Thermal Monocular

  • 384 x 288 resolution with 12μm sensor
  • High sensitivity thermal module NETD < 20 mK (@25° C, F#=1.0)
  • Replaceable and rechargeable Li-ion battery
  • Up to 7 hours continuous operation
  • Leading thermal image processing technology: Image Pro
  • 1024 x 768 resolution 0.39-inch OLED display

View Less
View more
Data Sheet
Sales Inquiry

Available models:

HM-TS43-35XG/W-FH35
FH35
Data Sheet

Specification

  • Thermal Module
  • Image SensorVOx Uncooled Focal Plane Arrays
  • Resolution384×288
  • Frame Rate50Hz
  • Pixel Interval12μm
  • Response Waveband8μm to 14μm
  • NETDLess than 20 mK (@25°C),F#=1.0
  • Focal Length35mm
  • ApertureF1.0
  • Min. Focusing Distance3.5m
  • Digital Zoom1×，2×，4×，8×
  • Field of View(H × V), Degrees / m @100m7.53°×5.65°/13.2m×9.9m
  • Optical Magnification3.03
  • Detection Range1800m
  • Image Display
  • Monitor 0.39 inch, OLED, 1024 ×768
  • PalettesBlack Hot, White Hot, Red Hot, Fusion
  • FFC (Flat Field Correction) ModeAuto,Manual,External Correction
  • System
  • StorageBuilt-in memory module (64 GB)
  • Record VideoYes
  • Capture SnapshotYes
  • Standby ModeYes
  • HotspotYes
  • Hot TrackYes
  • Power Supply
  • Power5V，1.5W
  • Battery TypeReplaceable and Rechargeable Li-ion Battery
  • Battery Operating Time7 hours continuous running with CVBS and hotspot function off (@25°C)
  • General
  • Work Temperature/HumidityFrom -30°C to 55°C (-22°F to 131°F); Humidity: 90% or Less
  • Protection LevelIP67
  • Dimension190.3 mm × 58.3 mm × 65.2 mm (7.49" × 2.29" × 2.57")
  • Weight505g (1.11 lb)
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specification

Thermal Module
Image Sensor
VOx Uncooled Focal Plane Arrays
Resolution
384×288
Frame Rate
50Hz
Pixel Interval
12μm
Response Waveband
8μm to 14μm
NETD
Less than 20 mK (@25°C),F#=1.0
Focal Length
35mm
Aperture
F1.0
Min. Focusing Distance
3.5m
Digital Zoom
1×，2×，4×，8×
Field of View(H × V), Degrees / m @100m
7.53°×5.65°/13.2m×9.9m
Optical Magnification
3.03
Detection Range
1800m
Image Display
Monitor
0.39 inch, OLED, 1024 ×768
Palettes
Black Hot, White Hot, Red Hot, Fusion
FFC (Flat Field Correction) Mode
Auto,Manual,External Correction
System
Storage
Built-in memory module (64 GB)
Record Video
Yes
Capture Snapshot
Yes
Standby Mode
Yes
Hotspot
Yes
Hot Track
Yes
Power Supply
Power
5V，1.5W
Battery Type
Replaceable and Rechargeable Li-ion Battery
Battery Operating Time
7 hours continuous running with CVBS and hotspot function off (@25°C)
General
Work Temperature/Humidity
From -30°C to 55°C (-22°F to 131°F); Humidity: 90% or Less
Protection Level
IP67
Dimension
190.3 mm × 58.3 mm × 65.2 mm (7.49" × 2.29" × 2.57")
Weight
505g (1.11 lb)
For better user experience, we highly recommend you to update your device to the latest firmware asap.
Specification
Thermal Module
  • Image SensorVOx Uncooled Focal Plane Arrays
  • Resolution384×288
  • Frame Rate50Hz
  • Pixel Interval12μm
  • Response Waveband8μm to 14μm
  • NETDLess than 20 mK (@25°C),F#=1.0
  • Focal Length35mm
  • ApertureF1.0
  • Min. Focusing Distance3.5m
  • Digital Zoom1×，2×，4×，8×
  • Field of View(H × V), Degrees / m @100m7.53°×5.65°/13.2m×9.9m
  • Optical Magnification3.03
  • Detection Range1800m
Image Display
  • Monitor 0.39 inch, OLED, 1024 ×768
  • PalettesBlack Hot, White Hot, Red Hot, Fusion
  • FFC (Flat Field Correction) ModeAuto,Manual,External Correction
System
  • StorageBuilt-in memory module (64 GB)
  • Record VideoYes
  • Capture SnapshotYes
  • Standby ModeYes
  • HotspotYes
  • Hot TrackYes
Power Supply
  • Power5V，1.5W
  • Battery TypeReplaceable and Rechargeable Li-ion Battery
  • Battery Operating Time7 hours continuous running with CVBS and hotspot function off (@25°C)
General
  • Work Temperature/HumidityFrom -30°C to 55°C (-22°F to 131°F); Humidity: 90% or Less
  • Protection LevelIP67
  • Dimension190.3 mm × 58.3 mm × 65.2 mm (7.49" × 2.29" × 2.57")
  • Weight505g (1.11 lb)
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Resources

For better user experience, we highly recommend you to update your device to the latest firmware asap.
Firmware_V5.5.85_240425
