Solar-powered Thermal Camera Kit

  • 256 × 192 resolution, 12 μm, VOx UFPA, NETD < 40 mK (25°C, F1.0)
  • Video content analysis: vehicle/human classification
  • 80 W photovoltaic panel, 30 Ah chargeable lithium battery(The battery should be ordered separately.)
  • Temperature exception alarm for fire prevention, -20°C to 150°C (-4°F to 302°F), ± 8°C (± 14.4°F)
  • LTE-TDD/LTE-FDD/WCDMA 4G wireless network transmission, support Micro SIM card
  • Water and dust resistant (IP67)
  • Embedded audible alert and strobe light
  • High quality detector with 10 years guarantee

View Less
View more
Data Sheet
Sales Inquiry
DS-2TXS2628-10P/QA/GLT/CH30S80(LA)
Data Sheet

Specifikace

  • Tepelný modul
  • Senzor obrazuVanadium Oxide Uncooled Focal Plane Arrays
  • Řešení256 x 192
  • Pixel Pitch12 μm
  • Spectral Range8 μm to 14 μm
  • NETD ≤ 40 mK (@25° C,F# = 1.0)
  • Ohnisková vzdálenost9.7 mm
  • IFOV1.24 mrad
  • Clona F1.0
  • Zorné pole18.0° × 13.5° (H × V)
  • Min. Zaostřovací vzdálenost1.5 m
  • Digitální Zoom×2, ×4
  • Optický modul
  • Senzor obrazu1/2.7" Progressive Scan CMOS
  • Řešení2688 × 1520
  • Min. osvětlení0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR
  • Zorné pole 39.4°(H) x22.1°(V)
  • Ohnisková vzdálenost8 mm
  • ClonaF 1.6
  • Rychlost závěrky1 s to 1/100,000 s
  • Vyvážení bíléMWB/AWB1/Locked WB/Fluorescent Lamp/Incandescent Lamp/Warm Light Lamp/Natural Light
  • Denní a noční režim IR Cut Filter with Auto Switch
  • WDR120 dB
  • Image Effect
  • Bi-spektrální obrazová fúze Display the details of optical channel on thermal channel
  • Target Coloration Yes. Supported in white hot and black hot mode
  • Iluminátor
  • IR vzdálenost Up to 30 m
  • IR intenzita a úhel Automatically adjusted
  • Audible and Visual Alarm
  • Dosah bílého světla Up to 30 m
  • Vizuální alarmYes. White light alarm with adjustable flashing frequencies
  • Audio alarm Yes, for three types of audible alarm (VCA and Temperature Exception) 3 preset voice alerts (one for each) 6 importable user-defined voice alerts (6 options shared in the two types)
  • Inteligentní funkce
  • VCA 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
  • Měření teploty3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
  • Teplotní rozsah-20°C to 150°C (-4°F to 302°F)
  • Přesnost teploty ± 8°C (± 14.4°F)
  • Video and Audio
  • Hlavní proud Thermal: 25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
  • Sub-stream Thermal: 25 fps (704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 480, 352 × 240)
  • Video komprese Main Stream: H.265/H.264 Sub-Stream: H.265/H.264/MJPEG
  • Audio kompreseG.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
  • Síť
  • Protokoly IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP
  • Síťové úložištěMicroSD/SDHC/SDXC card (32G inside) (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
  • API ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G)
  • Současný živý náhledUp to 20 channels
  • Úroveň uživatele/hostiteleUp to 32 users, 3 levels: Administrator, Operator, User
  • Bezpečnost User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
  • Klient iVMS-4200, Hik-Connect
  • Mobile Communication
  • SIM Card TypeMicroSIM
  • FrekvenceLTE FDD: B1/2/3/4/5/7/8/12/17/28/66 LTE TDD: B38/40 WCDMA: B1/2/3/4/5/8 GSM/GPRS/EDGE: 850/900/1800MHz
  • StandardLTE FDD/LTE TDD/WCDMA/GSM/GPRS/EDGE
  • Rozhraní
  • Vstup alarmu2, alarm input (0-5 VDC)
  • Výstup alarmu 2, alarm output (alarm response actions configurable)
  • Akce alarmuLinkage Method Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output, Email
  • Zvukový vstup1, 3.5 mm Mic in/Line in interface Line input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10%
  • Audio výstupLinear level, impedance: 600 Ω
  • Komunikační rozhraní 1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface (half duplex)
  • Všeobecné
  • Menu Language32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
  • Zdroj napájení 12 VDC ± 25%, φ 5.5 mm coaxial power plug PoE (802.3af, class 3)
  • Spotřeba energieThermal only mode power consumption: 2.73W The average power consumption of 24 hours: 2.97W The max. power consumption: 7.1W (IR light on)
  • Working Temperature/HumidityTemperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Úroveň ochranyIP67 Standard ,IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection
  • Dimensions 208.9 mm × 106 mm × 105.2 mm (8.22" × 4.17" × 4.14")
  • Adjustment RangeBullet camera: Tilt: -10 ° to +45°, Pan: -180 ° to +180° Photovoltaic panel: Tilt: 10 ° or 30°
  • Váha26.6kg(58.64lb)
  • Připevnění Pole Mount
  • S váhou balení27.79kg(61.26lb)
  • Podmínky skladování Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Spuštění a provozní podmínky Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Baterie
  • Typ baterieLithium *The battery should be ordered separately.
  • Napeti baterky10.8 V
  • Kapacita baterie30 Ah
  • Provozní teplotaCharging: -20 °C to 45 °C (-4 °F to 113 °F) Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
  • Životnost baterieMore than 500 cycles
  • Battery WeightApprox. 3.3 kg (7.3 lb.)
  • Rozšířené rozměry236 × 154 × 80 mm (9.3 " × 6.1 " × 3.2 ")
  • Max. Output Voltage12.6 V
  • Schválení
  • EMC FCC SDOC：47 CFR Part 15，Subpart B
  • RFFCC-ID
  • OchranaCamera: IP67 (IEC 60529-2013),IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection Wind resistance 12 level
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specifikace

