Discontinued

5-inch 2 MP 20X Powered by DarkFighter IR Network Speed Dome

  • High quality imaging with 2 MP resolution
  • Capture a detailed scene using 20x optical zoom
  • Offers another choice for the indoor environment with Wi-Fi function
  • Remote live viewing is available, supported by Hik-Connect cloud service.
View Less
View more
Data Sheet
Renseignements sur les ventes

Available models:

DS-2DF5220S-DE4/W
DS-2DF5220S-DE4/W Discontinued
Data Sheet

Specification

  • Lens
  • FOVHorizontal field of view: 58.3° to 3.2° (Wide-Tele)
  • Zoom SpeedApprox.2.7s(Optical Wide-Tele)
  • Working Distance10-1500mm(Wide-Tele)
  • Aperture RangeF1.6~F3.5
  • Focal Length4.7 mm to 94 mm, 20 ×
  • Video
  • Max. Resolution1920 × 1080
  • Network
  • ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
  • APIOpen-ended API, support ONVIF, PSIA, CGI and Genetec
  • Simultaneous Live ViewUp to 20 channels
  • User/HostUp to 32 users,3 Levels: Administrator, Operator and User
  • Security MeasuresUser authentication (ID and PW); Host authentication (MAC address); IP address filtering
  • ClientiVMS-4200, Hik-Connect *Wi-Fi connection with Hik-Connect directly is not possible.
  • Interface
  • BNC1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC
  • Alarm Output1-ch alarm output
  • Alarm Input2-ch alarm input
  • Audio Input1 Mic in/Line in interface, line input: 2-2.4V[p-p]; output impedance: 1KΩ, ±10%
  • Audio Output1 Audio output interface, line level, impedance: 600Ω
  • RS-485HIKVISION, Pelco-P, Pelco-D, self-adaptive
  • StorageMicro SD/SDHC/SDXC card local storage, Support up to 8 NAS storage; Edge recording(transmit the videos from SD card to the NAS after network resumed)
  • Camera Module
  • AGCAuto/Manual
  • Image Sensor1/3”Progressive Scan CMOS
  • Min. IlluminationF1.6, 1/1 sec, 50 IRE, AGC On: Color: 0.02 lux, B/W : 0.002 lux F1.6, 1/30 sec, 50 IRE, AGC On: Color:0.3 lux, B/W : 0.02 lux
  • Day & NightIR cut filter
  • Digital Zoom16×
  • Privacy Mask24 privacy masks programmable; optional multiple colors and mosaics
  • Focus ModeAuto/Semi-automatic/Manual
  • WDRDigital WDR
  • BLCYes
  • HLCYes
  • PTZ
  • Movement Range (Pan)360° endless
  • Pan SpeedConfigurable, from 0.1°/s to 150°/s, Preset Speed: 270°/s
  • Movement Range (Tilt)From -30° to 90°
  • Tilt SpeedConfigurable, from 0.1°/s to 120°/s, Preset Speed: 200°/s
  • Presets300
  • Patrol Scan8 patrols, up to 32 presets for each patrol
  • Pattern Scan4 pattern scans, record time over 10 minutes for each scan
  • Power-off MemoryYes
  • Park ActionPreset / Patrol / Pattern / Auto scan / Tilt scan / Random scan / Frame scan / Panorama scan
  • Smart Features
  • Smart TrackingManual/ Panorama/ Intrusion trigger/ Line crossing trigger/ Region entrance trigger/ Region exiting trigger Smart tracking when patrol between multiple scenarios
  • ROISupport 24 areas with adjustable levels
  • General
  • DimensionsΦ176.6(mm)×202.7(mm)
  • Weight1.8kg
  • Power12VDC, PoE+, Max. 24W
  • Working Temperature-10° C ~ 50° C (-14° F ~ 122° F)
  • Working Humidity≤ 90%
*Les performances du produit sont basées sur des tests en environnement contr?lé. Les résultats peuvent varier. Le contenu est traduit automatiquement; veuillez vous référer à la version anglaise pour plus de précision.

