Backup UPS

Built-in AVR
Super fast charging
Wide input voltage range
Overload protection
Short circuit protection
Surge protection

View Less

Available models:

DS-UPS2000-Q/T

Specification
Resources
Accessories

Power
UPS Capacity 2000 VA / 1200 W

Input
Input Voltage Range 145 VAC to 280VAC ±5VAC;70 VAC to 145 VAC ±5VAC
Input Frequency 50/60 Hz self-adaptive
Plug Type UK BS1363;Type B (NEMA 5-15)

Output
Output Frequency 50/60 Hz self-adaptive
Transfer Time typical 2-6 ms, 10 ms max
Waveform Simulated Sine Wave
Output Voltage Range 198VAC to 242VAC;99VAC to 121VAC
Outlet Type Universal;Type B (NEMA 5-15)
Outlet Number 4;4+4bypass

Battery
Battery Type 12 V/9 Ah *2 pcs, lead-acid battery
Recharge Time 4-6 hours recover to 90% capacity
Typical Backup Time Run time at 60w: 116 min Run time at 150w: 44 min Run time at 300w: 20 min

Interface
Communicate Ports No

Protection
Full Protection Surge protection, Overload protection, Discharge protection, Short circuit protection

Indicator
Display LCD Screen Input Voltage, Output Voltage, Battery capacity, load level
Alarm Charging Mode (DC mode): Sounding every 6 seconds Low Battery: Sounding every second Overloading Mode: Sounding every 0.5 seconds Fault: Continuously sounding

General
Operating Temperature 0 °C to 40 °C (32 °F to 104 °F）
Operating Humidity 0% to 90% (non-condensing)
Dimension 360 mm × 122 mm × 195 mm (14.17" × 4.80" × 7.68")
Weight Approx. 12.4 kg (27.3 lb)

Power

UPS Capacity

2000 VA / 1200 W

Input

Input Voltage Range

145 VAC to 280VAC ±5VAC

Input Frequency

50/60 Hz self-adaptive

Plug Type

UK version: UK TYPE G plug EU version: Schuko plug

Output

Output Frequency

50 Hz /60HZ± 1 Hz（Automatic Identification ）

Transfer Time

typical 2-6 ms, 10 ms max

Waveform

Simulated Sine Wave

Output Voltage Range

198VAC to 242VAC

Outlet Type

Universal

Outlet Number

Battery

Battery Type

12 V/9 Ah *2 pcs, lead-acid battery

Recharge Time

4-6 hours recover to 90% capacity

Typical Backup Time

Run time at 60w: 116 min Run time at 150w: 44 min Run time at 300w: 20 min

Interface

Communicate Ports

Protection

Full Protection

Surge protection, Overload protection, Discharge protection, Short circuit protection

Indicator

Display

LCD Screen Input Voltage, Output Voltage, Battery capacity, load level

Alarm

Charging Mode (DC mode): Sounding every 6 seconds Low Battery: Sounding every second Overloading Mode: Sounding every 0.5 seconds Fault: Continuously sounding

General

Operating Temperature

0 °C to 40 °C (32 °F to 104 °F）

Operating Humidity

0% to 90% (non-condensing)

Dimension

360 mm × 122 mm × 195 mm (14.17" × 4.80" × 7.68")

Weight

Approx. 12.4 kg (27.3 lb)
