DS-KV1101-ME2/Flush

Metal Vandal-proof 2-Wire Analog Villa Door Station

  • 2-wire plug & play, easy, cost-efficient
  • 2MP HD colorful camera
  • View in color, even in darkness
  • One-touch calling with nametag
  • IP65 water resistant, preventing from water Ingress
  • IK7 vandal resistant
  • 2 Lock relays, power supply for one electric lock(Up to 12V 1A)

Specification
  • System parameters
  • Operating systemEmbedded Analog operation system
  • ROM/
  • RAM/
  • CPU/
  • Display parameters
  • Screen size/
  • Operation method/
  • Type/
  • Resolution/
  • Video parameters
  • Supplement lightWhite light supplement
  • Video standard/
  • LensLow Illumination 2 MP HD IR Camera
  • FOVHorizontal: 100°, Vertical: 69°
  • WDRSupport
  • ResolutionMain stream : 1920 × 1080 Sub stream : 720 × 480
  • Audio parameters
  • Audio inputBuilt-in omnidirectional microphone
  • Audio compression standard/
  • Audio outputBuilt-in loudspeaker (More than 85 dB within 20 cm)
  • Audio compression bitrate/
  • Audio quality/
  • Volume adjustmentAdjustable with screwdriver
  • Capacity
  • Fingerprint capacity/
  • User capacity/
  • Face capacity/
  • Linked indoor station capacity/
  • Event capacity/
  • Network parameters
  • Communication protocol/
  • Wired network/
  • Wi-Fi/
  • Bluetooth/
  • 3G/4G/
  • Device interfaces
  • Alarm input4
  • Network interface/
  • TAMPER1
  • Exit button2
  • RS-485/
  • USB/
  • Wiegand/
  • TF card/
  • Alarm output/
  • Lock control2, locking time can be adjusted via DIP switch ( Max. 7 s)
  • Door contact input2
  • Power interface/
  • DIP switch4
  • General
  • Button1
  • InstallationFlush mounting
  • Indicator/
  • With package: 508.1 g Without package: 355.2 g
  • Protective levelIP65, IK7
  • Working temperature-30 °C to +60 °C (-22 °F to 140 °F)
  • Working humidity10% to 90%
  • Dimensions150 mm × 82 mm × 23.5 mm (5.91" × 3.23" × 0.93")
  • Battery/
  • Power supply48 VDC, 0.5 A
  • Application environmentOutdoor
  • Power consumption≤ 12 W
