THC-B227-LMS


    2MP Dual Light Audio Fixed Bullet Camera

    • High quality imaging with 2 MP, 1920 × 1080 resolution
    • 2.8 mm, 3.6 mm fixed focal lens
    • Up to 40 m IR distance for bright night imaging
    • Up to 40 m white light distance for bright night imaging
    • One port for four switchable signals (TVI/AHD/CVI/CVBS）
    • Water and dust resistant (IP66)
    • High quality audio with audio over coaxial cable, built-in microphone
    • Smart-Hybrid light, optimize your security with flexible lighting options

    View Less
    View more

    Available models:

    THC-B227-LMS(2.8mm)(HiLook STD)
    THC-B227-LMS(3.6mm)(HiLook STD)
    THC-B227-LMS(6mm)(HiLook STD)

    Specification

    • กล้อง
    • Image Sensor2 MP CMOS
    • Max. Resolution1920 (H) × 1080 (V)
    • Min. Illumination0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR
    • Shutter TimePAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
    • Day & NightICR
    • Angle AdjustmentPan: 0 to 360°, tilt: 0 to 180°, rotate: 0 to 360°
    • Signal SystemPAL/NTSC
    • Lens
    • Lens TypeFixed focal lens, 2.8 mm, 3.6 mm and 6 mm optional
    • Focal Length & FOV2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118° 3.6 mm, horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 92° 6 mm, horizontal FOV: 50°, vertical FOV:27 °, diagonal FOV: 58°
    • Lens MountM12
    • Illuminator
    • Supplement Light TypeWhite Light;IR
    • Supplement Light RangeIR : up to 40 m White Light : up to 40 m
    • Image
    • Image SettingsBrightness, Sharpness, Smart IR
    • Frame RateTVI: 1080P @30 fps, 1080P @25 fps AHD: 1080P @30 fps, 1080P@25 fps CVI: 1080P @30 fps, 1080P @25 fps CVBS: PAL/NTSC
    • Day/Night ModeAuto/Color/BW (Black and White)
    • Wide Dynamic Range (WDR)Digital WDR
    • Image EnhancementDWDR/BLC/HLC/Global
    • White BalanceAuto/Manual
    • AGCYes
    • Interface
    • Video OutputSwitchable TVI/AHD/CVI/CVBS
    • Built-in MicrophoneYes
    • General
    • MaterialFront cover: metal Main body: metal
    • Dimension223.3 mm × 75.4 mm × 87.3 mm (8.79" × 2.97" × 3.44")
    • WeightApprox. 569 g (0.56 lb)
    • Operating Condition-40 °C to 60 °C (-40 °F to 140 °F). Humidity: 90% or less (non-condensation)
    • CommunicationHIKVISION-C
    • LanguageEnglish
    • Power Supply12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera.
    • ConsumptionMax. 3.2 W
    • Approval
    • ProtectionIP66
    *Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

    Specification

    กล้อง
    Image Sensor
    2 MP CMOS
    Max. Resolution
    1920 (H) × 1080 (V)
    Min. Illumination
    0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR
    Shutter Time
    PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
    Day & Night
    ICR
    Angle Adjustment
    Pan: 0 to 360°, tilt: 0 to 180°, rotate: 0 to 360°
    Signal System
    PAL/NTSC
    Lens
    Lens Type
    Fixed focal lens, 2.8 mm, 3.6 mm and 6 mm optional
    Focal Length & FOV
    2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118° 3.6 mm, horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 92° 6 mm, horizontal FOV: 50°, vertical FOV:27 °, diagonal FOV: 58°
    Lens Mount
    M12
    Illuminator
    Supplement Light Type
    White Light;IR
    Supplement Light Range
    IR : up to 40 m White Light : up to 40 m
    Image Settings
    Brightness, Sharpness, Smart IR
    Frame Rate
    TVI: 1080P @30 fps, 1080P @25 fps AHD: 1080P @30 fps, 1080P@25 fps CVI: 1080P @30 fps, 1080P @25 fps CVBS: PAL/NTSC
    Day/Night Mode
    Auto/Color/BW (Black and White)
    Wide Dynamic Range (WDR)
    Digital WDR
    Image Enhancement
    DWDR/BLC/HLC/Global
    White Balance
    Auto/Manual
    AGC
    Yes
    Interface
    Video Output