Tepelný modul
Senzor obrazu
Vanadium Oxide Uncooled Focal Plane Arrays
Řešení
256 x 192
Pixel Pitch
12 μm
Spectral Range
8 μm to 14 μm
NETD
≤ 40 mK (@25° C,F# = 1.0)
Ohnisková vzdálenost
9.7 mm
IFOV
1.24 mrad
Clona
F1.0
Zorné pole
18.0° × 13.5° (H × V)
Min. Zaostřovací vzdálenost
1.5 m
Digitální Zoom
×2, ×4
Optický modul
Senzor obrazu
1/2.7" Progressive Scan CMOS
Řešení
2688 × 1520
Min. osvětlení
0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR
Zorné pole
39.4°(H) x22.1°(V)
Ohnisková vzdálenost
8 mm
Clona
F 1.6
Rychlost závěrky
1 s to 1/100,000 s
Vyvážení bílé
MWB/AWB1/Locked WB/Fluorescent Lamp/Incandescent Lamp/Warm Light Lamp/Natural Light
Denní a noční režim
IR Cut Filter with Auto Switch
WDR
120 dB
Image Effect
Bi-spektrální obrazová fúze
Display the details of optical channel on thermal channel
Target Coloration
Yes. Supported in white hot and black hot mode
Iluminátor
IR vzdálenost
Up to 30 m
IR intenzita a úhel
Automatically adjusted
Audible and Visual Alarm
Dosah bílého světla
Up to 30 m
Vizuální alarm
Yes. White light alarm with adjustable flashing frequencies
Audio alarm
Yes, for three types of audible alarm (VCA and Temperature Exception) 3 preset voice alerts (one for each) 6 importable user-defined voice alerts (6 options shared in the two types)
Inteligentní funkce
VCA
4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
Měření teploty
3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
Teplotní rozsah
-20°C to 150°C (-4°F to 302°F)
Přesnost teploty
± 8°C (± 14.4°F)
Video and Audio
Hlavní proud
Thermal: 25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-stream
Thermal: 25 fps (704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 480, 352 × 240)
Video komprese
Main Stream: H.265/H.264 Sub-Stream: H.265/H.264/MJPEG
Audio komprese
G.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
Síť
Protokoly
IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP
Síťové úložiště
MicroSD/SDHC/SDXC card (32G inside) (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
API
ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G)
Současný živý náhled
Up to 20 channels
Úroveň uživatele/hostitele
Up to 32 users, 3 levels: Administrator, Operator, User
Bezpečnost
User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
Klient
iVMS-4200, Hik-Connect
Mobile Communication
SIM Card Type
MicroSIM
Frekvence
LTE FDD: B1/2/3/4/5/7/8/12/17/28/66 LTE TDD: B38/40 WCDMA: B1/2/3/4/5/8 GSM/GPRS/EDGE: 850/900/1800MHz
Standard
LTE FDD/LTE TDD/WCDMA/GSM/GPRS/EDGE
Rozhraní
Vstup alarmu
2, alarm input (0-5 VDC)
Výstup alarmu
2, alarm output (alarm response actions configurable)
Akce alarmu
Linkage Method Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output, Email
Zvukový vstup
1, 3.5 mm Mic in/Line in interface Line input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10%
Audio výstup
Linear level, impedance: 600 Ω
Komunikační rozhraní
1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface (half duplex)
Všeobecné
Menu Language
32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Zdroj napájení
12 VDC ± 25%, φ 5.5 mm coaxial power plug PoE (802.3af, class 3)
Spotřeba energie
Thermal only mode power consumption: 2.73W The average power consumption of 24 hours: 2.97W The max. power consumption: 7.1W (IR light on)
Working Temperature/Humidity
Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
Úroveň ochrany
IP67 Standard ,IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection
Dimensions
208.9 mm × 106 mm × 105.2 mm (8.22" × 4.17" × 4.14")
Adjustment Range
Bullet camera: Tilt: -10 ° to +45°, Pan: -180 ° to +180° Photovoltaic panel: Tilt: 10 ° or 30°
Váha
26.6kg(58.64lb)
Připevnění
Pole Mount
S váhou balení
27.79kg(61.26lb)
Podmínky skladování
Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
Spuštění a provozní podmínky
Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
Baterie
Typ baterie
Lithium *The battery should be ordered separately.
Napeti baterky
10.8 V
Kapacita baterie
30 Ah
Provozní teplota
Charging: -20 °C to 45 °C (-4 °F to 113 °F) Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
Životnost baterie
More than 500 cycles
Battery Weight
Approx. 3.3 kg (7.3 lb.)
Rozšířené rozměry
236 × 154 × 80 mm (9.3 " × 6.1 " × 3.2 ")
Max. Output Voltage
12.6 V
Schválení
EMC
FCC SDOC：47 CFR Part 15，Subpart B
RF
FCC-ID
Ochrana
Camera: IP67 (IEC 60529-2013),IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection Wind resistance 12 level
For better user experience, we highly recommend you to update your device to the latest firmware asap.
Specifikace
Tepelný modul
  • Senzor obrazuVanadium Oxide Uncooled Focal Plane Arrays
  • Řešení256 x 192
  • Pixel Pitch12 μm
  • Spectral Range8 μm to 14 μm
  • NETD ≤ 40 mK (@25° C,F# = 1.0)
  • Ohnisková vzdálenost9.7 mm
  • IFOV1.24 mrad
  • Clona F1.0
  • Zorné pole18.0° × 13.5° (H × V)
  • Min. Zaostřovací vzdálenost1.5 m
  • Digitální Zoom×2, ×4
Optický modul
  • Senzor obrazu1/2.7" Progressive Scan CMOS
  • Řešení2688 × 1520
  • Min. osvětlení0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR
  • Zorné pole 39.4°(H) x22.1°(V)
  • Ohnisková vzdálenost8 mm
  • ClonaF 1.6
  • Rychlost závěrky1 s to 1/100,000 s
  • Vyvážení bíléMWB/AWB1/Locked WB/Fluorescent Lamp/Incandescent Lamp/Warm Light Lamp/Natural Light
  • Denní a noční režim IR Cut Filter with Auto Switch
  • WDR120 dB
Image Effect
  • Bi-spektrální obrazová fúze Display the details of optical channel on thermal channel
  • Target Coloration Yes. Supported in white hot and black hot mode
Iluminátor
  • IR vzdálenost Up to 30 m
  • IR intenzita a úhel Automatically adjusted
Audible and Visual Alarm
  • Dosah bílého světla Up to 30 m
  • Vizuální alarmYes. White light alarm with adjustable flashing frequencies
  • Audio alarm Yes, for three types of audible alarm (VCA and Temperature Exception) 3 preset voice alerts (one for each) 6 importable user-defined voice alerts (6 options shared in the two types)
Inteligentní funkce
  • VCA 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
  • Měření teploty3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
  • Teplotní rozsah-20°C to 150°C (-4°F to 302°F)
  • Přesnost teploty ± 8°C (± 14.4°F)
Video and Audio
  • Hlavní proud Thermal: 25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
  • Sub-stream Thermal: 25 fps (704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 480, 352 × 240)
  • Video komprese Main Stream: H.265/H.264 Sub-Stream: H.265/H.264/MJPEG
  • Audio kompreseG.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
Síť
  • Protokoly IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP
  • Síťové úložištěMicroSD/SDHC/SDXC card (32G inside) (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
  • API ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G)
  • Současný živý náhledUp to 20 channels
  • Úroveň uživatele/hostiteleUp to 32 users, 3 levels: Administrator, Operator, User
  • Bezpečnost User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
  • Klient iVMS-4200, Hik-Connect
Mobile Communication
  • SIM Card TypeMicroSIM
  • FrekvenceLTE FDD: B1/2/3/4/5/7/8/12/17/28/66 LTE TDD: B38/40 WCDMA: B1/2/3/4/5/8 GSM/GPRS/EDGE: 850/900/1800MHz
  • StandardLTE FDD/LTE TDD/WCDMA/GSM/GPRS/EDGE
Rozhraní
  • Vstup alarmu2, alarm input (0-5 VDC)
  • Výstup alarmu 2, alarm output (alarm response actions configurable)
  • Akce alarmuLinkage Method Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output, Email
  • Zvukový vstup1, 3.5 mm Mic in/Line in interface Line input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10%
  • Audio výstupLinear level, impedance: 600 Ω
  • Komunikační rozhraní 1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface (half duplex)
Všeobecné
  • Menu Language32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
  • Zdroj napájení 12 VDC ± 25%, φ 5.5 mm coaxial power plug PoE (802.3af, class 3)
  • Spotřeba energieThermal only mode power consumption: 2.73W The average power consumption of 24 hours: 2.97W The max. power consumption: 7.1W (IR light on)
  • Working Temperature/HumidityTemperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Úroveň ochranyIP67 Standard ,IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection
  • Dimensions 208.9 mm × 106 mm × 105.2 mm (8.22" × 4.17" × 4.14")
  • Adjustment RangeBullet camera: Tilt: -10 ° to +45°, Pan: -180 ° to +180° Photovoltaic panel: Tilt: 10 ° or 30°
  • Váha26.6kg(58.64lb)
  • Připevnění Pole Mount
  • S váhou balení27.79kg(61.26lb)
  • Podmínky skladování Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Spuštění a provozní podmínky Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
Baterie
  • Typ baterieLithium *The battery should be ordered separately.
  • Napeti baterky10.8 V
  • Kapacita baterie30 Ah
  • Provozní teplotaCharging: -20 °C to 45 °C (-4 °F to 113 °F) Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
  • Životnost baterieMore than 500 cycles
  • Battery WeightApprox. 3.3 kg (7.3 lb.)
  • Rozšířené rozměry236 × 154 × 80 mm (9.3 " × 6.1 " × 3.2 ")
  • Max. Output Voltage12.6 V
Schválení
  • EMC FCC SDOC：47 CFR Part 15，Subpart B
  • RFFCC-ID
  • OchranaCamera: IP67 (IEC 60529-2013),IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection Wind resistance 12 level
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Resources

