6MP DeepinView Moto Varifocal Bullet Camera

High quality imaging with 6 MP resolution
25 × optical zoom captures details in remote area
Clear imaging against strong back light due to 140 dB WDR technology
Efficient H.265+ compression technology to save bandwidth and storage
Built-in heater on the front viewing window to ensure clear image under snowy weather
Built-in gyroscope to ensure stable image output
Water and dust resistant (IP67) and vandal proof (IK10)

View Less

Ficha Técnica

iDS-2CD7A45G0-IZ(H)S(Y)UVS

Especificación
Resources
Accesorios

Ficha Técnica

Cámara
Sensor de imagen1/2.0" Progressive Scan CMOS
Max. Resolución3072 × 2048
Iluminación mínimaColor: 0.009 Lux @ (F1.5, AGC ON), B/W: 0.0018 Lux @ (F1.5, AGC ON), 0 Lux with IR
Tiempo de obturación2 s to 1/100,000 s
Día y NocheIR cut filter
Ajuste de ánguloPan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 360°

Lente
Focal Length & FOV4.7 to 118 mm, horizontal FOV 58° to 2.8°, vertical FOV 32.3° to 1.6°, diagonal FOV 63° to 3°
EnfoqueAuto, semi-auto, manual
Iris TypeP-iris
Apertura4.7 to 118 mm: F1.5 to F3.8

DORI
DORIWide: D: 106 m, O: 42.1 m, R: 21.2 m, I: 10.6 m Tele: D: 2200 m, O: 873 m, R: 440 m, I: 220 m

Iluminador
Tipo de luz suplementariaIR
Rango de luz suplementariaUp to 200 m
Luz de suplemento inteligenteYes
IR Wavelength850 nm

Vídeo
Main stream50 Hz: 25 fps (3072 × 2048, 2560 × 1440, 1920 × 1080, 1280 × 720) 50 fps (2560 × 1440, 1920 × 1080, 1280 × 720)60 Hz: 30 fps (3072 × 2048, 2560 × 1440, 1920 × 1080, 1280 × 720) 60 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-stream50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480)
Third Stream50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480)
Fifth Stream50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480)
Compresión de videoMain stream: H.265+/H.265/H.264+/H.264 Sub-stream/Fourth stream/Fifth stream: H.265/H.264/MJPEG Third stream: H.265/H.264
Vídeo bitrate32 Kbps to 8 Mbps
H.264 Type (MPEG-4 Part10/AVC)Baseline Profile/Main Profile/High Profile
H.265 Type (MPEG-H Part 2)Main Profile
Bit Rate ControlCBR/VBR
Codificación de video escalable (SVC)H.264 and H.265 encoding
Región de interés (ROI)4 fixed regions for each stream
Recorte objetivoYes
e-PTZSupports Patrol and Auto-tracking settings

Audio
Velocidad de bits de audio64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC)/8 to 320 Kbps (MP3)
Compresión de audioG.711/G.722.1/G.726/MP2L2/PCM/AAC/MP3
Tipo de audioMono sound
Filtro de ruido ambientalYes
Frecuencia de muestreo de audio8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHz

Red
ProtocolosTCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Vista en vivo simultáneaUp to 20 channels
APIOpen Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP
Usuario/operadorUp to 32 users 3 user levels: administrator, operator, and user
SeguridadPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2
Almacenamiento en redNAS (NFS, SMB/CIFS), auto network replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
ClienteiVMS-4200, Hik-Connect, Hik-Central
Navegador webPlug-in required live view: IE10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 12+ Local service: Chrome 57.0+, Firefox 52.0+

Imagen
Interruptor de parámetros de imagenYes
Configuración de imagenSaturation, brightness, contrast, sharpness, white balance, and AGC adjustable by client software or web browser
Interruptor día/nocheDay, Night, Auto, Schedule
Wide Dynamic Range (WDR)140 dB
Mejora de la imagenBLC, HLC, Defog, 3D DNR
SNR≥ 52 dB
Máscara de privacidad8 programmable polygon privacy masks, mask color or mosaic configurable
Image StabilizationEIS (Built-in gyroscope to improve EIS performance)
Superposición de imagenLOGO picture can be overlaid on video with 128 × 128 24bit bmp format

