IP Video Intercom Kit

  • Network video intercom kit for villa
  • One-press call button for easier calls
  • Convenient Hik-Connect APP mobile control
  • Device included: DS-KV6113-PE1(C) × 1, DS-KH6110-WE1 × 1, DS-KABV6113-RS × 1, PSU × 2
  • Power adapter included in the package

View Less
Veja mais
Data Sheet
Sales Inquiry

Modelos disponíveis:

DS-KIS606-P
Veja mais View Less
DS-KIS606-P
Data Sheet

Especificação

  • Door station/System parameters
  • Operation systemLinux
  • ProcessadorEmbeded high performance processor
  • RAM256 MB
  • ROM32 MB
  • Door station/Video parameters
  • Iluminação adicionalIR light, up to 3 m
  • ResoluçãoMain stream: 1920 × 1080p,1280 X 720p Sub stream: 1280 X 720p,640 x 480p
  • Lentes2MP HD camera
  • Campo de visãoHorizontal: 131°, Vertical: 78°
  • Padrão de compressão de vídeoH.264; H.265; MJPEG
  • Door station/Audio parameters
  • Audio input1 built-in omnidirectional microphone
  • Audio output1 built-in loudspeaker
  • Qualidade de áudioNoise suppression and echo cancellation
  • Ajuste de volumeAdjustable
  • Audio compression standardG711U、G711A、G726、AAC_LC、AAC_LD、OPUS、G722.1
  • Taxa de compressão de áudio64 Kbps
  • Door station/Capacity parameters
  • User capacity2000
  • Linked indoor station capacity16
  • Capacidade do cartão10000
  • Parâmetros de estação externa/rede
  • Network protocolTCP/IP, RTSP, IPV6,ONVIF
  • Door station/Device interfaces
  • Network interface1 RJ-45, 10/100 Mbps self-adaptive
  • RS-485 1
  • Entrada de alarme 4
  • Lock control1 relay, Max. 30 VDC 2 A
  • Botão Sair1
  • Entrada de contato da porta1
  • TAMPER1
  • Door station/General
  • Botão1 physical button(s)
  • Power consumption＜ 10 W
  • Working temperature-40 °C to 55 °C(-40 °F to 131 °F)
  • Working humidity10% to 95% (no-condensing)
  • Dimensões138 mm × 65 mm × 27 mm (5.4" × 2.6" × 1.1")
  • InstalaçãoSurface mounting
  • Nível de proteção IP65
  • Indicador2
  • Ambiente de aplicaçãoOutdoor
  • Fonte de alimentaçãoIEEE802.3af, standard PoE 12 VDC
  • PesoNet weight: 0.190 kg； Gross weight: 0.414 kg
  • Indoor station/System parameters
  • Operation systemEmbedded Linux operation system
  • RAM128 MB
  • ROM16 MB
  • ProcessadorEmbedded processor
  • Indoor station/Display parameters
  • Display resolution480 × 272
  • Método de operaçãoCapacitive touch screen with 9 touch buttons
  • Screen size4.3-inch colorful TFT screen
  • TipoColorful TFT screen
  • Indoor station/Video parameter
  • Padrão de compactação de vídeo/
  • Resolução/
  • Lentes/
  • Wide dynamic range (WDR)/
  • FOV (campo de visão)/
  • Indoor station/Audio parameters
  • Audio inputBuilt-in omnidirectional microphone
  • Audio outputBuilt-in loudspeaker
  • Qualidade de áudioNoise suppression and echo cancellation
  • Audio compression standardG.711 U, G.711 A
  • Taxa de bits de compressão de áudio64 Kps
  • Ajuste de volumeAdjustable
  • Indoor station/Capacity parameters
  • Notice capacity200
  • Linked indoor extensions capacity16
  • Parâmetros de estação interna/rede
  • Network protocolTCP/IP, SIP, RTSP
  • Wi-FiWi-Fi 802.11 b/g/n, 2.4 GHz
  • Indoor station/Device interfaces
  • Network interface1 RJ-45 10/100 Mbps self-adaptive
  • Indoor station/General
  • Botão9 physical button
  • Power consumption≤ 4 W
  • Fonte de alimentaçãoIEEE802.3af, Standard PoE,12 VDC
  • Working temperature-10 °C to 50 °C (14 °F to 122 °F)
  • Working humidity10% to 95% (no-condensing)
  • Dimensões (P x L x A)200 mm × 140 mm × 15.1 mm (7.9" × 5.5" × 0.6")
  • Pressão do ar em funcionamento120 mm × 120 mm × 21 mm (4.7" × 4.7" × 0.83")
  • InstalaçãoWall mounting, table mounting
  • Ambiente de aplicaçãoIndoor
  • Nível de proteção/
  • PesoWith package: 336.6 g Without package: 197.8 g
  • IdiomaEnglish, French, Portuguese, Portuguese (Brazil), Spanish, Russian, German, Italian, Polish, Turkish, Vietnamese, Arabic, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian Danish, Slovenian, Slovak, Swedish, Finnish, Traditional Chinese, Mongolian, Hebrew, Kazakh, Uzbek

