RS485 to Wiegand Module

  • RS-485 to Wiegand module
  • Suitable for connection between DS-K5603 series and third party barriers
View Less
View more

Available models:

DS-K1101M

Specification

  • System Parameters
  • Processor32-bit
  • Device Interface
  • Input / Output InterfaceRS-485/Wiegand
  • General
  • Power supply12 VDC
  • Working current≤ 500 mA
  • Working temperature-20 °C to 65 °C (-4 °F to 149 °F)
  • Working humidity10% to 90% (Non Condensing)
  • Protection LevelIP64
  • Dimensions132.0 mm × 92.3 mm × 20.5 mm (5.20" × 3.63" × 0.81")
  • Weight≤ 0.14 kg (4.94 oz)

Specification

Specification
System Parameters
  • Processor32-bit
Device Interface
  • Input / Output InterfaceRS-485/Wiegand
General
  • Power supply12 VDC
  • Working current≤ 500 mA
  • Working temperature-20 °C to 65 °C (-4 °F to 149 °F)
  • Working humidity10% to 90% (Non Condensing)
  • Protection LevelIP64
  • Dimensions132.0 mm × 92.3 mm × 20.5 mm (5.20" × 3.63" × 0.81")
  • Weight≤ 0.14 kg (4.94 oz)

Download Center

Firmware

Applied to:
DS-K1101M
For better user experience, we highly recommend you to update your device to the latest firmware asap.
