4MP Smart Manufacturing Vari-focal Bullet Camera

  • High quality imaging with 4 MP resolution
  • Clear imaging against strong back light due to 120 dB true WDR technology
  • High frame rate, up to 4 MP@60 fps
  • Motorized varifocal lens for easy installation and monitoring
  • Support on-board storage up to 512 GB (SD card slot)
  • Alarm interface available
  • White and IR supplement light
  • Support shock absorption to reduce positional deviation in vibrating machine environment
  • Adopt displacement detection alarm

View Less
View more
Sales Inquiry

Available models:

iDS-2CD8B45G0-IZS(2.8-8mm)(HIK)
iDS-2CD8B45G0-IZS

Specification

  • Camera
  • Image Sensor1/2.7″ Progressive Scan CMOS
  • Max. Resolution2560 × 1440
  • Min. IlluminationColor: 0.002 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR
  • Shutter Time1/3 s to 1/100,000 s
  • Day & NightIR cut filter
  • Lens
  • Lens TypeMotorized lens, 2.8 to 8 mm
  • Focal Length & FOV2.8 to 8 mm, horizontal FOV 93.2° to 48.6°, vertical FOV 50.3° to 27.3°, diagonal FOV 109.7° to 55.8°
  • ApertureF1.8
  • Lens MountØ14
  • Illuminator
  • Supplement Light TypeIR,White Light
  • Supplement Light RangeIR: up to 3 m White Light: up to 3 m
  • Smart Supplement LightYes
  • IR Wavelength850 nm
  • AI Open Platform
  • Model SpecificationUp to 1 model, Model type: detection model, classification model, mixed model (detection model and classification model)
  • Video
  • Main Stream50Hz: 50 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60Hz: 60 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
  • Sub-Stream50 Hz: 25 fps (640 × 480, 704 × 576) 60 Hz: 30 fps (640 × 480, 704 × 480)
  • Video Compression Main stream: H.265/H.264, Sub-stream: H.265/H.264/MJPEG
  • Video Bit Rate32 Kbps to 8 Mbps
  • H.264 TypeBaseline Profile,Main Profile,High Profile
  • H.265 TypeMain Profile
  • Bit Rate ControlCBR,VBR
  • Scalable Video Coding (SVC)H.264 and H.265 encoding
  • Region of Interest (ROI)4 fixed regions for each stream
  • Network
  • ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
  • APIONVIF,ISAPI,SDK,ISUP
  • Simultaneous Live ViewUp to 6 channels
  • User/HostUp to 32 users. 3 user levels: administrator, operator and user
  • SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2
  • Network StorageNAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
  • ClientiVMS-4200, Hik-Connect, Hik-Central
  • Web BrowserPlug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+
  • Image
  • Image Parameters SwitchYes
  • Image Settingssaturation,brightness,contrast,sharpness,white balance,AGC,adjustable by client software or web browser
  • Day/Night SwitchDay,Night,Auto,Schedule
  • Wide Dynamic Range (WDR)120 dB
  • Image EnhancementBLC,HLC,3D DNR,Defog
  • Picture OverlayLOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
  • Interface
  • Alarm 1 input, 1 output (max. 24 VDC, 30 A)
  • On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
  • Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
  • Reset KeyYes
  • Event
  • Basic Event Motion detection,video tampering alarm,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error),video quality diagnosis,IP address conflict,illegal login,HDD full,HDD error
  • Smart EventLine crossing detection, intrusion detection, region entrance detection, region exiting detection,scene change detection,defocus detection
  • LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture
  • General
  • Powerreverse polarity protection,12 VDC ± 25%, 0.5 A, max. 6 W,Ø5.5 mm coaxial power plug, PoE: IEEE 802.3af, Class 3, max. 6 W
  • MaterialAluminum alloy body
  • Dimension60 mm × 60 mm × 76.9 mm (2.36" × 2.36" × 3.03")
  • Package Dimension174 mm × 111 mm × 101 mm (6.85" × 4.37" × 3.98")
  • WeightApprox. 350 g (0.77 lb.)
  • With Package WeightApprox. 557 g (1.23 lb.)
  • Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Startup and Operating Conditions-20 °C to 60 °C (-4 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
  • General FunctionHeartbeat,pixel counter,password protection,mirror
  • Approval
  • EMCCE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
  • Safety CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017
  • EnvironmentCE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specification

