5 MP PoC Motorized Varifocal Bullet Camera

  • 5 MP high performance bullet camera
  • Strong night performance, capturing images in ultra-low light down to 0.008 lux
  • 2.8-12 mm motorized vari-focal lens
  • EXIR 2.0: advanced infrared technology with 40 m IR distance
  • Water and dust resistant (IP67)
  • Transmits both HD video and power over the same coaxial cable.

Available models:

DS-2CE16H5T-IT3ZE(2.8-12mm)

Specification

  • Camera
  • Image Sensor5 MP CMOS image sensor
  • Max. Resolution2560 (H) × 1944 (V)
  • Min. IlluminationColor: 0.008 Lux @ (F1.2, AGC ON), 0 Lux with IR
  • Shutter TimePAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s
  • Day & NightIR cut filter
  • Angle AdjustmentPan: 0° to 360°; Tilt:0° to 90°; Rotate: 0° to 360°
  • Signal SystemPAL/NTSC
  • Lens
  • Lens Type2.8 mm to 12 mm motorized vari-focal lens
  • Lens MountΦ14
  • Image
  • Image SettingsBrightness, Sharpness, DNR, Mirror, Smart IR
  • Frame Rate2560 × 1944@20fps, 2560 × 1944@12.5fps 2560× 1440@30fps, 2560× 1440@25fps (default) 1920×1080@30fps, 1920×1080@25fps * Under the PoC mode, 2560 × 1944@12.5fps is not available.
  • Day/Night ModeAuto/Color/BW (Black and White)
  • Image EnhancementBLC
  • White BalanceATW/MWB
  • Interface
  • Video Output1 HD analog output
  • General
  • MaterialMetal
  • Dimension92 mm × 89 mm × 269.6 mm (3.62" × 3.5" × 10.6")
  • Approx. 900 g (1.98 lb.)
  • Operating Condition-40° C to 60° C (-40° F to 140° F), Humidity 90% or less (no condensation)
  • CommunicationUp the coax, Protocol: HIKVISION-C (TVI output)
  • LanguageEnglish, Chinese
  • Power Supply12 V DC ±25% /PoC.at
  • ConsumptionMax. 8 W
  • IR RangeUp to 40 m
  • Approval
  • ProtectionIP67

Specification

Firmware
Applied to:
DS-2CE16H5T-IT3ZE(2.8-12mm)
*For better user experience, we highly recommend you to update your device to the latest firmware asap.
