DS-2CD3543G2-IS


    4 MP Acusense Fixed Mini Dome Network Camera

    • High quality imaging with 4 MP resolution
    • Clear imaging against strong backlight due to 120 dB WDR technology
    • Efficient H.265+ compression technology
    • Focus on human and vehicle targets classification based on deep learning
    • Audio and alarm interface available
    • Water and dust resistant (IP67) and vandal resistant (IK08)

    View Less
    View more

    Available models:

    DS-2CD3543G2-IS(4mm)
    DS-2CD3543G2-IS(2.8mm)

    Specification

    • กล้อง
    • Image Sensor1/2.8" Progressive Scan CMOS
    • Max. Resolution1920 × 1080
    • Min. IlluminationColor: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
    • Shutter Time1/3 s to 1/100,000 s
    • Day & NightIR cut filter
    • Angle AdjustmentPan: -30° to 30°,tilt: 0° to 75°,rotate: 0° to 360°
    • Lens
    • Lens TypeFixed focal lens, 2.8 and 4 mm optional
    • Focal Length & FOV2.8 mm, horizontal FOV 108°, vertical FOV 59°, diagonal FOV 127° 4 mm, horizontal FOV 86°, vertical FOV 47°, diagonal FOV 100°
    • Lens MountM12
    • Iris TypeFixed
    • ApertureF1.6
    • Depth of Field2.8 mm: 1 m to ∞ 4 mm: 1.1 m to ∞
    • DORI
    • DORI2.8 mm: D: 42 m, O: 17 m, R: 8 m, I: 4 m 4 mm: D: 54 m, O: 21 m, R: 11 m, I: 5 m
    • Illuminator
    • Supplement Light TypeIR
    • Supplement Light RangeUp to 30 m
    • Smart Supplement LightYes
    • IR Wavelength850 nm
    • Video
    • Main Stream50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
    • Sub-Stream50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
    • Third Stream50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360), *Third stream is supported under certain settings.
    • Video Compression Main stream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
    • Video Bit Rate32 Kbps to 8 Mbps
    • H.264 TypeBaseline Profile,Main Profile,High Profile
    • H.265 TypeMain Profile
    • Bit Rate ControlCBR,VBR
    • Scalable Video Coding (SVC)H.264 and H.265 encoding
    • Region of Interest (ROI)1 fixed region(s) for main stream and sub-stream
    • Audio
    • Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
    • Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
    • Audio Sampling Rate8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
    • Environment Noise FilteringYes
    • Network
    • ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
    • Simultaneous Live ViewUp to 6 channels
    • APIOpen Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
    • User/HostUp to 32 users 3 user levels: administrator, operator, and user
    • SecurityPassword protection, complicated pass