Příslušenství

DS-2FSCH30

IPC Battery
DS-2TXS2628-10P/QA/GLT/CH30S80(LA)
Data Sheet

Specifikace

  • Tepelný modul
  • Senzor obrazuVanadium Oxide Uncooled Focal Plane Arrays
  • Řešení256 x 192
  • Pixel Pitch12 μm
  • Spectral Range8 μm to 14 μm
  • NETD ≤ 40 mK (@25° C,F# = 1.0)
  • Ohnisková vzdálenost9.7 mm
  • IFOV1.24 mrad
  • Clona F1.0
  • Zorné pole18.0° × 13.5° (H × V)
  • Min. Zaostřovací vzdálenost1.5 m
  • Digitální Zoom×2, ×4
  • Optický modul
  • Senzor obrazu1/2.7" Progressive Scan CMOS
  • Řešení2688 × 1520
  • Min. osvětlení0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR
  • Zorné pole 39.4°(H) x22.1°(V)
  • Ohnisková vzdálenost8 mm
  • ClonaF 1.6
  • Rychlost závěrky1 s to 1/100,000 s
  • Vyvážení bíléMWB/AWB1/Locked WB/Fluorescent Lamp/Incandescent Lamp/Warm Light Lamp/Natural Light
  • Denní a noční režim IR Cut Filter with Auto Switch
  • WDR120 dB
  • Image Effect
  • Bi-spektrální obrazová fúze Display the details of optical channel on thermal channel
  • Target Coloration Yes. Supported in white hot and black hot mode
  • Iluminátor
  • IR vzdálenost Up to 30 m
  • IR intenzita a úhel Automatically adjusted
  • Audible and Visual Alarm
  • Dosah bílého světla Up to 30 m
  • Vizuální alarmYes. White light alarm with adjustable flashing frequencies
  • Audio alarm Yes, for three types of audible alarm (VCA and Temperature Exception) 3 preset voice alerts (one for each) 6 importable user-defined voice alerts (6 options shared in the two types)
  • Inteligentní funkce
  • VCA 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
  • Měření teploty3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
  • Teplotní rozsah-20°C to 150°C (-4°F to 302°F)
  • Přesnost teploty ± 8°C (± 14.4°F)
  • Video and Audio
  • Hlavní proud Thermal: 25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
  • Sub-stream Thermal: 25 fps (704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 480, 352 × 240)
  • Video komprese Main Stream: H.265/H.264 Sub-Stream: H.265/H.264/MJPEG
  • Audio kompreseG.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
  • Síť
  • Protokoly IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP
  • Síťové úložištěMicroSD/SDHC/SDXC card (32G inside) (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
  • API ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G)
  • Současný živý náhledUp to 20 channels
  • Úroveň uživatele/hostiteleUp to 32 users, 3 levels: Administrator, Operator, User
  • Bezpečnost User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
  • Klient iVMS-4200, Hik-Connect
  • Mobile Communication
  • SIM Card TypeMicroSIM
  • FrekvenceLTE FDD: B1/2/3/4/5/7/8/12/17/28/66 LTE TDD: B38/40 WCDMA: B1/2/3/4/5/8 GSM/GPRS/EDGE: 850/900/1800MHz
  • StandardLTE FDD/LTE TDD/WCDMA/GSM/GPRS/EDGE
  • Rozhraní
  • Vstup alarmu2, alarm input (0-5 VDC)
  • Výstup alarmu 2, alarm output (alarm response actions configurable)
  • Akce alarmuLinkage Method Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output, Email
  • Zvukový vstup1, 3.5 mm Mic in/Line in interface Line input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10%
  • Audio výstupLinear level, impedance: 600 Ω
  • Komunikační rozhraní 1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface (half duplex)
  • Všeobecné
  • Menu Language32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
  • Zdroj napájení 12 VDC ± 25%, φ 5.5 mm coaxial power plug PoE (802.3af, class 3)
  • Spotřeba energieThermal only mode power consumption: 2.73W The average power consumption of 24 hours: 2.97W The max. power consumption: 7.1W (IR light on)
  • Working Temperature/HumidityTemperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Úroveň ochranyIP67 Standard ,IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection
  • Dimensions 208.9 mm × 106 mm × 105.2 mm (8.22" × 4.17" × 4.14")
  • Adjustment RangeBullet camera: Tilt: -10 ° to +45°, Pan: -180 ° to +180° Photovoltaic panel: Tilt: 10 ° or 30°
  • Váha26.6kg(58.64lb)
  • Připevnění Pole Mount
  • S váhou balení27.79kg(61.26lb)
  • Podmínky skladování Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Spuštění a provozní podmínky Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Baterie
  • Typ baterieLithium *The battery should be ordered separately.
  • Napeti baterky10.8 V
  • Kapacita baterie30 Ah
  • Provozní teplotaCharging: -20 °C to 45 °C (-4 °F to 113 °F) Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
  • Životnost baterieMore than 500 cycles
  • Battery WeightApprox. 3.3 kg (7.3 lb.)
  • Rozšířené rozměry236 × 154 × 80 mm (9.3 " × 6.1 " × 3.2 ")
  • Max. Output Voltage12.6 V
  • Schválení
  • EMC FCC SDOC：47 CFR Part 15，Subpart B
  • RFFCC-ID
  • OchranaCamera: IP67 (IEC 60529-2013),IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection Wind resistance 12 level
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specifikace

