Interface Type
SC;FC
Transmission Distance
0~20 km
Optical Type
Single-mode and Single-fiber,9/125 μm
Input/output Wavelength
Tx1310/Rx1550nm;Tx1550/Rx1310nm
Sending Power
-14~-7dBm
Receiving Sensitivity
-32 dB
Interface
1 RJ45, 10/100BaseT(X)
Network Standard
IEEE802.3,802.3u, 802.3x
Process Mode
Storage and Forwarding
Flow Control
IEEE802.3x Full Duplex, backpressure
Priority Queue
4
MAC Address Table
2k
QoS(Qualityof Service)
Support
Exchange Capacity
12Gbps
Packet Forwarding Rate
0.3Mpps
Internal Cache
384Kbit
LED Indicator
OPT optical fiber link indicator, PWR power indicator
Cover
Metal Material, No Fan
IP level
IP40
Power Supply
12 VDC/1 A
Consumption
< 6W
Working Temperature
-30 °C ~ 70 °C (-22 °F ~ 158 °F)
Working Humidity
5~95% (No Condensation)
Weight
0.4kg (0.88lb)
Dimension (H×W×D)
138.3mm×32mm×99.5mm (5.44″×1.26″×3.92″)
Installation
DIN Industrial Rail Mounted;4U Rack-Mounted
