HikCentral-Storage

  • A flexible, reliable, and powerful central security system
  • Provides central management, information sharing, convenient connection and multi-service cooperation
  • Capable of adding devices for management, live view, storage and playback of video files, alarm linkage, access control, and so on
View Less
View more

Modelos disponibles:

Hikcentral-Storage/256/16H

Especificación

  • Devices and Servers
  • Cameras256
  • Video Intercom Devices64
  • Alarm Inputs64
  • Alarm Outputs64
  • ANPR Cameras32
  • Facial Recognition Cameras16
  • Security Radars and Radar PTZ Cameras16
  • Recording Server16
  • People Counting Cameras16
  • Heat Map Cameras16
  • Thermal Cameras16
  • Queue Management Cameras16
  • Recording Schedule
  • Recording Schedule64
  • Recording Schedule Template32
  • Event & Alarm
  • Event and Alarm Rules1,500
  • Storage of Events or Alarms without Pictures100/s
  • Events or Alarms Sent to Clients15/s 32 Clients/s
  • Almacenamiento
  • Picture Storage20/s *Including event/alarm pictures, face pictures, and vehicle pictures.
  • Data Retention PeriodStored for 3 Years
  • Users and Roles
  • Concurrent Accesses via Web Clients, Control Clients, and OpenAPI Clients32
  • Concurrent Accesses via Mobile Clients and OpenAPI Clients32
  • Users256
  • Roles32
  • Entrance & Exit
  • Vehicle Lists100
  • Vehicles per Vehicle List5,000
  • Lanes8
  • Vehicle Passing Frequency in Each Lane1 Vehicle/s
  • Comparación de rostros
  • Persons with Profiles for Face Comparison10,000
  • Face Comparison Groups16
  • Persons in One Face Comparison Group1,000
  • Access Control
  • Persons with Credentials for Access Control10,000
  • Total Credentials (Card + Fingerprint)50,000
  • Tarjetas50,000
  • Fingerprints40,000
  • Profile Pictures10,000
  • Access Points (Doors + Outdoor Station)128
  • Access Levels256
  • Time and Attendance
  • Persons for Time and Attendance10,000
  • Shift Schedules128
  • Major Leave Types64
  • Minor Leave Types of One Major Type128
  • Smart Wall
  • Decoding Devices32
  • Smart Walls32
  • Views Auto-Switched Simultaneously32
  • Sistema
  • Main ProcessorQuad-Core Intel® Xeon® Processor E3 V5 Series
  • Memoria16GB DDR4. ECC parity. Extendable up to 64 GB
  • System BandwidthMulti-address/net fault-tolerance mode: 768 Mbps; Load balancing mode: 1,000 Mbps
  • Number of Storage Channels256
  • Video and Audio
  • HDMI 1 Output1024 × 768/60 Hz
  • HDMI 2 Output1024 × 768/60 Hz
  • VGA Output1024 × 768/60 Hz
  • Video Output ModeHDMI1/HDMI2/VGA simultaneous output
  • Salida de audio1-ch, RCA (Linear, 1 KΩ)
  • Entrada de Audio1-ch, RCA (2.0 Vp-p, 1 KΩ)
  • Red
  • Interfaz de red4 × RJ45 10M/100M/1000M self-adaptive Ethernet interface
  • RAID
  • RAID TypeRAID0, RAID1, RAID5, RAID6, RAID10, RAID50, RAID60, JBOD
  • Auxiliary Interface
  • SATA16 SATA interfaces supporting hot-swapping (except the HDD at the first slot which contains the system disk)
  • eSATA1 eSATA interface
  • CapacidadUp to 10 TB capacity for each disk
  • Interfaz USBFront panel: 2 × USB 2.0; Rear panel: 2 × USB 3.0
  • Alarma E/S16/8
  • Tablero de extensiónThe extension board is optional to support. It has four 10M/100M/1000M optical interfaces (1.25 Gbps SFP module), eight RS-485 interfaces, 32 alarm inputs, and 16 alarm outputs.
  • General
  • Consumo≤ 140 W (without HDD)
  • Temperatura de trabajo 0 °C to 50 °C (32 °F to 122 °F);
  • Condiciones de Humedad10% to 90% RH (no freezing and no condensation)
  • Chassis3U
  • Dimensión (W × D × H)446 × 495 × 133 mm (17.6 × 19.5 × 5.2 inch)
  • ≤ 17 kg (37.5 lb.)