Tepelný modul
Senzor obrazu
Vanadium Oxide Uncooled Focal Plane Arrays
Řešení
256 x 192
Pixel Pitch
12 μm
Spectral Range
8 μm to 14 μm
NETD
≤ 40 mK (@25° C,F# = 1.0)
Ohnisková vzdálenost
9.7 mm
IFOV
1.24 mrad
Clona
F1.0
Zorné pole
18.0° × 13.5° (H × V)
Min. Zaostřovací vzdálenost
1.5 m
Digitální Zoom
×2, ×4
Optický modul
Senzor obrazu
1/2.7" Progressive Scan CMOS
Řešení
2688 × 1520
Min. osvětlení
0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR
Zorné pole
39.4°(H) x22.1°(V)
Ohnisková vzdálenost
8 mm
Clona
F 1.6
Rychlost závěrky
1 s to 1/100,000 s
Vyvážení bílé
MWB/AWB1/Locked WB/Fluorescent Lamp/Incandescent Lamp/Warm Light Lamp/Natural Light
Denní a noční režim
IR Cut Filter with Auto Switch
WDR
120 dB
Image Effect
Bi-spektrální obrazová fúze
Display the details of optical channel on thermal channel
Target Coloration
Yes. Supported in white hot and black hot mode
Iluminátor
IR vzdálenost
Up to 30 m
IR intenzita a úhel
Automatically adjusted
Audible and Visual Alarm
Dosah bílého světla
Up to 30 m
Vizuální alarm
Yes. White light alarm with adjustable flashing frequencies
Audio alarm
Yes, for three types of audible alarm (VCA and Temperature Exception) 3 preset voice alerts (one for each) 6 importable user-defined voice alerts (6 options shared in the two types)
Inteligentní funkce
VCA
4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
Měření teploty
3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
Teplotní rozsah
-20°C to 150°C (-4°F to 302°F)
Přesnost teploty
± 8°C (± 14.4°F)
Video and Audio
Hlavní proud
Thermal: 25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-stream
Thermal: 25 fps (704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 480, 352 × 240)
Video komprese
Main Stream: H.265/H.264 Sub-Stream: H.265/H.264/MJPEG
Audio komprese
G.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
Síť
Protokoly
IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP
Síťové úložiště
MicroSD/SDHC/SDXC card (32G inside) (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
API
ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G)
Současný živý náhled
Up to 20 channels
Úroveň uživatele/hostitele
Up to 32 users, 3 levels: Administrator, Operator, User
Bezpečnost
User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
Klient
iVMS-4200, Hik-Connect
Mobile Communication
SIM Card Type
MicroSIM
Frekvence
LTE FDD: B1/2/3/4/5/7/8/12/17/28/66 LTE TDD: B38/40 WCDMA: B1/2/3/4/5/8 GSM/GPRS/EDGE: 850/900/1800MHz
Standard
LTE FDD/LTE TDD/WCDMA/GSM/GPRS/EDGE
Rozhraní
Vstup alarmu
2, alarm input (0-5 VDC)
Výstup alarmu
2, alarm output (alarm response actions configurable)
Akce alarmu
Linkage Method Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output, Email
Zvukový vstup
1, 3.5 mm Mic in/Line in interface Line input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10%
Audio výstup
Linear level, impedance: 600 Ω
Komunikační rozhraní
1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface (half duplex)
Všeobecné
Menu Language
32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Zdroj napájení
12 VDC ± 25%, φ 5.5 mm coaxial power plug PoE (802.3af, class 3)
Spotřeba energie
Thermal only mode power consumption: 2.73W The average power consumption of 24 hours: 2.97W The max. power consumption: 7.1W (IR light on)
Working Temperature/Humidity
Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
Úroveň ochrany
IP67 Standard ,IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection
Dimensions
208.9 mm × 106 mm × 105.2 mm (8.22" × 4.17" × 4.14")
Adjustment Range
Bullet camera: Tilt: -10 ° to +45°, Pan: -180 ° to +180° Photovoltaic panel: Tilt: 10 ° or 30°
Váha
26.6kg(58.64lb)
Připevnění
Pole Mount
S váhou balení
27.79kg(61.26lb)
Podmínky skladování
Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
Spuštění a provozní podmínky
Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
Baterie
Typ baterie
Lithium *The battery should be ordered separately.
Napeti baterky
10.8 V
Kapacita baterie
30 Ah
Provozní teplota
Charging: -20 °C to 45 °C (-4 °F to 113 °F) Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
Životnost baterie
More than 500 cycles
Battery Weight
Approx. 3.3 kg (7.3 lb.)
Rozšířené rozměry
236 × 154 × 80 mm (9.3 " × 6.1 " × 3.2 ")
Max. Output Voltage
12.6 V
Schválení
EMC
FCC SDOC：47 CFR Part 15，Subpart B
RF
FCC-ID
Ochrana
Camera: IP67 (IEC 60529-2013),IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection Wind resistance 12 level
For better user experience, we highly recommend you to update your device to the latest firmware asap.
Specifikace
Tepelný modul
  • Senzor obrazuVanadium Oxide Uncooled Focal Plane Arrays
  • Řešení256 x 192