Camera
Image Sensor
1/2.7″ Progressive Scan CMOS
Max. Resolution
2560 × 1440
Min. Illumination
Color: 0.002 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR cut filter
Lens
Lens Type
Motorized lens, 2.8 to 8 mm
Focal Length & FOV
2.8 to 8 mm, horizontal FOV 93.2° to 48.6°, vertical FOV 50.3° to 27.3°, diagonal FOV 109.7° to 55.8°
Aperture
F1.8
Lens Mount
Ø14
Illuminator
Supplement Light Type
IR,White Light
Supplement Light Range
IR: up to 3 m White Light: up to 3 m
Smart Supplement Light
Yes
IR Wavelength
850 nm
AI Open Platform
Model Specification
Up to 1 model, Model type: detection model, classification model, mixed model (detection model and classification model)
Video
Main Stream
50Hz: 50 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60Hz: 60 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (640 × 480, 704 × 576) 60 Hz: 30 fps (640 × 480, 704 × 480)
Video Compression
Main stream: H.265/H.264, Sub-stream: H.265/H.264/MJPEG
Video Bit Rate
32 Kbps to 8 Mbps
H.264 Type
Baseline Profile,Main Profile,High Profile
H.265 Type
Main Profile
Bit Rate Control
CBR,VBR
Scalable Video Coding (SVC)
H.264 and H.265 encoding
Region of Interest (ROI)
4 fixed regions for each stream
Network
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
API
ONVIF,ISAPI,SDK,ISUP
Simultaneous Live View
Up to 6 channels
User/Host
Up to 32 users. 3 user levels: administrator, operator and user
Security
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2
Network Storage
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client
iVMS-4200, Hik-Connect, Hik-Central
Web Browser
Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+
Image Parameters Switch
Yes
Image Settings
saturation,brightness,contrast,sharpness,white balance,AGC,adjustable by client software or web browser
Day/Night Switch
Day,Night,Auto,Schedule
Wide Dynamic Range (WDR)
120 dB
Image Enhancement
BLC,HLC,3D DNR,Defog
Picture Overlay
LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
Interface
Alarm
1 input, 1 output (max. 24 VDC, 30 A)
On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
Reset Key
Yes
Event
Basic Event
Motion detection,video tampering alarm,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error),video quality diagnosis,IP address conflict,illegal login,HDD full,HDD error
Smart Event
Line crossing detection, intrusion detection, region entrance detection, region exiting detection,scene change detection,defocus detection
Linkage
Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture
General
Power
reverse polarity protection,12 VDC ± 25%, 0.5 A, max. 6 W,Ø5.5 mm coaxial power plug, PoE: IEEE 802.3af, Class 3, max. 6 W
Material
Aluminum alloy body
Dimension
60 mm × 60 mm × 76.9 mm (2.36" × 2.36" × 3.03")
Package Dimension
174 mm × 111 mm × 101 mm (6.85" × 4.37" × 3.98")
Weight
Approx. 350 g (0.77 lb.)
With Package Weight
Approx. 557 g (1.23 lb.)
Storage Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions
-20 °C to 60 °C (-4 °F to 140 °F). Humidity 95% or less (non-condensing)
Language
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function
Heartbeat,pixel counter,password protection,mirror
Approval
EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
Safety
CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017
Environment
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
For better user experience, we highly recommend you to update your device to the latest firmware asap.
Specification
Camera
  • Image Sensor1/2.7″ Progressive Scan CMOS
  • Max. Resolution2560 × 1440
  • Min. IlluminationColor: 0.002 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR
  • Shutter Time1/3 s to 1/100,000 s
  • Day & NightIR cut filter
Lens
  • Lens TypeMotorized lens, 2.8 to 8 mm
  • Focal Length & FOV2.8 to 8 mm, horizontal FOV 93.2° to 48.6°, vertical FOV 50.3° to 27.3°, diagonal FOV 109.7° to 55.8°
  • ApertureF1.8
  • Lens MountØ14
Illuminator
  • Supplement Light TypeIR,White Light
  • Supplement Light RangeIR: up to 3 m White Light: up to 3 m
