Hik-ProConnect Box

Cloud Storage
Up to 8-ch cloud storage with Hikvision cameras or DVRs/NVRs
Cloud storage videos support ANR (Automatic Network Replenishment)
Hik-Partner Pro Platform
Manageable by Hik-Partner Pro platform
Cloud storage videos support remote playback

View Less

Ficha Técnica

Modelos disponibles:

DS-6700NI-S

Especificación
Resources
Accesorios

Ficha Técnica

Parámetro del sistema
Canal de reenvío de video8-ch

Video and Audio
Entrada de vídeo IP8-ch
Incoming Bandwidth80 Mbps
Outgoing Bandwidth80 Mbps

Descodificación
Formato de decodificaciónH.265, H.265+, H.264, H.264+
Decodificación8-ch@1080p (30 fps) *: The total resolution of all cloud storage video channels cannot exceed 8 × 1080p (fps).
Stream TypeVideo, Video & Audio

Codificación
Video Encoding Resolution1080p/720p
Encoding Capability2-ch@1080p (30 fps)
Frame Rate5-ch@1080p (10 fps), 6-ch@1080p (8 fps), 7-ch@1080p (7 fps), 8-ch@1080p (6 fps) *: 5-ch/6-ch/7-ch/8-ch is the total number of channels for uploading cloud storage videos.

Red
Protocolo de redIPv4, IPv6, HTTP, HTTPS, NTP, SADP, DHCP
Interfaz de red1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

Auxiliary Interface
Salida de potencia12 VDC, 1A

General
Consumo≤ 6 W
Temperatura de trabajo-10℃ to 55℃ (32 °F to 122 °F)
Condiciones de Humedad10％ to 90％
Dimensión (W × D × H)92 × 93 × 45.8 mm (3.6 × 3.7 × 1.8 inch)
≤ 0.5 kg (1.1 lb)

Parámetro del sistema

Canal de reenvío de video

8-ch

Video and Audio

Entrada de vídeo IP

8-ch

Incoming Bandwidth

80 Mbps

Outgoing Bandwidth

80 Mbps

Descodificación

Formato de decodificación

H.265, H.265+, H.264, H.264+

Decodificación

8-ch@1080p (30 fps) *: The total resolution of all cloud storage video channels cannot exceed 8 × 1080p (fps).

Stream Type

Video, Video & Audio

Codificación

Video Encoding Resolution

1080p/720p

Encoding Capability

2-ch@1080p (30 fps)

Frame Rate

5-ch@1080p (10 fps), 6-ch@1080p (8 fps), 7-ch@1080p (7 fps), 8-ch@1080p (6 fps) *: 5-ch/6-ch/7-ch/8-ch is the total number of channels for uploading cloud storage videos.

Red

Protocolo de red

IPv4, IPv6, HTTP, HTTPS, NTP, SADP, DHCP

Interfaz de red

1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

Auxiliary Interface

Salida de potencia

12 VDC, 1A

General

Consumo

≤ 6 W

Temperatura de trabajo

-10℃ to 55℃ (32 °F to 122 °F)

Condiciones de Humedad

10％ to 90％

Dimensión (W × D × H)

92 × 93 × 45.8 mm (3.6 × 3.7 × 1.8 inch)

≤ 0.5 kg (1.1 lb)

Parámetro del sistema

Canal de reenvío de video8-ch

Video and Audio

Entrada de vídeo IP8-ch
Incoming Bandwidth80 Mbps
Outgoing Bandwidth80 Mbps

Descodificación

Formato de decodificaciónH.265, H.265+, H.264, H.264+
Decodificación8-ch@1080p (30 fps) *: The total resolution of all cloud storage video channels cannot exceed 8 × 1080p (fps).
Stream TypeVideo, Video & Audio

Codificación

Video Encoding Resolution1080p/720p
Encoding Capability2-ch@1080p (30 fps)
Frame Rate5-ch@1080p (10 fps), 6-ch@1080p (8 fps), 7-ch@1080p (7 fps), 8-ch@1080p (6 fps) *: 5-ch/6-ch/7-ch/8-ch is the total number of channels for uploading cloud storage videos.

Red
