply Brand
Megmeet
Control System
Hikvision-developed
Pixel Pitch
2.54 mm
Dimensions(W×H×D)
609.92×343.08×75 mm
Packing Dimensions(W×H×D)
796×484×192 mm
Resolusion
240×135
Pixel Density
154837 pitch/m²
Area
0.209 m²
Aspect Ratio
16：9
Material
Sealed die casting aluminum
Maintenance Method
Magnet front maintenace for lamp boards,and rear maintenance for power supply and receiving card
Max.Brightness
500 nits
Brightness Control
Manual/Automatic/Remote controller
Color Temperature
3000 to 10000 adjustable
Viewing Angle
Horizontal 160°，vertical 160°
Opitmal Viewing Distance
8 m
Center Distance Deviation of LED
＜3%
Brightness Uniformity
≥97%
Color Uniformity
≤±0.003Cx，Cy
Contrast
≥3000：1
Driver Mode
Constant current driving
Frame frequency
60 Hz
Refresh Rate
3840 Hz
Power Supply
100 to 240 VAC
Max.Consumption
≤850 W/m²
Average Consumption
＜280 W/m²
Operating Temperature
-10℃ to 40℃（14℉ to 104℉）
Storage Temperature
-20℃ to 60℃（-4℉ to 140℉）
Operating Humidity
10% to 80%(non-condensing)
Storage Humidity
10% to 85%(non-condensing)
Gross Weight
9.8 kg(21.6 lb including packaging)
Wet Weight
9.3 kg(20.5 lb)
