Wide input voltage range
Built-in AVR
Super fast charging
Overload and short circuit protection
LCD display
Compact design
USB port for remote control

View Less

Data Sheet

Available models:

DS-UPS2000

Specification
Resources
Accessories

Data Sheet

Power
UPS Capacity 2000 VA / 1200 W

Input
Input Voltage Range 140 VAC to 290 VAC
Input Frequency50/60 Hz

Output
Output Voltage Range210 VAC to 235 VAC
Output Frequency50 Hz ± 0.5 Hz
Transfer Time≤ 10 ms
WaveformPWM

Battery
Battery Type12 V/9 Ah,2pcs
Recharge Time6-8 hours recover to 90% capacity

Interface
Communicate PortsUSB

Protection
Full ProtectionSurge protection,Overload protection,Overcharge protection

Indicator
DisplayLCD Screen Input Voltage, Output Voltage, Battery capacity, load level
AlarmCharging Mode (DC mode): Sounding every 8 seconds Low Battery: Sounding every second Overloading Mode: Sounding every 0.5 seconds Fault: Continuously sounding

General
Operating Temperature0 °C to 40 °C (32 °F to 104 °F）
Operating Humidity30% to 90% (non-condensing)
Dimension345 mm × 122 mm × 192 mm (13.58" × 4.80" × 7.56")
WeightApprox. 11 kg (24.3 lb)

Power

UPS Capacity

2000 VA / 1200 W

Input

Input Voltage Range

140 VAC to 290 VAC

Input Frequency

50/60 Hz

Output

Output Voltage Range

210 VAC to 235 VAC

Output Frequency

50 Hz ± 0.5 Hz

Transfer Time

≤ 10 ms

Waveform

PWM

Battery

Battery Type

12 V/9 Ah,2pcs

Recharge Time

6-8 hours recover to 90% capacity

Interface

Communicate Ports

USB

Protection

Full Protection

Surge protection,Overload protection,Overcharge protection

Indicator

Display

LCD Screen Input Voltage, Output Voltage, Battery capacity, load level

Alarm

Charging Mode (DC mode): Sounding every 8 seconds Low Battery: Sounding every second Overloading Mode: Sounding every 0.5 seconds Fault: Continuously sounding

General

Operating Temperature

0 °C to 40 °C (32 °F to 104 °F）

Operating Humidity

30% to 90% (non-condensing)

Dimension

345 mm × 122 mm × 192 mm (13.58" × 4.80" × 7.56")

Weight

Approx. 11 kg (24.3 lb)
