Solar-powered Thermal Camera Kit

  • 256 × 192 resolution, 12 μm, VOx UFPA, NETD < 40 mK (25°C, F1.0)
  • Video content analysis: vehicle/human classification
  • 80 W photovoltaic panel, 30 Ah chargeable lithium battery(The battery should be ordered separately.)
  • Temperature exception alarm for fire prevention, -20°C to 150°C (-4°F to 302°F), ± 8°C (± 14.4°F)
  • LTE-TDD/LTE-FDD/WCDMA 4G wireless network transmission, support Micro SIM card
  • Water and dust resistant (IP67)
  • Embedded audible alert and strobe light
  • High quality detector with 10 years guarantee

View Less
View more

Available models:

DS-2TXS2628-10P/QA/GLT/CH30S80

Specification

  • Thermal Module
  • Image SensorVanadium Oxide Uncooled Focal Plane Arrays
  • Resolution256 x 192
  • Pixel Pitch12 μm
  • Spectral Range8 μm to 14 μm
  • NETD ≤ 40 mK (@25° C,F# = 1.0)
  • Focal Length9.7 mm
  • IFOV1.24 mrad
  • Aperture F1.0
  • Field of View18.0° × 13.5° (H × V)
  • Min. Focusing Distance1.5 m
  • Digital Zoom×2, ×4
  • Optical Module
  • Image Sensor1/2.7" Progressive Scan CMOS
  • Resolution2688 × 1520
  • Min. Illumination0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR
  • Field of View 39.4°(H) x22.1°(V)
  • Focal Length8 mm
  • ApertureF 1.6
  • Shutter Speed1 s to 1/100,000 s
  • White BalanceMWB/AWB1/Locked WB/Fluorescent Lamp/Incandescent Lamp/Warm Light Lamp/Natural Light
  • Day & Night Mode IR Cut Filter with Auto Switch
  • WDR120 dB
  • Image Effect
  • Bi-spectrum Image Fusion Display the details of optical channel on thermal channel
  • Target Coloration Yes. Supported in white hot and black hot mode
  • Illuminator
  • IR Distance Up to 30 m
  • IR Intensity and Angle Automatically adjusted
  • Audible and Visual Alarm
  • White Light Range Up to 30 m
  • Visual AlarmYes. White light alarm with adjustable flashing frequencies
  • Audio alarm Yes, for three types of audible alarm (VCA and Temperature Exception) 3 preset voice alerts (one for each) 6 importable user-defined voice alerts (6 options shared in the two types)
  • Smart Function
  • VCA 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
  • Temperature Measurement3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
  • Temperature Range-20°C to 150°C (-4°F to 302°F)
  • Temperature Accuracy ± 8°C (± 14.4°F)
  • Video and Audio
  • Main Stream Thermal: 25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
  • Sub-stream Thermal: 25 fps (704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 480, 352 × 240)
  • Video Compression Main Stream: H.265/H.264 Sub-Stream: H.265/H.264/MJPEG
  • Audio CompressionG.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
  • Network
  • Protocols IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP
  • Network StorageMicroSD/SDHC/SDXC card (32G inside) (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
  • API ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G)
  • Simultaneous Live ViewUp to 20 channels
  • User/Host levelUp to 32 users, 3 levels: Administrator, Operator, User
  • Security User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
  • Client iVMS-4200, Hik-Connect
  • Mobile Communication
  • SIM Card TypeMicroSIM
  • FrequencyLTE FDD: B 1/3/5/7/8/20/28 LTE TDD: B 38/40/41 WCDMA: B 1/5/8
  • StandardLTE FDD/LTE TDD/WCDMA
  • Interface
  • Alarm Input2, alarm input (0-5 VDC)
  • Alarm Output 2, alarm output (alarm response actions configurable)
  • Alarm ActionLinkage Method Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output, Email
  • Audio Input1, 3.5 mm Mic in/Line in interface Line input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10%
  • Audio OutputLinear level, impedance: 600 Ω
  • Communication Interface 1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface (half duplex)
  • General
  • Menu Language32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
  • Alimentation 12 VDC ± 25%, φ 5.5 mm coaxial power plug PoE (802.3af, class 3)
  • Power ConsumptionThermal only mode power consumption: 2.73W The average power consumption of 24 hours: 2.97W The max. power consumption: 7.1W (IR light on)
  • Working Temperature/HumidityTemperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Protection LevelIP67 Standard ,IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection
  • Dimensions 208.9 mm × 106 mm × 105.2 mm (8.22" × 4.17" × 4.14")
  • Adjustment RangeBullet camera: Tilt: -10 ° to +45°, Pan: -180 ° to +180° Photovoltaic panel: Tilt: 10 ° or 30°
  • Weight26.6kg(58.64lb)
  • Mount Pole Mount
  • With Package Weight27.79kg(61.26lb)
  • Storage Conditions Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Startup and Operating Conditions Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
  • Battery
  • Battery TypeLithium *The battery should be ordered separately.
  • Battery Voltage10.8 V
  • Battery Capacity30 Ah
  • Operating TemperatureCharging: -20 °C to 45 °C (-4 °F to 113 °F) Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
  • Battery LifeMore than 500 cycles
  • Battery WeightApprox. 3.3 kg (7.3 lb.)
  • Extended Dimension236 × 154 × 80 mm (9.3 " × 6.1 " × 3.2 ")
  • Max. Output Voltage12.6 V
  • Approval
  • EMCCE-EMC：EN 55032:2015+A11:2020；EN 50130-4:2011+A1:2014；EN IEC 61000-3-2:2019+A1:2021；EN 61000-3-3:2013+A1:2019 FCC SDOC：47 CFR Part 15，Subpart B
  • RFCE-RED : EN 301 489-1 V2.2.3; EN 301 489-19 V2.2.0; EN 301 489-52 V1.2.1; EN 301 511 V12.5.1; EN 301 908-1 V13.1.1; EN 301 908-2 V13.1.1; EN 301 908-13 V13.1.1; EN 303 413 V1.1.1; EN 62311:2008
  • SafetyCB : IEC 62368-1: 2014 CE-LVD： IEC 62368-1: 2014
  • Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
  • ProtectionCamera: IP67 (IEC 60529-2013),IK10-rated housing TVS 4000V lightning protection, surge protection, voltage transient protection Wind resistance 12 level
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specification

