DS-2CE12DF8T-FSLN

2 MP ColorVu Audio Fixed Bullet Camera

High quality imaging with 2 MP, 1920 × 1080 resolution
24/7 color imaging with F1.0 aperture
Clear imaging against strong back light due to 130 dB true WDR technology
3D DNR technology delivers clean and sharp images
2.8 mm, 3.6 mm, 6 mm fixed focal lens
Up to 40 m white light distance for bright night imaging
High quality audio with audio over coaxial cable, built-in mic
One port for four switchable signals (TVI/AHD/CVI/CVBS)
Water and dust resistant (IP67)

View Less

2 MP ColorVu Audio Fixed Bullet Camera

High quality imaging with 2 MP, 1920 × 1080 resolution
24/7 color imaging with F1.0 aperture
Clear imaging against strong back light due to 130 dB true WDR technology
3D DNR technology delivers clean and sharp images
2.8 mm, 3.6 mm, 6 mm fixed focal lens
Up to 40 m white light distance for bright night imaging
High quality audio with audio over coaxial cable, built-in mic
One port for four switchable signals (TVI/AHD/CVI/CVBS)
Water and dust resistant (IP67)

View Less

Available models:

DS-2CE12DF8T-FSLN(2.8mm)

DS-2CE12DF8T-FSLN(3.6mm)

Camera
Image Sensor2 MP CMOS
Max. Resolution1920 (H) × 1080 (V)
Min. Illumination0.0003 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Day & Night24/7 Color Imaging
Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
Signal SystemPAL/NTSC
Slow ShutterMax. 16 times
Light AlarmSolid Light Alarm (White Light)

Lens
Lens Type2.8 mm, 3.6 mm, 6 mm fixed focal lens
Focal Length & FOV2.8 mm, horizontal FOV: 106°, vertical FOV: 56°, diagonal FOV: 129° 3.6 mm, horizontal FOV: 83°, vertical FOV: 44°, diagonal FOV: 100° 6 mm, horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 64°
Lens MountM12

Illuminator
Supplement Light RangeUp to 40 m
Smart Supplement LightYes
Supplement Light TypeWhite Light

Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
Image SettingsBrightness, Contrast, Mirror, Sharpness, Anti-Banding, AGC
Frame RateTVI: 1080p @ 25 fps/30 fps CVI: 1080p @ 25 fps/30 fps AHD: 1080p @ 25 fps/30 fps CVBS: PAL/NTSC
Day/Night ModeColor
Wide Dynamic Range (WDR)≥130 dB
Image EnhancementBLC, HLC, Global, HLS
Privacy Mask4 programmable privacy masks
Noise Reduction3D DNR/2D DNR
White BalanceAuto

Interface
Video OutputSwitchable TVI/AHD/CVI/CVBS
AudioLine-in
Built-in MicrophoneYes

Event
Motion Detection4 programmable motion areas

General
Power12 VDC ± 25%, max. 6.3 W *You are recommended to use one power adapter to supply the power for one camera.
MaterialMetal
Dimension194.2 mm × 78 mm × 74.5 mm (7.65" × 3.07" × 2.93")
WeightApprox. 527 g (1.16 lb.)
Operating Condition-40°C to 50°C (-40°F to 122°F), Humidity: 90% or less (non-condensing)
CommunicationHIKVISION-C
言語English

Approval
ProtectionIP67

Specification

Camera

Image Sensor

2 MP CMOS

Max. Resolution

1920 (H) × 1080 (V)

Min. Illumination

0.0003 Lux @ (F1.0, AGC ON), 0 Lux with white light

Shutter Time

PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s

Day & Night

24/7 Color Imaging

Angle Adjustment

Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°

Signal System

PAL/NTSC

Slow Shutter

Max. 16 times

Light Alarm

Solid Light Alarm (White Light)

Lens

Lens Type

2.8 mm, 3.6 mm, 6 mm fixed focal lens

Focal Length & FOV

2.8 mm, horizontal FOV: 106°, vertical FOV: 56°, diagonal FOV: 129° 3.6 mm, horizontal FOV: 83°, vertical FOV: 44°, diagonal FOV: 100° 6 mm, horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 64°

Lens Mount

M12

Illuminator

Supplement Light Range

Up to 40 m

Smart Supplement Light

Yes

Supplement Light Type

White Light


Image Parameters Switch

STD/HIGH-SAT/HIGHLIGHT

Image Settings

Brightness, Contrast, Mirror, Sharpness, Anti-Banding, AGC

Frame Rate

TVI: 1080p @ 25 fps/30 fps CVI: 1080p @ 25 fps/30 fps AHD: 1080p @ 25 fps/30 fps CVBS: PAL/NTSC

Day/Night Mode

Color

Wide Dynamic Range (WDR)

≥130 dB

Image Enhancement

BLC, HLC, Global, HLS

Privacy Mask

4 programmable privacy masks

Noise Reduction

3D DNR/2D DNR

White Balance

Auto

Interface

Video Output

Switchable TVI/AHD/CVI/CVBS

Audio

Line-in

Built-in Microphone

Yes

Event

Motion Detection

4 programmable motion areas

General

Power

12 VDC ± 25%, max. 6.3 W *You are recommended to use one power adapter to supply the power for one camera.

Material

Metal

Dimension

194.2 mm × 78 mm × 74.5 mm (7.65" × 3.07" × 2.93")

Weight

Approx. 527 g (1.16 lb.)

Operating Condition

-40°C to 50°C (-40°F to 122°F), Humidity: 90% or less (non-condensing)

Communication

HIKVISION-C

言語

English

Approval

Protection

IP67
