5 MP ColorVu PoC Fixed Turret Camera

  • High quality imaging with 5 MP, 2560 × 1944 resolution
  • 24/7 color imaging
  • Clear imaging against strong back light due to 130 dB true WDR technology
  • 3D DNR technology delivers clean and sharp images
  • 2.8 mm, 3.6 mm fixed focal lens
  • Smart Light, up to 20 m white light distance
  • Water and dust resistant (IP67)

View Less
View more

Available models:

DS-2CE72HFT-E(2.8mm)
DS-2CE72HFT-E(3.6mm)

Specification

  • Camera
  • Image Sensor5 MP CMOS
  • Max. Resolution2560 (H) × 1944 (V)
  • Min. Illumination0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
  • Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
  • Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
  • Signal SystemPAL/NTSC
  • Lens
  • Lens Type2.8 mm, 3.6 mm fixed focal lens
  • Focal Length & FOV2.8 mm, horizontal FOV: 99.7°, vertical FOV: 72°, diagonal FOV: 139.8° 3.6 mm, horizontal FOV: 80.1°, vertical FOV: 58.6°, diagonal FOV: 106.2°
  • Lens MountM16
  • Illuminator
  • Supplement Light TypeWhite Light
  • Supplement Light RangeUp to 20 m
  • Smart Supplement LightYes
  • Image
  • Image Parameters SwitchSTD/HIGH-SAT
  • Image SettingsBrightness;Sharpness;Mirror;AGC;Anti-Banding
  • Frame Rate5 MP @ 20 fps, 4 MP @ 30 fps, 4 MP @ 25 fps, 1080p @ 30 fps, 1080p @ 25 fps
  • Day/Night ModeColor
  • Wide Dynamic Range (WDR)≥130 dB
  • Image EnhancementBLC;HLC;Global;HLS
  • Noise Reduction3D DNR/2D DNR
  • White BalanceAuto/Manual
  • Interface
  • Video Output1 HD analog output
  • AlarmSolid Light Alarm (White Light)