Thermal Module
Image Sensor
Vanadium Oxide Uncooled Focal Plane Arrays
Resolution
256 x 192
Pixel Pitch
12 μm
Spectral Range
8 μm to 14 μm
NETD
≤ 40 mK (@25° C,F# = 1.0)
Focal Length
9.7 mm
IFOV
1.24 mrad
Aperture
F1.0
Field of View
18.0° × 13.5° (H × V)
Min. Focusing Distance
1.5 m
Digital Zoom
×2, ×4
Optical Module
Image Sensor
1/2.7" Progressive Scan CMOS
Resolution
2688 × 1520
Min. Illumination
0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR
Field of View
39.4°(H) x22.1°(V)
Focal Length
8 mm
Aperture
F 1.6
Shutter Speed
1 s to 1/100,000 s
White Balance
MWB/AWB1/Locked WB/Fluorescent Lamp/Incandescent Lamp/Warm Light Lamp/Natural Light
Day & Night Mode
IR Cut Filter with Auto Switch
WDR
120 dB
Image Effect
Bi-spectrum Image Fusion
Display the details of optical channel on thermal channel
Target Coloration
Yes. Supported in white hot and black hot mode
Illuminator
IR Distance
Up to 30 m
IR Intensity and Angle
Automatically adjusted
Audible and Visual Alarm
White Light Range
Up to 30 m
Visual Alarm
Yes. White light alarm with adjustable flashing frequencies
Audio alarm
Yes, for three types of audible alarm (VCA and Temperature Exception) 3 preset voice alerts (one for each) 6 importable user-defined voice alerts (6 options shared in the two types)
Smart Function
VCA
4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
Temperature Measurement
3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
Temperature Range
-20°C to 150°C (-4°F to 302°F)
Temperature Accuracy
± 8°C (± 14.4°F)
Video and Audio
Main Stream
Thermal: 25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-stream
Thermal: 25 fps (704 × 576, 640 × 512, 320 × 240) Optical: 50 Hz: 25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 480, 352 × 240)
Video Compression
Main Stream: H.265/H.264 Sub-Stream: H.265/H.264/MJPEG
Audio Compression
G.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
Network
Protocols
IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP
Network Storage
MicroSD/SDHC/SDXC card (32G inside) (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
API
ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G)
Simultaneous Live View
Up to 20 channels
User/Host level
Up to 32 users, 3 levels: Administrator, Operator, User
Security
User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
Client
iVMS-4200, Hik-Connect
