DS-2CE70DF3T-PFS

2 MP ColorVu Indoor Audio Fixed Turret Camera

View Less

Available models:

DS-2CE70DF3T-PFS(2.8mm)

DS-2CE70DF3T-PFS(3.6mm)

Lens
Lens Type2.8 mm, 3.6 mm fixed focal lens
Focal Length & FOV2.8 mm, horizontal FOV: 98°, vertical FOV: 52°, diagonal FOV: 116° 3.6 mm, horizontal FOV: 77°, vertical FOV: 42°, diagonal FOV: 91°
Lens MountM12

Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
Image SettingsBrightness, Contrast, Mirror, Defective Pixel Correction, Sharpness, Anti-Banding, AGC
Frame RateTVI: 1080P@25 fps/30 fps CVI: 1080P@25 fps/30 fps AHD: 1080P@25 fps/30 fps CVBS: PAL/NTSC
Day/Night ModeColor
Wide Dynamic Range (WDR)≥130 dB
Image EnhancementBLC, HLC, Global, HLS
Privacy Mask4 programmable privacy masks
Noise Reduction3D DNR/2D DNR
White BalanceAuto/Manual

General
Power12 VDC ± 25%, max. 4.2 W *You are recommended to use one power adapter to supply the power for one camera.
MaterialPlastic
Dimension85.02 mm × 81.25 mm (3.35" × 3.2")
WeightApprox. 163 g (0.36 lb.)
Operating Condition-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
CommunicationHIKVISION-C
LanguageEnglish

Camera

Image Sensor

2 MP CMOS

Max. Resolution

1920 (H) × 1080 (V)