  • Pixel Pitch12 μm
  • Spectral Range8 μm to 14 μm
  • NETD ≤ 40 mK (@25° C,F# = 1.0)
  • Ohnisková vzdálenost9.7 mm
  • IFOV1.24 mrad
  • Clona F1.0
  • Zorné pole18.0° × 13.5° (H × V)
  • Min. Zaostřovací vzdálenost1.5 m
  • Digitální Zoom×2, ×4
Optický modul
  • Senzor obrazu1/2.7" Progressive Scan CMOS
  • Řešení2688 × 1520
  • Min. osvětlení0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR
  • Zorné pole 39.4°(H) x22.1°(V)
  • Ohnisková vzdálenost8 mm
  • ClonaF 1.6
  • Rychlost závěrky1 s to 1/100,000 s
  • Vyvážení bíléMWB/AWB1/Locked WB/Fluorescent Lamp/Incandescent Lamp/Warm Light Lamp/Natural Light
  • Denní a noční režim IR Cut Filter with Auto Switch
  • WDR120 dB
Image Effect
  • Bi-spektrální obrazová fúze Display the details of optical channel on thermal channel
  • Target Coloration Yes. Supported in white hot and black hot mode
Iluminátor
  • IR vzdálenost Up to 30 m
  • IR intenzita a úhel Automatically adjusted
Audible and Visual Alarm
  • Dosah bílého světla Up to 30 m
  • Vizuální alarmYes. White light alarm with adjustable flashing frequencies
  • Audio alarm Yes, for three types of audible alarm (VCA and Temperature Exception) 3 preset voice alerts (one for each) 6 importable user-defined voice alerts (6 options shared in the two types)
Inteligentní funkce
  • VCA 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
  • Měření teploty3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
  • Teplotní rozsah-20°C to 150°C (-4°F to 302°F)
  • Přesnost teploty ± 8°C (± 14.4°F)
Video and Audio
  • Hlavní proud Thermal: 25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
  • Sub-stream Thermal: 25 fps (704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 480, 352 × 240)
  • Video komprese Main Stream: H.265/H.264 Sub-Stream: H.265/H.264/MJPEG
  • Audio kompreseG.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
Síť
  • Protokoly IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP
  • Síťové úložištěMicroSD/SDHC/SDXC card (32G inside) (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
  • API ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G)
  • Současný živý náhledUp to 20 channels
  • Úroveň uživatele/hostiteleUp to 32 users, 3 levels: Administrator, Operator, User
  • Bezpečnost User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
  • Klient iVMS-4200, Hik-Connect
Mobile Communication
  • SIM Card TypeMicroSIM
  • FrekvenceLTE FDD: B1/2/3/4/5/7/8/12/17/28/66 LTE TDD: B38/40 WCDMA: B1/2/3/4/5/8 GSM/GPRS/EDGE: 850/900/1800MHz
  • StandardLTE FDD/LTE TDD/WCDMA/GSM/GPRS/EDGE
Rozhraní
  • Vstup alarmu2, alarm input (0-5 VDC)
  • Výstup alarmu 2, alarm output (alarm response actions configurable)
  • Akce alarmuLinkage Method Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output, Email
  • Zvukový vstup1, 3.5 mm Mic in/Line in interface Line input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10%
  • Audio výstupLinear level, impedance: 600 Ω
  • Komunikační rozhraní 1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface (half duplex)
Všeobecné
  • Menu Language32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
  • Zdroj napájení 12 VDC ± 25%, φ 5.5 mm coaxial power plug PoE (802.3af, class 3)
  • Spotřeba energieThermal only mode power consumption: 2.73W The average power consumption of 24 hours: 2.97W The max. power consumption: 7.1W (IR light on)
  • Working Temperature/HumidityTemperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Úroveň ochranyIP67 Standard ,IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection
  • Dimensions 208.9 mm × 106 mm × 105.2 mm (8.22" × 4.17" × 4.14")
  • Adjustment RangeBullet camera: Tilt: -10 ° to +45°, Pan: -180 ° to +180° Photovoltaic panel: Tilt: 10 ° or 30°
  • Váha26.6kg(58.64lb)
  • Připevnění Pole Mount
  • S váhou balení27.79kg(61.26lb)
  • Podmínky skladování Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Spuštění a provozní podmínky Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
Baterie
  • Typ baterieLithium *The battery should be ordered separately.
  • Napeti baterky10.8 V
  • Kapacita baterie30 Ah
  • Provozní teplotaCharging: -20 °C to 45 °C (-4 °F to 113 °F) Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
  • Životnost baterieMore than 500 cycles
  • Battery WeightApprox. 3.3 kg (7.3 lb.)
  • Rozšířené rozměry236 × 154 × 80 mm (9.3 " × 6.1 " × 3.2 ")
  • Max. Output Voltage12.6 V
Schválení
  • EMC FCC SDOC：47 CFR Part 15，Subpart B
  • RFFCC-ID
  • OchranaCamera: IP67 (IEC 60529-2013),IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection Wind resistance 12 level
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Resources

