DS-2CD1T57G0-L(UF)

5 MP ColorVu Fixed Bullet Network Camera

View Less

Modelos disponibles:

DS-2CD1T57G0-L(4mm)(C)

DS-2CD1T57G0-L(6mm)(C)

Lente
LenteFixed focal lens, 4 and 6 mm optional
Focal Length & FOV4 mm, horizontal FOV 76°, vertical FOV 57°, diagonal FOV 98° 6 mm, horizontal FOV 50°, vertical FOV 37°, diagonal FOV 63°
Montura del lenteM12
Iris TypeFixed
AperturaF1.0
Depth of Field4 mm: 2.7 m to ∞ 6 mm: 6 m to ∞

DORI
DORI4 mm, D: 82 m, O: 32 m, R: 16 m, I: 8 m 6 mm, D: 120 m, O: 47 m, R: 24 m, I: 12 m

Vídeo
Main stream50 Hz: 20 fps (2560 x 1920) 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 x 1920) 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-stream50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Compresión de videoMain stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG
Vídeo bitrate32 Kbps to 16 Mbps
Tipo H.264Baseline Profile,Main Profile,High Profile
Tipo H.265Main Profile
Bit Rate ControlCBR,VBR
Región de interés (ROI)1 fixed region(s) for main stream

Audio
Tipo de audio-U: Mono sound
Filtro de ruido ambiental-U: Yes
Frecuencia de muestreo de audio-U: 8 kHz/16 kHz
Compresión de audio-U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
Velocidad de bits de audio-U: 64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)

Red
ProtocolosTCP/IP, ICMP, DHCP, DNS, DDNS, HTTP, HTTPS, RTP, RTSP, NTP, UPnP, IGMP, IPv6, UDP, QoS, Bonjour,FTP,802.1x,SMTP
Vista en vivo simultáneaUp to 6 channels
APIOpen Network Video Interface (Profile S, Profile G ((only -U model supports)),ISAPI,SDK
Usuario/operadorUp to 32 users 3 user levels: administrator, operator, and user
SeguridadPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS,security audit log, TLS 1.2, host authentication (MAC address)
ClienteiVMS-4200,Hik-Connect
Navegador webPlug-in required live view: IE 10, IE 11, Local service: Chrome 57.0+, Firefox 52.0+

Imagen
Wide Dynamic Range (WDR)120 dB
SNR≥ 52 dB
Interruptor día/nocheDay,Night,Auto,Schedule
Mejora de la imagenBLC,HLC,3D DNR
Configuración de imagenRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Máscara de privacidad4 programmable polygon privacy masks

Interfaz
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage-F: Built-in memory card slot, support MicroSD/SDHC/SDXC card, up to 256 GB
Micrófono incorporado-U: Yes
Reset Key-F: Yes

Evento
Evento BásicoMotion detection,video tampering alarm,exception
LinkageUpload to FTP/memory card (-F), notify surveillance center, send email, trigger recording (-F), trigger capture

General
alimentación12 VDC ± 25%, 0.4 A, max. 5 W,Ø5.5 mm coaxial power plug, PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W
MaterialFront cover: metal, body: plastic, bracket: metal
Dimensión83.7 mm × 80.7 mm × 205.6 mm (3.3" × 3.2" × 8.1")
Dimensión del paquete260 mm × 125 mm × 125 mm (10.2" × 4.9" × 4.9")
-L : Approx. 410 g (0.9 lb.) -LUF : Approx. 420 g (0.9 lb.)
Con peso del paquete -L: Approx. 634 g (1.4 lb.) -LUF: Approx. 654 g (1.4 lb.)
Condiciones de almacenaje-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Condiciones de inicio y funcionamiento-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
IdiomaEnglish, Ukranian
Función generalHeartbeat,anti-flicker,mirror,password protection,password reset via email

Certificaciones
EMCFCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, KC: KN32: 2015, KN35: 2015
SeguridadUL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
AmbienteCE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
ProtecciónIP67: IEC 60529-2013
