2 MP Fixed Bullet Network Camera

  • High quality imaging with 2 MP resolution
  • Easy installation with Power over Ethernet (PoE) technology
  • Efficient H.265+ compression technology
  • Support person detection
  • Water and dust resistant (IP67)
  • Clear imaging against strong back light due to digital WDR technology

View Less
View more
Data Sheet
Sales Inquiry

Available models:

IPC-B121HE-UC(2.8mm)(HiLookSTD)
IPC-B121HE-UC(4mm)(HiLookSTD)
IPC-B121HE-(L)UC
Data Sheet

Specification

  • กล้อง
  • Image Sensor 1/3" Progressive Scan CMOS
  • Max. Resolution 1920 × 1080
  • Min. Illumination Color: 0.01 Lux @ (F2.2, AGC ON),B/W: 0 Lux with IR
  • Shutter Time 1/3 s to 1/100,000 s
  • Day & Night IR cut filter
  • Angle Adjustment Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
  • Lens
  • Lens Type Fixed focal lens, 2.8 and 4 mm optional
  • Focal Length & FOV 2.8 mm, horizontal FOV 97°, vertical FOV 54°, diagonal FOV 113° 4 mm, horizontal FOV 76°, vertical FOV 42°, diagonal FOV 90°
  • Lens Mount M12
  • Iris Type Fixed
  • Aperture F2.2
  • Depth of Field 2.8 mm: 0.8 m to ∞ 4 mm: 1 m to ∞
  • DORI
  • DORI 2.8 mm, D: 45 m, O: 18 m, R: 9 m, I: 4 m 4 mm, D: 57 m, O: 22 m, R: 11 m, I: 5 m
  • Illuminator
  • Supplement Light Type IR
  • Supplement Light Range Up to 20 m
  • Smart Supplement Light Yes
  • IR Wavelength 850 nm
  • Video
  • Main Stream 50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
  • Sub-Stream 50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
  • Video Compression Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264
  • Video Bit Rate 32 Kbps to 8 Mbps
  • H.264 Type Baseline Profile,Main Profile,High Profile
  • H.265 Type Main Profile
  • Bit Rate Control CBR,VBR
  • Region of Interest (ROI) 1 fixed region for main stream
  • Network
  • API ONVIF (Profile S, Profile T),ISAPI,SDK
  • Security Password protection, complicated password, watermark, basic and digest authentication for HTTP, security audit log, host authentication (MAC address)
  • Simultaneous Live View Up to 6 channels
  • Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv4, UDP, QoS
  • User/Host Up to 32 users 3 user levels: administrator, operator, and user
  • Client iVMS-4200,HiLookVision
  • Web Browser Local service: Local service: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+
  • Image
  • Wide Dynamic Range (WDR) Digital WDR
  • SNR ≥ 52 dB
  • Privacy Mask 1 programmable polygon privacy mask
  • Day/Night Switch Day,Night,Auto,Schedule
  • Image Enhancement BLC,HLC,3D DNR
  • Image Settings Saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
  • Interface
  • Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
  • Built-in Microphone Yes,1 built-in microphone
  • Event
  • Basic Event Motion detection,exception
  • Linkage Notify surveillance center
  • General
  • Power PoE: IEEE 802.3af, Class 0, max. 6.5 W
  • Material Plastic
  • Dimension 138.8 mm × 60.9 mm × 57.9 mm (5.5" × 2.4" × 2.3")
  • Package Dimension 163 mm × 75 mm × 75 mm (6.4" × 3.0" × 3.0")
  • Weight Approx. 160 g (0.4 lb.)
  • With Package Weight Approx. 240 g (0.5 lb.)
  • Storage Conditions -30 °C to 45 °C (-22 °F to 113 °F). Humidity 95% or less (non-condensing)
  • Startup and Operating Conditions -30 °C to 45 °C (-22 °F to 113 °F). Humidity 95% or less (non-condensing)
  • Language English, Ukrainian
  • General Function Heartbeat,anti-banding,mirror,password protection,password reset via email
  • Approval
  • EMC CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
  • Safety CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017
  • Environment CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
  • Protection IP67: IEC 60529-2013
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specification

กล้อง
Image Sensor
1/3" Progressive Scan CMOS
Max. Resolution
1920 × 1080
Min. Illumination
Color: 0.01 Lux @ (F2.2, AGC ON),B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
Lens
Lens Type
Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV 97°, vertical FOV 54°, diagonal FOV 113° 4 mm, horizontal FOV 76°, vertical FOV 42°, diagonal FOV 90°
Lens Mount
M12
Iris Type
Fixed
Aperture
F2.2
Depth of Field
2.8 mm: 0.8 m to ∞ 4 mm: 1 m to ∞
DORI
DORI
2.8 mm, D: 45 m, O: 18 m, R: 9 m, I: 4 m 4 mm, D: 57 m, O: 22 m, R: 11 m, I: 5 m
Illuminator
Supplement Light Type
LUC: White Light UC: IR
Supplement Light Range
LUC: up to 15 m UC: up to 20 m
Smart Supplement Light
Yes
IR Wavelength
850 nm
Video
Main Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
Video Compression
Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264
Video Bit Rate
32 Kbps to 8 Mbps
H.264 Type
Baseline Profile,Main Profile,High Profile
H.265 Type
Main Profile
Bit Rate Control
CBR,VBR
Region of Interest (ROI)
1 fixed region for main stream
Network
API
ONVIF (Profile S, Profile T),ISAPI,SDK
Security
Password protection, complicated password, watermark, basic and digest authentication for HTTP, security audit log, host authentication (MAC address)
Simultaneous Live View
Up to 6 channels
Protocols
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv4, UDP, QoS
User/Host
Up to 32 users 3 user levels: administrator, operator, and user
Client
iVMS-4200,HiLookVision
Web Browser
Local service: Local service: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+
Wide Dynamic Range (WDR)
Digital WDR
SNR
≥ 52 dB
Privacy Mask
1 programmable polygon privacy mask
Day/Night Switch
Day,Night,Auto,Schedule
Image Enhancement
BLC,HLC,3D DNR
Image Settings
Saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Interface
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
Built-in Microphone
Yes,1 built-in microphone
Event
Basic Event
Motion detection,exception
Linkage
Notify surveillance center
General
Power
PoE: IEEE 802.3af, Class 0, max. 6.5 W
Material
Plastic
Dimension
138.8 mm × 60.9 mm × 57.9 mm (5.5" × 2.4" × 2.3")
Package Dimension
163 mm × 75 mm × 75 mm (6.4" × 3.0" × 3.0")
Weight
Approx. 160 g (0.4 lb.)
With Package Weight
Approx. 240 g (0.5 lb.)
Storage Conditions
-30 °C to 45 °C (-22 °F to 113 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions
-30 °C to 45 °C (-22 °F to 113 °F). Humidity 95% or less (non-condensing)
Language
English, Ukrainian
General Function
Heartbeat,anti-banding,mirror,password protection,password reset via email
Approval
EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
Safety
CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017
Environment
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
Protection
IP67: IEC 60529-2013
