F/UTP outdoor Cat 6

  • Stable electrical performance, compliant with ANSI/TIA-568.2-D, IEC61156, ISO/IEC11801.
  • Compliant with RoHS 2.0.
  • Sheath with strong mechanical properties, and high tensile and compressive strength, reducing damage during the project.
  • Excellent performance in the Fluke 90-meter permanent link test while working continuously at 50°C high temperature.
  • Excellent performance in the Fluke 100-meter channel test while being continuously loaded with 57 V/1 A DC power (PoE).
  • Solid-Bare Copper conductor with less resistance, and better electrical properties and transmission performance.
View Less
View more
Data Sheet
Sales Inquiry

Available models:

DS-1LN6OPSPE
DS-1LN6OPSPE
HOT
Data Sheet

Especificación

  • General
  • CategoríaCat 6
  • EstructuraF/UTP
  • Fire ResistanceNone
  • Escenarios de aplicaciónOutdoor
  • Conduct
  • Conductor MaterialSolid-Bare Copper
  • Conductor Diameter0.565± 0.005 mm 23AWG
  • Insulation
  • Insulation Diameter1.12 ± 0.05 mm
  • Sheath
  • Sheath MaterialPE
  • Sheath ColorBlack
  • Estructura
  • Length305 ± 1.5 m
  • Rip CordYes
  • SeparatorYes
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Especificación

General
Categoría
Cat 6
Estructura
F/UTP
Fire Resistance
None
Escenarios de aplicación
Outdoor
Conduct
Conductor Material
Solid-Bare Copper
Conductor Diameter
0.565± 0.005 mm 23AWG
Insulation
Insulation Diameter
1.12 ± 0.05 mm
Sheath
Sheath Material
PE
Sheath Color
Black
Estructura
Length
305 ± 1.5 m
Rip Cord
Yes
Separator
Yes
For better user experience, we highly recommend you to update your device to the latest firmware asap.
Especificación
General
  • CategoríaCat 6
  • EstructuraF/UTP
  • Fire ResistanceNone
  • Escenarios de aplicaciónOutdoor
Conduct
  • Conductor MaterialSolid-Bare Copper
  • Conductor Diameter0.565± 0.005 mm 23AWG
Insulation
  • Insulation Diameter1.12 ± 0.05 mm
Sheath
  • Sheath MaterialPE
  • Sheath ColorBlack
Estructura
  • Length305 ± 1.5 m
  • Rip CordYes
  • SeparatorYes
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.
