Pixel Package
SMD2020
Pixel Structure
1R1G1B
Pixel pitch
3.75mm
Pixel density
71111 pitch/m²
Module Resolution(W×H)
64×72
Module Dimensions (W×H)
240×270 mm
Unit Modules component (W×H)
2×1
Resolution (W×H)
128×72
Unit Dimension
480×270×56 mm
Unit Area
0.1296 m²
Weight
≤3.0 kg
Ingress protection
IP3X
Aspect ratio
16:9
Unit flatness(mm)
≤0.2
maintenance mode
Rear Access
Material
Die-cast Aluminum
Brightness(nits)
＞600
Color temperature
2000 to 10000 adjustable
Viewing angle
Horizontal 160°，vertical 160°
Recommended viewing distance
≥7 m
Center distance deviation of LED
≤3%
Brightness uniformity
≥97%
Color uniformity
≤±0.003 Cx,Cy
Contrast
≥5000：1
Max.consumption (W/m²)
400
Average consumption (W/m²)
130
Power supply
100 to 240 VAC ±15%
Driving mode
Constant current driving
Frame frequency
60 Hz
Refresh rate
1920~3840 Hz
Processing depth(bit)
16
Grey level
65536
Color
281.4 trillion
Brightness control
Auto/Manual
Working hours
≥100000h
Working temperature
-10 to 40 ℃
Storage temperature
-20 to 60℃
Working humidity
10 to 95%(non-condensing)
Storage humidity
10 to 95%(non-condensing)