Příslušenství

DS-2FSCH30

IPC Battery
DS-2TXS2628-10P/QA/GLT/CH30S80(LA)
Data Sheet

Specifikace

  • Tepelný modul
  • Senzor obrazuVanadium Oxide Uncooled Focal Plane Arrays
  • Řešení256 x 192
  • Pixel Pitch12 μm
  • Spectral Range8 μm to 14 μm
  • NETD ≤ 40 mK (@25° C,F# = 1.0)
  • Ohnisková vzdálenost9.7 mm
  • IFOV1.24 mrad
  • Clona F1.0
  • Zorné pole18.0° × 13.5° (H × V)
  • Min. Zaostřovací vzdálenost1.5 m
  • Digitální Zoom×2, ×4
  • Optický modul
  • Senzor obrazu1/2.7" Progressive Scan CMOS
  • Řešení2688 × 1520
  • Min. osvětlení0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR
  • Zorné pole 39.4°(H) x22.1°(V)
  • Ohnisková vzdálenost8 mm
  • ClonaF 1.6
  • Rychlost závěrky1 s to 1/100,000 s
  • Vyvážení bíléMWB/AWB1/Locked WB/Fluorescent Lamp/Incandescent Lamp/Warm Light Lamp/Natural Light
  • Denní a noční režim IR Cut Filter with Auto Switch
  • WDR120 dB
  • Image Effect
  • Bi-spektrální obrazová fúze Display the details of optical channel on thermal channel
  • Target Coloration Yes. Supported in white hot and black hot mode
  • Iluminátor
  • IR vzdálenost Up to 30 m
  • IR intenzita a úhel Automatically adjusted
  • Audible and Visual Alarm
  • Dosah bílého světla Up to 30 m
  • Vizuální alarmYes. White light alarm with adjustable flashing frequencies
  • Audio alarm Yes, for three types of audible alarm (VCA and Temperature Exception) 3 preset voice alerts (one for each) 6 importable user-defined voice alerts (6 options shared in the two types)
  • Inteligentní funkce
  • VCA 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
  • Měření teploty3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
  • Teplotní rozsah-20°C to 150°C (-4°F to 302°F)
  • Přesnost teploty ± 8°C (± 14.4°F)
  • Video and Audio
  • Hlavní proud Thermal: 25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
  • Sub-stream Thermal: 25 fps (704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 480, 352 × 240)
  • Video komprese Main Stream: H.265/H.264 Sub-Stream: H.265/H.264/MJPEG
  • Audio kompreseG.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
  • Síť
  • Protokoly IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP
  • Síťové úložištěMicroSD/SDHC/SDXC card (32G inside) (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
  • API ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G)
  • Současný živý náhledUp to 20 channels
  • Úroveň uživatele/hostiteleUp to 32 users, 3 levels: Administrator, Operator, User
  • Bezpečnost User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
  • Klient iVMS-4200, Hik-Connect
  • Mobile Communication
  • SIM Card TypeMicroSIM
  • FrekvenceLTE FDD: B1/2/3/4/5/7/8/12/17/28/66 LTE TDD: B38/40 WCDMA: B1/2/3/4/5/8 GSM/GPRS/EDGE: 850/900/1800MHz
  • StandardLTE FDD/LTE TDD/WCDMA/GSM/GPRS/EDGE
  • Rozhraní
  • Vstup alarmu2, alarm input (0-5 VDC)
  • Výstup alarmu 2, alarm output (alarm response actions configurable)
  • Akce alarmuLinkage Method Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output, Email
  • Zvukový vstup1, 3.5 mm Mic in/Line in interface Line input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10%
  • Audio výstupLinear level, impedance: 600 Ω
  • Komunikační rozhraní 1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface (half duplex)
  • Všeobecné
  • Menu Language32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
  • Zdroj napájení 12 VDC ± 25%, φ 5.5 mm coaxial power plug PoE (802.3af, class 3)
  • Spotřeba energieThermal only mode power consumption: 2.73W The average power consumption of 24 hours: 2.97W The max. power consumption: 7.1W (IR light on)
  • Working Temperature/HumidityTemperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Úroveň ochranyIP67 Standard ,IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection
  • Dimensions 208.9 mm × 106 mm × 105.2 mm (8.22" × 4.17" × 4.14")
  • Adjustment RangeBullet camera: Tilt: -10 ° to +45°, Pan: -180 ° to +180° Photovoltaic panel: Tilt: 10 ° or 30°
  • Váha26.6kg(58.64lb)
  • Připevnění Pole Mount
  • S váhou balení27.79kg(61.26lb)
  • Podmínky skladování Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Spuštění a provozní podmínky Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Baterie
  • Typ baterieLithium *The battery should be ordered separately.
  • Napeti baterky10.8 V
  • Kapacita baterie30 Ah
  • Provozní teplotaCharging: -20 °C to 45 °C (-4 °F to 113 °F) Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
  • Životnost baterieMore than 500 cycles
  • Battery WeightApprox. 3.3 kg (7.3 lb.)
  • Rozšířené rozměry236 × 154 × 80 mm (9.3 " × 6.1 " × 3.2 ")
  • Max. Output Voltage12.6 V
  • Schválení
  • EMC FCC SDOC：47 CFR Part 15，Subpart B
  • RFFCC-ID
  • OchranaCamera: IP67 (IEC 60529-2013),IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection Wind resistance 12 level
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specifikace