Interfaz
Salida de Vídeo1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)
Ethernet Interface1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Audio1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium
Alarma2 inputs, 2 outputs (max. 24 VDC, 1 A)
RS-485With -Y: 1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Reset KeyYes
Salida de alimentaciónWith -Y: 12 VDC, max. 100 mA

Evento
Evento BásicoMotion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception (network disconnected, IP address conflict, illegal login, abnormal reboot, HDD full, HDD error), video quality diagnosis, vibration detection
Evento inteligenteLine crossing detection, intrusion detection, region entrance, region exiting (support alarm triggering by specified target types (human and vehicle)) Scene change detection, audio exception detection, defocus detection
LinkageUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture

Deep Learning Function
Detección de tipo multi-objetivoDetects up to 60 taregets simultaneously Supports simultaneous detection and capture of human body, face and vehicle Gets 7 face features, 13 human body features and 2 vehicle features
Captura de la cara1. Detects up to 60 faces simultaneously 2. Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30° 3. Uploads face with background and closed-up face pictures
Comparación de rostrosUp to 10 face libraries. Up to 30,000 faces for each library. 150,000 faces in total. Supports face library encryption

General
alimentación-IZHSY: 12 VDC ± 20%, 1.73 A, max. 20.7 W, three-core terminal block 24 VAC ± 20%, 1.31 A, max. 19.9 W, three-core terminal block PoE: 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.46 A to 0.35 A, max. 19.5 W -IZHS: 12 VDC ± 20%, 1.62 A, max. 19.4 W, two-core terminal block 24 VAC ± 20%, 1.21 A, max. 18.7 W, two-core terminal block PoE: 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.43 A to 0.32 A, max. 18.2 W -IZSY: 12 VDC ± 20%, 1.13 A, max. 13.48 W, three-core terminal block 24 VAC ± 20%, 0.89 A, max. 12.14 W, three-core terminal block PoE: 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.22 A to 0.29 A, max. 12.29 W -IZS: 12 VDC ± 20%, 1.02 A, max. 12.22 W, two-core terminal block 24 VAC ± 20%, 0.8 A, max. 11.49 W, two-core terminal block PoE: 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.20 A to 0.26 A, max. 10.50 W
DimensiónWith -Y: Ø140 mm × 378.4 mm (Ø5.5" × 14.9") Without -Y: Ø144.1 mm × 375.2 mm (Ø5.7" × 14.8")
Dimensión del paquete425 mm × 190 mm × 180 mm (16.7" × 7.5" × 7.1")
With -Y: Approx. 2160 g (4.8 lb.) Without -Y: Approx. 2130 g (4.7 lb.)
Con peso del paqueteWith -Y: Approx. 3310 g (7.3 lb.) Without -Y: Approx. 3200 g (7.1 lb.)
Condiciones de almacenajeWithout -H: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) With -H: -40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
Condiciones de inicio y funcionamiento-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
Idioma33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
Función general5 streams, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
CalentadorYes
DeshieloYes

Certificaciones
EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EEN 61000-3-3:2013+A1:2019, EN 50130-4: 2011+A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 7); KC (KN 32: 2015, KN 35: 2015)
SeguridadUL (UL 62368-1); CB (IEC 62368-1:2014+A11); CE-LVD (EN 62368-1:2014/A11:2017); BIS (IS 13252(Part 1):2010/ IEC 60950-1 : 2005); LOA (IEC/EN 60950-1)
AmbienteCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
ProtecciónIK10 (IEC 62262:2002), IP67 (IEC 60529-2013)
Protección anticorrosivaWith -Y: NEMA 4X(NEMA 250-2018)
OtrosPVC FREE