Especificação

Door station/System parameters
Operation system
Linux
Processador
Embeded high performance processor
RAM
256 MB
ROM
32 MB
Door station/Video parameters
Iluminação adicional
IR light, up to 3 m
Resolução
Main stream: 1920 × 1080p,1280 X 720p Sub stream: 1280 X 720p,640 x 480p
Lentes
2MP HD camera
Campo de visão
Horizontal: 131°, Vertical: 78°
Padrão de compressão de vídeo
H.264; H.265; MJPEG
Door station/Audio parameters
Audio input
1 built-in omnidirectional microphone
Audio output
1 built-in loudspeaker
Qualidade de áudio
Noise suppression and echo cancellation
Ajuste de volume
Adjustable
Audio compression standard
G711U、G711A、G726、AAC_LC、AAC_LD、OPUS、G722.1
Taxa de compressão de áudio
64 Kbps
Door station/Capacity parameters
User capacity
2000
Linked indoor station capacity
16
Capacidade do cartão
10000
Parâmetros de estação externa/rede
Network protocol
TCP/IP, RTSP, IPV6,ONVIF
Door station/Device interfaces
Network interface
1 RJ-45, 10/100 Mbps self-adaptive
RS-485
1
Entrada de alarme
4
Lock control
1 relay, Max. 30 VDC 2 A
Botão Sair
1
Entrada de contato da porta
1
TAMPER
1
Door station/General
Botão
1 physical button(s)
Power consumption
＜ 10 W
Working temperature
-40 °C to 55 °C(-40 °F to 131 °F)
Working humidity
10% to 95% (no-condensing)
Dimensões
138 mm × 65 mm × 27 mm (5.4" × 2.6" × 1.1")
Instalação
Surface mounting
Nível de proteção
IP65
Indicador
2
Ambiente de aplicação
Outdoor
Fonte de alimentação
IEEE802.3af, standard PoE 12 VDC
Peso
Net weight: 0.190 kg； Gross weight: 0.414 kg
Indoor station/System parameters
Operation system
Embedded Linux operation system
RAM
128 MB
ROM
16 MB
Processador
Embedded processor
Indoor station/Display parameters
Display resolution
480 × 272
Método de operação
Capacitive touch screen with 9 touch buttons
Screen size
4.3-inch colorful TFT screen
Tipo
Colorful TFT screen
Indoor station/Video parameter
Padrão de compactação de vídeo
/
Resolução
/
Lentes
/
Wide dynamic range (WDR)
/
FOV (campo de visão)
/
Indoor station/Audio parameters
Audio input
Built-in omnidirectional microphone
Audio output
Built-in loudspeaker
Qualidade de áudio
Noise suppression and echo cancellation
Audio compression standard
G.711 U, G.711 A
Taxa de bits de compressão de áudio
64 Kps
Ajuste de volume
Adjustable
Indoor station/Capacity parameters
Notice capacity
200
Linked indoor extensions capacity
16
Parâmetros de estação interna/rede
Network protocol
TCP/IP, SIP, RTSP
Wi-Fi
Wi-Fi 802.11 b/g/n, 2.4 GHz
Indoor station/Device interfaces
Network interface
1 RJ-45 10/100 Mbps self-adaptive
Indoor station/General
Botão
9 physical button
Power consumption
≤ 4 W
Fonte de alimentação
IEEE802.3af, Standard PoE,12 VDC
Working temperature
-10 °C to 50 °C (14 °F to 122 °F)
Working humidity
10% to 95% (no-condensing)
Dimensões (P x L x A)
200 mm × 140 mm × 15.1 mm (7.9" × 5.5" × 0.6")
Pressão do ar em funcionamento
120 mm × 120 mm × 21 mm (4.7" × 4.7" × 0.83")
Instalação
Wall mounting, table mounting
Ambiente de aplicação
Indoor
Nível de proteção
/
Peso
With package: 336.6 g Without package: 197.8 g
Idioma
English, French, Portuguese, Portuguese (Brazil), Spanish, Russian, German, Italian, Polish, Turkish, Vietnamese, Arabic, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian Danish, Slovenian, Slovak, Swedish, Finnish, Traditional Chinese, Mongolian, Hebrew, Kazakh, Uzbek