Tepelný modul
Senzor obrazu
Vanadium Oxide Uncooled Focal Plane Arrays
Řešení
256 x 192
Pixel Pitch
12 μm
Spectral Range
8 μm to 14 μm
NETD
≤ 40 mK (@25° C,F# = 1.0)
Ohnisková vzdálenost
9.7 mm
IFOV
1.24 mrad
Clona
F1.0
Zorné pole
18.0° × 13.5° (H × V)
Min. Zaostřovací vzdálenost
1.5 m
Digitální Zoom
×2, ×4
Optický modul
Senzor obrazu
1/2.7" Progressive Scan CMOS
Řešení
2688 × 1520
Min. osvětlení
0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR
Zorné pole
39.4°(H) x22.1°(V)
Ohnisková vzdálenost
8 mm
Clona
F 1.6
Rychlost závěrky
1 s to 1/100,000 s
Vyvážení bílé
MWB/AWB1/Locked WB/Fluorescent Lamp/Incandescent Lamp/Warm Light Lamp/Natural Light
Denní a noční režim
IR Cut Filter with Auto Switch
WDR
120 dB
Image Effect
Bi-spektrální obrazová fúze
Display the details of optical channel on thermal channel
Target Coloration
Yes. Supported in white hot and black hot mode
Iluminátor
IR vzdálenost
Up to 30 m
IR intenzita a úhel
Automatically adjusted
Audible and Visual Alarm
Dosah bílého světla
Up to 30 m
Vizuální alarm
Yes. White light alarm with adjustable flashing frequencies
Audio alarm
Yes, for three types of audible alarm (VCA and Temperature Exception) 3 preset voice alerts (one for each) 6 importable user-defined voice alerts (6 options shared in the two types)
Inteligentní funkce
VCA
4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
Měření teploty
3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
Teplotní rozsah
-20°C to 150°C (-4°F to 302°F)
Přesnost teploty
± 8°C (± 14.4°F)
Video and Audio
Hlavní proud
Thermal: 25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-stream
Thermal: 25 fps (704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 480, 352 × 240)
Video komprese
Main Stream: H.265/H.264 Sub-Stream: H.265/H.264/MJPEG
Audio komprese
G.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
Síť
Protokoly
IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP
Síťové úložiště
MicroSD/SDHC/SDXC card (32G inside) (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
API
ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G)
Současný živý náhled
Up to 20 channels
Úroveň uživatele/hostitele
Up to 32 users, 3 levels: Administrator, Operator, User
Bezpečnost
User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
Klient
iVMS-4200, Hik-Connect
Mobile Communication
SIM Card Type
MicroSIM
Frekvence
LTE FDD: B1/2/3/4/5/7/8/12/17/28/66 LTE TDD: B38/40 WCDMA: B1/2/3/4/5/8 GSM/GPRS/EDGE: 850/900/1800MHz
Standard
LTE FDD/LTE TDD/WCDMA/GSM/GPRS/EDGE
Rozhraní
Vstup alarmu
2, alarm input (0-5 VDC)
Výstup alarmu
2, alarm output (alarm response actions configurable)
Akce alarmu
Linkage Method Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output, Email
Zvukový vstup
1, 3.5 mm Mic in/Line in interface Line input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10%
Audio výstup
Linear level, impedance: 600 Ω
Komunikační rozhraní
1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface (half duplex)
Všeobecné
Menu Language
32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Zdroj napájení
12 VDC ± 25%, φ 5.5 mm coaxial power plug PoE (802.3af, class 3)
Spotřeba energie
Thermal only mode power consumption: 2.73W The average power consumption of 24 hours: 2.97W The max. power consumption: 7.1W (IR light on)
Working Temperature/Humidity
Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
Úroveň ochrany
IP67 Standard ,IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection
Dimensions
208.9 mm × 106 mm × 105.2 mm (8.22" × 4.17" × 4.14")
Adjustment Range
Bullet camera: Tilt: -10 ° to +45°, Pan: -180 ° to +180° Photovoltaic panel: Tilt: 10 ° or 30°
Váha
26.6kg(58.64lb)
Připevnění
Pole Mount
S váhou balení
27.79kg(61.26lb)
Podmínky skladování
Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
Spuštění a provozní podmínky
Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
Baterie
Typ baterie
Lithium *The battery should be ordered separately.
Napeti baterky
10.8 V
Kapacita baterie
30 Ah
Provozní teplota
Charging: -20 °C to 45 °C (-4 °F to 113 °F) Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
Životnost baterie
More than 500 cycles
Battery Weight
Approx. 3.3 kg (7.3 lb.)
Rozšířené rozměry
236 × 154 × 80 mm (9.3 " × 6.1 " × 3.2 ")
Max. Output Voltage
12.6 V
Schválení
EMC
FCC SDOC：47 CFR Part 15，Subpart B
RF
FCC-ID
Ochrana
Camera: IP67 (IEC 60529-2013),IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection Wind resistance 12 level
For better user experience, we highly recommend you to update your device to the latest firmware asap.
Specifikace
Tepelný modul
  • Senzor obrazuVanadium Oxide Uncooled Focal Plane Arrays
  • Řešení256 x 192
  • Pixel Pitch12 μm
  • Spectral Range8 μm to 14 μm
  • NETD ≤ 40 mK (@25° C,F# = 1.0)
  • Ohnisková vzdálenost9.7 mm
  • IFOV1.24 mrad
  • Clona F1.0
  • Zorné pole18.0° × 13.5° (H × V)
  • Min. Zaostřovací vzdálenost1.5 m
  • Digitální Zoom×2, ×4
Optický modul
  • Senzor obrazu1/2.7" Progressive Scan CMOS
  • Řešení2688 × 1520
  • Min. osvětlení0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR
  • Zorné pole 39.4°(H) x22.1°(V)
