Mobile Computer

Name: Mobile Computer
Brand: Hikvision
Availability: InStock
Rating: 5.0 (1 reviews)

Support various one-dimensional codes: EAN/UPC/ISBN13/Codabar/ITF25/ITF14/Matrix25/MSI/Code39/Code93/Code128/Code11/IND25
Support various QR codes: DM/QR/MicroQR/Aztec/Hanxin/PDF417
Rear 13MP camera, Front 5MP camera
ARM octa-core 2.3GHz processor, 4GB RAM, 64GB ROM
Built-in high-sensitivity satellite positioning module, integrated with Beidou, GPS, AGPS, Glonass, and Galileo positioning
Dustproof and drop-resistant, supports 1.5m drop resistance, suitable for all-weather indoor/outdoor operations
Integrated high-performance UHF, more stable and durable

View Less

Data Sheet

Available models:

DS-MDT201/UHF/4&64/GLE

View more View Less

DS-MDT201/UHF ^NEW

Specification
Resources
Accessories

Data Sheet

Camera
Image Sensor Front camera: 5 MP; Fix-focus Rear camera: 13 MP; Auto-focus
Flashing Light Supported

Screen
Screen Size 6.0"
Screen Type IPS; Capacitive touch panel; multi-touch
Resolution 720 * 1440 pixel

Storage
CPU 8cores,2.3GHz
RAM 4 GB
ROM 64 GB
Extended Storage 1 TF card (Max. 512GB)

Wireless Network
Cellular Network GSM：B2/3/5/8 CDMA2000 ECDO：BC0 WCDMA：B1/2/4/5/8 FDD -LTE：B1/3/4/5/7/8/12/17/20/28A/28B TDD -LTE：B38/B39/B40/B41
Wi-Fi Protocol Supports IEEE 802.11 a/b/g/n/ac
Wi-Fi Frequency Band Dual-band 2.4G/5G
Bluetooth BT 5.0
Positioning Mode GPS, BeiDou, GLONASS, Galileo, AGPS
NFC Optional

Interface
Button Side Keys Volume+,Volume-,Left Scan Key, Right Scan Key,Power Button,Function Key
Keypad 3 Virtual keys+6 Side keys
SIM Card Only available for models with /GLE /5G: 2 (Nano-SIM)
Charging Interface Type C, Support OTG

General
Operating System Android 11.0
Dimension 178 * 94 * 128mm
600 g
Power DC 5V, 2A
Vibration Motor Supported
G-sensor Supported
Distance Sensor Supported
Light Sensor Supported
Geomagnetic Optional
Gyroscope Optional
Speaker Built-in single speaker; Built-in dual microphones (with noise-cancellation function)
Drop Specifications 1.5 m
Operating Condition Operating Temp: -20℃～+50℃ Humidity: 5%~95%
Storage Condition Storage Temp: -40℃～+70℃
Sealing IP65

Battery
Battery Type Rechargeable Li-ion battery; Support Hot-Swap
Capacity 6700 mAh + 100 mAh spare battery
Battery Duration Standby Time > 350H

Scanning Engine
Model Hikvision
Sensor CMOS, Global shutter
Barcode Type 1D: EAN/UPC/ISBN13/Codabar/ITF25/ITF14/Matrix25/MSI/Code39/Code93/Code128/Code11 /IND25 2D: DM(ecc200), QR, MicroQR, Aztec, Hanxin, PDF417
Decode Ranges Code 39（5 mil）： 95 mm ~ 180 mm Code 39（10 mil）： 55 mm ~ 400 mm Code 39（25 mil）： 70 mm ~ 920 mm Code 128（25 mil）： 90 mm ~ 1020 mm QR（15 mil）： 40 mm ~ 270 mm DM（10 mil）： 90 mm ~ 170 mm UPCA（10 mil）： 65 mm ~ 410 mm
Minimum reading accuracy 3 mil

