2-wire HD KIT

  • Great image quality of 2 MP resolution
  • One-press to call, remote unlocking with App control
  • Real plug&play
  • IP65 water resistant and IK08 vandal resistant entry panel
  • 7-inch touch screen indoor monitor, user friendly interface
View Less
View more
Data Sheet
Sales Inquiry

Available models:

DS-KIS704EY/Aluminum
DS-KIS704EY/Aluminum
Data Sheet

Specifikace

  • Dveřní stanice/Parametry systému
  • ProcesorEmbedded Processor
  • ROM4 GB
  • RAM256 MB
  • Operační systémEmbedded Linux operation system
  • Door station/Screen parameters
  • Screen sizeNA
  • ŘešeníNA
  • TypNA
  • Provozní metodaNA
  • Dveřní stanice/Parametry videa
  • Supplement lightSupplement light Low illumination, IR supplement lights
  • Řešení2MP
  • Objektiv1
  • Wide dynamic range (WDR)Support
  • FOVHorizontal: 133°, Vertical: 82°
  • Standard komprese videaH.264
  • Dveřní stanice/Parametry zvuku
  • Audio inputBuilt-in omnidirectional microphone
  • Audio outputBuilt-in loudspeaker
  • Nastavení hlasitostiAdjustable
  • Standard komprese zvukuG.711 U, G.711 A
  • Přenosová rychlost komprese zvuku64 Kps
  • Kvalita zvukuNoise suppression and echo cancellation
  • Door station/Capacity parameters
  • Linked indoor station capacityMax.99
  • Sub door station capacity16
  • Dveřní stanice/Síťové parametry
  • Wireless network10/100 Mbps self-adaptive through 2-wire interface
  • Wi-FiOnly AP mode for configuration
  • Dveřní stanice/Rozhraní zařízení
  • RS-4852 (RS485 out for Hikvision's sub module communication, RS485 for reservation)
  • Lock control2 (1 relay, max to 30 VDC, 2 A；1 DC pulse，20V 4A impulsive，300 mA holding current，30 ohm max )
  • Tlačítko Konec1
  • Vstup dveřního kontaktu1
  • Alarm input2（supports Exit button or Door contact input）
  • Power supply input12VDC input
  • TAMPER1
  • Ladění portu1
  • Two-Wire1
  • DIP Switch6 decimal DIP switch
  • Dveřní stanice/Obecné
  • Tlačítko0-2（Flexible adjustment）
  • Indikátor4 LED lights(Opening door、Calling、Intercom、In use）
  • Power supply48V，Powered by distributor DS-KAD7060EY or 12VDC
  • Power consumption≤ 6 W
  • Working temperature-40° C to 60° C (-22° F to 140° F)
  • Working humidity10% to 90%
  • Prostředí aplikaceOutdoor
  • Rozměry (Š × V × H)99.5 mm × 98.5 mm × 35 mm (3.92" × 3.88" × 1.37")
  • InstalaceSurface mounting & flush mounting
  • Ochranná úroveňIP65 IK08
  • JazykEnglish, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch , Spanish, Romanian, Estonian, Croatian, Slovenian, Serbian, Ukrainian, Portuguese
  • Video Audio Distributor/Rozhraní
  • Power interface48VDC
  • Dvouvodičové rozhraní6("IN""OUT" for casacading, CH1-CH4 for Door station and Indoor station)
  • Distributor zvuku a videa/Obecné
  • Power supply48VDC
  • Power consumptionCH1＜30W，CH2＜30W，CH3＜30W，CH4＜30W；MAX Total 30W
  • Working temperature-10 °C to 5 °C (14 °F to 131 °F)
  • Working humidity10% to 90% (no-condensing)
  • Rozměry (Š × V × H)143.7 mm × 92.4 mm × 65.9 mm (5.66" × 3.64" × 2.59")
  • InstalaceDIN rail installation
  • Indicators6 Signal indicators; 1 Power indicator
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specifikace