  • Ohnisková vzdálenost8 mm
  • ClonaF 1.6
  • Rychlost závěrky1 s to 1/100,000 s
  • Vyvážení bíléMWB/AWB1/Locked WB/Fluorescent Lamp/Incandescent Lamp/Warm Light Lamp/Natural Light
  • Denní a noční režim IR Cut Filter with Auto Switch
  • WDR120 dB
Image Effect
  • Bi-spektrální obrazová fúze Display the details of optical channel on thermal channel
  • Target Coloration Yes. Supported in white hot and black hot mode
Iluminátor
  • IR vzdálenost Up to 30 m
  • IR intenzita a úhel Automatically adjusted
Audible and Visual Alarm
  • Dosah bílého světla Up to 30 m
  • Vizuální alarmYes. White light alarm with adjustable flashing frequencies
  • Audio alarm Yes, for three types of audible alarm (VCA and Temperature Exception) 3 preset voice alerts (one for each) 6 importable user-defined voice alerts (6 options shared in the two types)
Inteligentní funkce
  • VCA 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
  • Měření teploty3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
  • Teplotní rozsah-20°C to 150°C (-4°F to 302°F)
  • Přesnost teploty ± 8°C (± 14.4°F)
Video and Audio
  • Hlavní proud Thermal: 25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
  • Sub-stream Thermal: 25 fps (704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 480, 352 × 240)
  • Video komprese Main Stream: H.265/H.264 Sub-Stream: H.265/H.264/MJPEG
  • Audio kompreseG.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
Síť
  • Protokoly IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP
  • Síťové úložištěMicroSD/SDHC/SDXC card (32G inside) (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
  • API ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G)
  • Současný živý náhledUp to 20 channels
  • Úroveň uživatele/hostiteleUp to 32 users, 3 levels: Administrator, Operator, User
  • Bezpečnost User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
  • Klient iVMS-4200, Hik-Connect
Mobile Communication
  • SIM Card TypeMicroSIM
  • FrekvenceLTE FDD: B1/2/3/4/5/7/8/12/17/28/66 LTE TDD: B38/40 WCDMA: B1/2/3/4/5/8 GSM/GPRS/EDGE: 850/900/1800MHz
  • StandardLTE FDD/LTE TDD/WCDMA/GSM/GPRS/EDGE
Rozhraní
  • Vstup alarmu2, alarm input (0-5 VDC)
  • Výstup alarmu 2, alarm output (alarm response actions configurable)
  • Akce alarmuLinkage Method Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output, Email
  • Zvukový vstup1, 3.5 mm Mic in/Line in interface Line input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10%
  • Audio výstupLinear level, impedance: 600 Ω
  • Komunikační rozhraní 1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface (half duplex)
Všeobecné
  • Menu Language32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
  • Zdroj napájení 12 VDC ± 25%, φ 5.5 mm coaxial power plug PoE (802.3af, class 3)
  • Spotřeba energieThermal only mode power consumption: 2.73W The average power consumption of 24 hours: 2.97W The max. power consumption: 7.1W (IR light on)
  • Working Temperature/HumidityTemperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Úroveň ochranyIP67 Standard ,IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection
  • Dimensions 208.9 mm × 106 mm × 105.2 mm (8.22" × 4.17" × 4.14")
  • Adjustment RangeBullet camera: Tilt: -10 ° to +45°, Pan: -180 ° to +180° Photovoltaic panel: Tilt: 10 ° or 30°
  • Váha26.6kg(58.64lb)
  • Připevnění Pole Mount
  • S váhou balení27.79kg(61.26lb)
  • Podmínky skladování Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Spuštění a provozní podmínky Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
Baterie
  • Typ baterieLithium *The battery should be ordered separately.
  • Napeti baterky10.8 V
  • Kapacita baterie30 Ah
  • Provozní teplotaCharging: -20 °C to 45 °C (-4 °F to 113 °F) Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
  • Životnost baterieMore than 500 cycles
  • Battery WeightApprox. 3.3 kg (7.3 lb.)
  • Rozšířené rozměry236 × 154 × 80 mm (9.3 " × 6.1 " × 3.2 ")
  • Max. Output Voltage12.6 V
Schválení
  • EMC FCC SDOC：47 CFR Part 15，Subpart B
  • RFFCC-ID
  • OchranaCamera: IP67 (IEC 60529-2013),IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection Wind resistance 12 level
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Resources

Příslušenství

DS-2FSCH30

IPC Battery

Hikvision.com uses strictly necessary cookies and related technologies to enable the website to function. With your consent, we would also like to use cookies to observe and analyse traffic levels and other metrics and tailor our website’s content. For more information on cookie practices please refer to our cookie policy.

Manage Cookies Reject all Accept
Accept
Reject all Manage Cookies
Prodej
Technická podpora
Odběr newsletteru
Online podpora
Kde nakupovat
Jiné
Kontakt
Hik-Partner Pro close
Hik-Partner Pro
Security Business Assistant. At Your Fingertips. Learn more
Hik-Partner Pro
Scan and download the app
Download
Hik-Partner Pro
Hik-Partner Pro

Get a better browsing experience

You are using a web browser we don’t support. Please try one of the following options to have a better experience of our web content.
