4-Wire HD Door Station

  • HD TVI video quality
  • Plug & play
  • One-press to call
  • One-press to unlock the door
  • Max 2 door stations and 3 indoor stations in one system

View Less
View more
Data Sheet
Sales Inquiry

Available models:

DS-KB2412T-IM
DS-KB2412T-IM
Data Sheet

Specification

  • Video parameters
  • FOVHorizontal: 130°，Vertical: 70°
  • Supplement lightIR light, up to 3 m
  • ResolutionStream resolution:1280 * 720@60fps
  • Audio parameters
  • Audio input1 built-in omnidirectional microphone
  • Audio output1 built-in loudspeaker
  • Device interfaces
  • Lock control1 relay, max 30V 1 A
  • Four-Wire interface1
  • General
  • Button1
  • Working temperature-30 °C to 60 °C
  • InstallationSurface mounting
  • Working humidity10% to 90% (no-condensing)
  • Dimension (W × H × D)50.94 mm × 135.94 mm × 20 mm (2" × 5.35" × 0.79")
  • Indicator/
  • Power consumption≤ 4 W
  • MaterialPlastic
  • Protective level/
  • Battery/
  • Application environmentIndoor
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specification

Video parameters
FOV
Horizontal: 130°，Vertical: 70°
Supplement light
IR light, up to 3 m
Resolution
Stream resolution:1280 * 720@60fps
Audio parameters
Audio input
1 built-in omnidirectional microphone
Audio output
1 built-in loudspeaker
Device interfaces
Lock control
1 relay, max 30V 1 A
Four-Wire interface
1
General
Button
1
Working temperature
-30 °C to 60 °C
Installation
Surface mounting
Working humidity
10% to 90% (no-condensing)
Dimension (W × H × D)
50.94 mm × 135.94 mm × 20 mm (2" × 5.35" × 0.79")
Indicator
/
Power consumption
≤ 4 W
Material
Plastic
Protective level
/
Battery
/
Application environment
Indoor
For better user experience, we highly recommend you to update your device to the latest firmware asap.
Specification
Video parameters
  • FOVHorizontal: 130°，Vertical: 70°
  • Supplement lightIR light, up to 3 m
  • ResolutionStream resolution:1280 * 720@60fps
Audio parameters
  • Audio input1 built-in omnidirectional microphone
  • Audio output1 built-in loudspeaker
Device interfaces
  • Lock control1 relay, max 30V 1 A
  • Four-Wire interface1
General
  • Button1
  • Working temperature-30 °C to 60 °C
  • InstallationSurface mounting
  • Working humidity10% to 90% (no-condensing)
  • Dimension (W × H × D)50.94 mm × 135.94 mm × 20 mm (2" × 5.35" × 0.79")
  • Indicator/
  • Power consumption≤ 4 W
  • MaterialPlastic
  • Protective level/
  • Battery/
  • Application environmentIndoor
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.
