4 MP MD 2.0 Fixed Dome Network Camera

  • High quality imaging with 4 MP resolution
  • Support Human and Vehicle Detection
  • Water and dust resistant (IP67) and vandal resistant (IK10)
  • Clear imaging against strong back light due to 120 dB true WDR technology
  • Efficient H.265+ compression technology to save bandwidth and storage
  • Easy installation with Power over Ethernet (PoE) technology

View Less
View more

Available models:

IPC-D140HA(2.8mm)(HiLookSTD)
IPC-D140HA(4mm)(HiLookSTD)
Specification
  • กล้อง
  • Image Sensor 1/3" Progressive Scan CMOS
  • Max. Resolution 2560 × 1440
  • Min. Illumination Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR
  • Shutter Time 1/3 s to 1/100,000 s
  • Day & Night IR cut filter
  • Angle Adjustment Pan: 0° to 355°, tilt: 0° to 75°
  • Lens
  • Lens Type Fixed focal lens, 2.8 and 4 mm optional
  • Focal Length & FOV 2.8 mm, horizontal FOV 99°, vertical FOV 55°, diagonal FOV 116° 4 mm, horizontal FOV 76°, vertical FOV 41°, diagonal FOV 90°
  • Lens Mount M12
  • Iris Type Fixed
  • Aperture F2.0
  • DORI
  • DORI 2.8 mm, D: 59 m, O: 23 m, R: 11 m, I: 5 m 4 mm, D: 79 m, O: 31 m, R: 15 m, I: 7 m
  • Illuminator
  • Supplement Light Type IR
  • Supplement Light Range Up to 30 m
  • Smart Supplement Light Yes
  • IR Wavelength 850 nm
  • Video
  • Main Stream 50 Hz: 20 fps (2560 × 1440) 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440) 24 fps (1920 × 1080, 1280 × 720)
  • Sub-Stream 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)
  • Video Compression Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG
  • Video Bit Rate 32 Kbps to 8 Mbps
  • H.264 Type Baseline Profile, Main Profile, High Profile
  • H.265 Type Main Profile
  • Bit Rate Control CBR/VBR
  • Region of Interest (ROI) 1 fixed region for main stream
  • Network
  • Security Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
  • Simultaneous Live View Up to 6 channels
  • API Open Network Video Interface (Profile S, Profile T), ISAPI, SDK
  • Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
  • User/Host Up to 32 users 3 levels: administrator, operator and user
  • Client iVMS-4200, HiLookVision
  • Web Browser Plug-in required live view: IE 10, IE 11 Local service: Chrome 57.0+, Firefox 52.0+
  • Image
  • Wide Dynamic Range (WDR) 120 dB
  • SNR ≥ 52 dB
  • Day/Night Switch Day, Night, Auto, Schedule
  • Image Enhancement BLC, HLC, 3D DNR
  • Image Settings Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
  • Privacy Mask 4 programmable polygon privacy masks
  • Interface
  • Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
  • Event
  • Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
  • Linkage Upload to FTP, notify surveillance center, trigger capture, send email
  • General
  • Power 12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W
  • Material Metal & Plastic
  • Dimension Ø110.8 mm × 84.7 mm (4.4" × 3.3")
  • Package Dimension 134 mm × 134 mm × 108 mm (5.3" × 5.3" × 4.3")
  • Weight Approx. 520 g (1.1 lb.)