  • Smart Supplement LightYes
  • IR Wavelength850 nm
AI Open Platform
  • Model SpecificationUp to 1 model, Model type: detection model, classification model, mixed model (detection model and classification model)
Video
  • Main Stream50Hz: 50 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60Hz: 60 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
  • Sub-Stream50 Hz: 25 fps (640 × 480, 704 × 576) 60 Hz: 30 fps (640 × 480, 704 × 480)
  • Video Compression Main stream: H.265/H.264, Sub-stream: H.265/H.264/MJPEG
  • Video Bit Rate32 Kbps to 8 Mbps
  • H.264 TypeBaseline Profile,Main Profile,High Profile
  • H.265 TypeMain Profile
  • Bit Rate ControlCBR,VBR
  • Scalable Video Coding (SVC)H.264 and H.265 encoding
  • Region of Interest (ROI)4 fixed regions for each stream
Network
  • ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
  • APIONVIF,ISAPI,SDK,ISUP
  • Simultaneous Live ViewUp to 6 channels
  • User/HostUp to 32 users. 3 user levels: administrator, operator and user
  • SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2
  • Network StorageNAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
  • ClientiVMS-4200, Hik-Connect, Hik-Central
  • Web BrowserPlug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+
  • Image Parameters SwitchYes
  • Image Settingssaturation,brightness,contrast,sharpness,white balance,AGC,adjustable by client software or web browser
  • Day/Night SwitchDay,Night,Auto,Schedule
  • Wide Dynamic Range (WDR)120 dB
  • Image EnhancementBLC,HLC,3D DNR,Defog
  • Picture OverlayLOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
Interface
  • Alarm 1 input, 1 output (max. 24 VDC, 30 A)
  • On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
  • Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
  • Reset KeyYes
Event
  • Basic Event Motion detection,video tampering alarm,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error),video quality diagnosis,IP address conflict,illegal login,HDD full,HDD error
  • Smart EventLine crossing detection, intrusion detection, region entrance detection, region exiting detection,scene change detection,defocus detection
  • LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture
General
  • Powerreverse polarity protection,12 VDC ± 25%, 0.5 A, max. 6 W,Ø5.5 mm coaxial power plug, PoE: IEEE 802.3af, Class 3, max. 6 W
  • MaterialAluminum alloy body
  • Dimension60 mm × 60 mm × 76.9 mm (2.36" × 2.36" × 3.03")
  • Package Dimension174 mm × 111 mm × 101 mm (6.85" × 4.37" × 3.98")
  • WeightApprox. 350 g (0.77 lb.)
  • With Package WeightApprox. 557 g (1.23 lb.)
  • Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Startup and Operating Conditions-20 °C to 60 °C (-4 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
  • General FunctionHeartbeat,pixel counter,password protection,mirror
Approval
  • EMCCE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
  • Safety CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017
  • EnvironmentCE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Resources

Technical documents

Hikvision.com uses strictly necessary cookies and related technologies to enable the website to function. With your consent, we would also like to use cookies to observe and analyse traffic levels and other metrics and tailor our website’s content. For more information on cookie practices please refer to our cookie policy.

Manage Cookies Reject all Acceptare
Acceptare
Reject all Manage Cookies
Cerere ofertă de vânzare
Cerere asistență tehnică
Serviciu online
Where to Buy
Where to Buy
Website Feedback
Contactați-ne
Hik-Partner Pro close
Hik-Partner Pro
Security Business Assistant. At Your Fingertips. Learn more
Hik-Partner Pro
Scan and download the app
Download
Hik-Partner Pro
Hik-Partner Pro

Get a better browsing experience

You are using a web browser we don’t support. Please try one of the following options to have a better experience of our web content.