Dveřní stanice/Parametry systému
Procesor
Embedded Processor
ROM
4 GB
RAM
256 MB
Operační systém
Embedded Linux operation system
Door station/Screen parameters
Screen size
NA
Řešení
NA
Typ
NA
Provozní metoda
NA
Dveřní stanice/Parametry videa
Supplement light
Supplement light Low illumination, IR supplement lights
Řešení
2MP
Objektiv
1
Wide dynamic range (WDR)
Support
FOV
Horizontal: 133°, Vertical: 82°
Standard komprese videa
H.264
Dveřní stanice/Parametry zvuku
Audio input
Built-in omnidirectional microphone
Audio output
Built-in loudspeaker
Nastavení hlasitosti
Adjustable
Standard komprese zvuku
G.711 U, G.711 A
Přenosová rychlost komprese zvuku
64 Kps
Kvalita zvuku
Noise suppression and echo cancellation
Door station/Capacity parameters
Linked indoor station capacity
Max.99
Sub door station capacity
16
Dveřní stanice/Síťové parametry
Wireless network
10/100 Mbps self-adaptive through 2-wire interface
Wi-Fi
Only AP mode for configuration
Dveřní stanice/Rozhraní zařízení
RS-485
2 (RS485 out for Hikvision's sub module communication, RS485 for reservation)
Lock control
2 (1 relay, max to 30 VDC, 2 A；1 DC pulse，20V 4A impulsive，300 mA holding current，30 ohm max )
Tlačítko Konec
1
Vstup dveřního kontaktu
1
Alarm input
2（supports Exit button or Door contact input）
Power supply input
12VDC input
TAMPER
1
Ladění portu
1
Two-Wire
1
DIP Switch
6 decimal DIP switch
Dveřní stanice/Obecné
Tlačítko
0-2（Flexible adjustment）
Indikátor
4 LED lights(Opening door、Calling、Intercom、In use）
Power supply
48V，Powered by distributor DS-KAD7060EY or 12VDC
Power consumption
≤ 6 W
Working temperature
-40° C to 60° C (-22° F to 140° F)
Working humidity
10% to 90%
Prostředí aplikace
Outdoor
Rozměry (Š × V × H)
99.5 mm × 98.5 mm × 35 mm (3.92" × 3.88" × 1.37")
Instalace
Surface mounting & flush mounting
Ochranná úroveň
IP65 IK08
Jazyk
English, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch , Spanish, Romanian, Estonian, Croatian, Slovenian, Serbian, Ukrainian, Portuguese
Video Audio Distributor/Rozhraní
Power interface
48VDC
Dvouvodičové rozhraní
6("IN""OUT" for casacading, CH1-CH4 for Door station and Indoor station)
Distributor zvuku a videa/Obecné
Power supply
48VDC
Power consumption
CH1＜30W，CH2＜30W，CH3＜30W，CH4＜30W；MAX Total 30W
Working temperature
-10 °C to 5 °C (14 °F to 131 °F)
Working humidity
10% to 90% (no-condensing)
Rozměry (Š × V × H)
143.7 mm × 92.4 mm × 65.9 mm (5.66" × 3.64" × 2.59")
Instalace
DIN rail installation
Indicators
6 Signal indicators; 1 Power indicator
For better user experience, we highly recommend you to update your device to the latest firmware asap.
Specifikace
Dveřní stanice/Parametry systému
  • ProcesorEmbedded Processor
  • ROM4 GB
  • RAM256 MB
  • Operační systémEmbedded Linux operation system
Door station/Screen parameters
  • Screen sizeNA
  • ŘešeníNA
  • TypNA
  • Provozní metodaNA
Dveřní stanice/Parametry videa
  • Supplement lightSupplement light Low illumination, IR supplement lights
  • Řešení2MP
  • Objektiv1
  • Wide dynamic range (WDR)Support
  • FOVHorizontal: 133°, Vertical: 82°
  • Standard komprese videaH.264
Dveřní stanice/Parametry zvuku
  • Audio inputBuilt-in omnidirectional microphone
  • Audio outputBuilt-in loudspeaker
  • Nastavení hlasitostiAdjustable
  • Standard komprese zvukuG.711 U, G.711 A
  • Přenosová rychlost komprese zvuku64 Kps
  • Kvalita zvukuNoise suppression and echo cancellation
Door station/Capacity parameters
  • Linked indoor station capacityMax.99
  • Sub door station capacity16
Dveřní stanice/Síťové parametry
  • Wireless network10/100 Mbps self-adaptive through 2-wire interface
  • Wi-FiOnly AP mode for configuration
Dveřní stanice/Rozhraní zařízení
  • RS-4852 (RS485 out for Hikvision's sub module communication, RS485 for reservation)
  • Lock control2 (1 relay, max to 30 VDC, 2 A；1 DC pulse，20V 4A impulsive，300 mA holding current，30 ohm max )
  • Tlačítko Konec1
  • Vstup dveřního kontaktu1
  • Alarm input2（supports Exit button or Door contact input）
  • Power supply input12VDC input
  • TAMPER1
  • Ladění portu1
  • Two-Wire1
  • DIP Switch6 decimal DIP switch
Dveřní stanice/Obecné
  • Tlačítko0-2（Flexible adjustment）
  • Indikátor4 LED lights(Opening door、Calling、Intercom、In use）
  • Power supply48V，Powered by distributor DS-KAD7060EY or 12VDC
  • Power consumption≤ 6 W
  • Working temperature-40° C to 60° C (-22° F to 140° F)
  • Working humidity10% to 90%
  • Prostředí aplikaceOutdoor
  • Rozměry (Š × V × H)99.5 mm × 98.5 mm × 35 mm (3.92" × 3.88" × 1.37")
  • InstalaceSurface mounting & flush mounting
  • Ochranná úroveňIP65 IK08
  • JazykEnglish, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch , Spanish, Romanian, Estonian, Croatian, Slovenian, Serbian, Ukrainian, Portuguese
Video Audio Distributor/Rozhraní
  • Power interface48VDC
  • Dvouvodičové rozhraní6("IN""OUT" for casacading, CH1-CH4 for Door station and Indoor station)
Distributor zvuku a videa/Obecné
  • Power supply48VDC
  • Power consumptionCH1＜30W，CH2＜30W，CH3＜30W，CH4＜30W；MAX Total 30W
  • Working temperature-10 °C to 5 °C (14 °F to 131 °F)
  • Working humidity10% to 90% (no-condensing)
  • Rozměry (Š × V × H)143.7 mm × 92.4 mm × 65.9 mm (5.66" × 3.64" × 2.59")
  • InstalaceDIN rail installation
  • Indicators6 Signal indicators; 1 Power indicator
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Resources

Firmware

For better user experience, we highly recommend you to update your device to the latest firmware asap.

Firmware

For better user experience, we highly recommend you to update your device to the latest firmware asap.
Firmware_V1.0.6_241107
Firmware_V2.2.56_250306
2-Wire HD KH7100 Indoor Station Release Note_V2.2.48_build241101