Specification

Lens
FOV
Horizontal field of view: 58.3° to 3.2° (Wide-Tele)
Zoom Speed
Approx.2.7s(Optical Wide-Tele)
Working Distance
10-1500mm(Wide-Tele)
Aperture Range
F1.6~F3.5
Focal Length
4.7 mm to 94 mm, 20 ×
Video
Max. Resolution
1920 × 1080
Network
Protocols
IPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
API
Open-ended API, support ONVIF, PSIA, CGI and Genetec
Simultaneous Live View
Up to 20 channels
User/Host
Up to 32 users,3 Levels: Administrator, Operator and User
Security Measures
User authentication (ID and PW); Host authentication (MAC address); IP address filtering
Client
iVMS-4200, Hik-Connect *Wi-Fi connection with Hik-Connect directly is not possible.
Interface
BNC
1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC
Alarm Output
1-ch alarm output
Alarm Input
2-ch alarm input
Audio Input
1 Mic in/Line in interface, line input: 2-2.4V[p-p]; output impedance: 1KΩ, ±10%
Audio Output
1 Audio output interface, line level, impedance: 600Ω
RS-485
HIKVISION, Pelco-P, Pelco-D, self-adaptive
Storage
Micro SD/SDHC/SDXC card local storage, Support up to 8 NAS storage; Edge recording(transmit the videos from SD card to the NAS after network resumed)
Camera Module
AGC
Auto/Manual
Image Sensor
1/3”Progressive Scan CMOS
Min. Illumination
F1.6, 1/1 sec, 50 IRE, AGC On: Color: 0.02 lux, B/W : 0.002 lux F1.6, 1/30 sec, 50 IRE, AGC On: Color:0.3 lux, B/W : 0.02 lux
Day & Night
IR cut filter
Digital Zoom
16×
Privacy Mask
24 privacy masks programmable; optional multiple colors and mosaics
Focus Mode
Auto/Semi-automatic/Manual
WDR
Digital WDR
BLC
Yes
HLC
Yes
PTZ
Movement Range (Pan)
360° endless
Pan Speed
Configurable, from 0.1°/s to 150°/s, Preset Speed: 270°/s
Movement Range (Tilt)
From -30° to 90°
Tilt Speed
Configurable, from 0.1°/s to 120°/s, Preset Speed: 200°/s
Presets
300
Patrol Scan
8 patrols, up to 32 presets for each patrol
Pattern Scan
4 pattern scans, record time over 10 minutes for each scan
Power-off Memory
Yes
Park Action
Preset / Patrol / Pattern / Auto scan / Tilt scan / Random scan / Frame scan / Panorama scan
Smart Features
Smart Tracking
Manual/ Panorama/ Intrusion trigger/ Line crossing trigger/ Region entrance trigger/ Region exiting trigger Smart tracking when patrol between multiple scenarios
ROI
Support 24 areas with adjustable levels
General
Dimensions
Φ176.6(mm)×202.7(mm)
Weight
1.8kg
Power
12VDC, PoE+, Max. 24W
Working Temperature
-10° C ~ 50° C (-14° F ~ 122° F)
Working Humidity
≤ 90%
Pour une meilleure expérience utilisateur, nous vous recommandons fortement de mettre à jour votre appareil avec le dernier micrologiciel dès que possible.
Specification
Lens
  • FOVHorizontal field of view: 58.3° to 3.2° (Wide-Tele)
  • Zoom SpeedApprox.2.7s(Optical Wide-Tele)
  • Working Distance10-1500mm(Wide-Tele)
  • Aperture RangeF1.6~F3.5
  • Focal Length4.7 mm to 94 mm, 20 ×
Video
  • Max. Resolution1920 × 1080
Network
  • ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
  • APIOpen-ended API, support ONVIF, PSIA, CGI and Genetec
  • Simultaneous Live ViewUp to 20 channels
  • User/HostUp to 32 users,3 Levels: Administrator, Operator and User
  • Security MeasuresUser authentication (ID and PW); Host authentication (MAC address); IP address filtering
  • ClientiVMS-4200, Hik-Connect *Wi-Fi connection with Hik-Connect directly is not possible.
Interface
  • BNC1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC
  • Alarm Output1-ch alarm output
  • Alarm Input2-ch alarm input
  • Audio Input1 Mic in/Line in interface, line input: 2-2.4V[p-p]; output impedance: 1KΩ, ±10%
  • Audio Output1 Audio output interface, line level, impedance: 600Ω
  • RS-485HIKVISION, Pelco-P, Pelco-D, self-adaptive
  • StorageMicro SD/SDHC/SDXC card local storage, Support up to 8 NAS storage; Edge recording(transmit the videos from SD card to the NAS after network resumed)
Camera Module
  • AGCAuto/Manual
  • Image Sensor1/3”Progressive Scan CMOS
  • Min. IlluminationF1.6, 1/1 sec, 50 IRE, AGC On: Color: 0.02 lux, B/W : 0.002 lux F1.6, 1/30 sec, 50 IRE, AGC On: Color:0.3 lux, B/W : 0.02 lux
  • Day & NightIR cut filter
  • Digital Zoom16×
  • Privacy Mask24 privacy masks programmable; optional multiple colors and mosaics
  • Focus ModeAuto/Semi-automatic/Manual
  • WDRDigital WDR
  • BLCYes
  • HLCYes
PTZ
  • Movement Range (Pan)360° endless
  • Pan SpeedConfigurable, from 0.1°/s to 150°/s, Preset Speed: 270°/s
  • Movement Range (Tilt)From -30° to 90°
  • Tilt SpeedConfigurable, from 0.1°/s to 120°/s, Preset Speed: 200°/s
  • Presets300
  • Patrol Scan8 patrols, up to 32 presets for each patrol
  • Pattern Scan4 pattern scans, record time over 10 minutes for each scan
  • Power-off MemoryYes
  • Park ActionPreset / Patrol / Pattern / Auto scan / Tilt scan / Random scan / Frame scan / Panorama scan
Smart Features
  • Smart TrackingManual/ Panorama/ Intrusion trigger/ Line crossing trigger/ Region entrance trigger/ Region exiting trigger Smart tracking when patrol between multiple scenarios
  • ROISupport 24 areas with adjustable levels
General
  • DimensionsΦ176.6(mm)×202.7(mm)
  • Weight1.8kg
  • Power12VDC, PoE+, Max. 24W
  • Working Temperature-10° C ~ 50° C (-14° F ~ 122° F)
  • Working Humidity≤ 90%
*Les performances du produit sont basées sur des tests en environnement contr?lé. Les résultats peuvent varier. Le contenu est traduit automatiquement; veuillez vous référer à la version anglaise pour plus de précision.

Ressources

Micrologiciel

Pour une meilleure expérience utilisateur, nous vous recommandons fortement de mettre à jour votre appareil avec le dernier micrologiciel dès que possible.

Micrologiciel

Pour une meilleure expérience utilisateur, nous vous recommandons fortement de mettre à jour votre appareil avec le dernier micrologiciel dès que possible.
Firmware_V9.27_050201
Applied to:
DS-2DF5220S-DE4/W