UHF RFID
Read Range - 33.5m (DS-TRC900-5 (anti-metal), antenna size: 182×6mm) - 8.3m (DS-TRC900-1, antenna size: 100×30mm) - 7m (DS-TRC900-1/HTID, antenna size: 65×25×4mm) (Read range can be affected by tag and environment)
Read Rate ≥1300 tags/sec
UHF Module CM710-1, based on Impinj E710
Frequency Range 902-925MHz/902-928MHz/865-868MHz
Output Power 1W (30dBm, supporting adjustable from +5dBm to +30dBm)
Antenna Circularly polarized antenna (5 dBi)
Standards Supported ISO 18000-6C

Accessories
Standard Accessories USB cable*1, Power adapter*1

Warranty
Warranty 1 year

Camera

Image Sensor

Front camera: 5 MP; Fix-focus Rear camera: 13 MP; Auto-focus

Flashing Light

Supported

Screen

Screen Size

6.0"

Screen Type

IPS; Capacitive touch panel; multi-touch

Resolution

720 * 1440 pixel

Storage

CPU

8cores,2.3GHz

RAM

4 GB

ROM

64 GB

Extended Storage

1 TF card (Max. 512GB)

Wireless Network

Cellular Network

GSM：B2/3/5/8 CDMA2000 ECDO：BC0 WCDMA：B1/2/4/5/8 FDD -LTE：B1/3/4/5/7/8/12/17/20/28A/28B TDD -LTE：B38/B39/B40/B41

Wi-Fi Protocol

Supports IEEE 802.11 a/b/g/n/ac

Wi-Fi Frequency Band

Dual-band 2.4G/5G

Bluetooth

BT 5.0

Positioning Mode

GPS, BeiDou, GLONASS, Galileo, AGPS

NFC

Optional

Interface

Button

Side Keys Volume+,Volume-,Left Scan Key, Right Scan Key,Power Button,Function Key

Keypad

3 Virtual keys+6 Side keys

SIM Card

Only available for models with /GLE /5G: 2 (Nano-SIM)

Charging Interface

Type C, Support OTG

General

Operating System

Android 11.0

Dimension

178 * 94 * 128mm

600 g

Power

DC 5V, 2A

Vibration Motor

Supported

G-sensor

Supported

Distance Sensor

Supported

Light Sensor

Supported

Geomagnetic

Optional

Gyroscope

Optional

Speaker

Built-in single speaker; Built-in dual microphones (with noise-cancellation function)

Drop Specifications

1.5 m

Operating Condition

Operating Temp: -20℃～+50℃ Humidity: 5%~95%

Storage Condition

Storage Temp: -40℃～+70℃

Sealing

IP65

Battery

Battery Type

Rechargeable Li-ion battery; Support Hot-Swap

Capacity

6700 mAh + 100 mAh spare battery

Battery Duration

Standby Time > 350H

Scanning Engine

Model

Hikvision

Sensor

CMOS, Global shutter

Barcode Type

1D: EAN/UPC/ISBN13/Codabar/ITF25/ITF14/Matrix25/MSI/Code39/Code93/Code128/Code11 /IND25 2D: DM(ecc200), QR, MicroQR, Aztec, Hanxin, PDF417

Decode Ranges

Code 39（5 mil）： 95 mm ~ 180 mm Code 39（10 mil）： 55 mm ~ 400 mm Code 39（25 mil）： 70 mm ~ 920 mm Code 128（25 mil）： 90 mm ~ 1020 mm QR（15 mil）： 40 mm ~ 270 mm DM（10 mil）： 90 mm ~ 170 mm UPCA（10 mil）： 65 mm ~ 410 mm

Minimum reading accuracy

3 mil

UHF RFID

Read Range

- 33.5m (DS-TRC900-5 (anti-metal), antenna size: 182×6mm) - 8.3m (DS-TRC900-1, antenna size: 100×30mm) - 7m (DS-TRC900-1/HTID, antenna size: 65×25×4mm) (Read range can be affected by tag and environment)

Read Rate

≥1300 tags/sec

UHF Module

CM710-1, based on Impinj E710

Frequency Range

902-925MHz/902-928MHz/865-868MHz

Output Power

1W (30dBm, supporting adjustable from +5dBm to +30dBm)

Antenna

Circularly polarized antenna (5 dBi)

Standards Supported

ISO 18000-6C
