2 MP ColorVu Audio Fixed Bullet Camera

  • High quality imaging with 2 MP, 1920 × 1080 resolution
  • 24/7 color imaging with F1.0 aperture
  • Clear imaging against strong back light due to 130 dB true WDR technology
  • 3D DNR technology delivers clean and sharp images
  • 2.8 mm, 3.6 mm, 6 mm fixed focal lens
  • Up to 40 m white light distance for bright night imaging
  • High quality audio with audio over coaxial cable, built-in mic
  • One port for four switchable signals (TVI/AHD/CVI/CVBS)
  • Water and dust resistant (IP67)

View Less
View more

Available models:

DS-2CE12DF8T-FSLN(2.8mm)
DS-2CE12DF8T-FSLN(3.6mm)

Specification

  • Camera
  • Image Sensor2 MP CMOS
  • Max. Resolution1920 (H) × 1080 (V)
  • Min. Illumination0.0003 Lux @ (F1.0, AGC ON), 0 Lux with white light
  • Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
  • Day & Night24/7 Color Imaging
  • Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
  • Signal SystemPAL/NTSC
  • Slow ShutterMax. 16 times
  • Light AlarmSolid Light Alarm (White Light)
  • Lens
  • Lens Type2.8 mm, 3.6 mm, 6 mm fixed focal lens
  • Focal Length & FOV2.8 mm, horizontal FOV: 106°, vertical FOV: 56°, diagonal FOV: 129° 3.6 mm, horizontal FOV: 83°, vertical FOV: 44°, diagonal FOV: 100° 6 mm, horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 64°
  • Lens MountM12
  • Illuminator
  • Supplement Light TypeWhite Light
  • Supplement Light RangeUp to 40 m
  • Smart Supplement LightYes
  • Image
  • Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
  • Image SettingsBrightness, Contrast, Mirror, Sharpness, Anti-Banding, AGC
  • Frame RateTVI: 1080p @ 25 fps/30 fps CVI: 1080p @ 25 fps/30 fps AHD: 1080p @ 25 fps/30 fps CVBS: PAL/NTSC
  • Day/Night ModeColor
  • Wide Dynamic Range (WDR)≥130 dB
  • Image EnhancementBLC, HLC, Global, HLS
  • Privacy Mask4 programmable privacy masks
  • Noise Reduction3D DNR/2D DNR
  • White BalanceAuto
  • Interface
  • Video OutputSwitchable TVI/AHD/CVI/CVBS
  • AudioLine-in
  • Built-in MicrophoneYes
  • Event
  • Motion Detection4 programmable motion areas
  • General
  • Power12 VDC ± 25%, max. 6.3 W *You are recommended to use one power adapter to supply the power for one camera.
  • MaterialMetal
  • Dimension194.2 mm × 78 mm × 74.5 mm (7.65" × 3.07" × 2.93")
  • WeightApprox. 527 g (1.16 lb.)
  • Operating Condition-40°C to 50°C (-40°F to 122°F), Humidity: 90% or less (non-condensing)
  • CommunicationHIKVISION-C
  • LanguageEnglish
  • Approval
  • ProtectionIP67
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specification

Camera
Image Sensor
2 MP CMOS
Max. Resolution
1920 (H) × 1080 (V)
Min. Illumination
0.0003 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time
PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Day & Night
24/7 Color Imaging
Angle Adjustment
Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
Signal System
PAL/NTSC
Slow Shutter
Max. 16 times
Light Alarm
Solid Light Alarm (White Light)
Lens
Lens Type
2.8 mm, 3.6 mm, 6 mm fixed focal lens
Focal Length & FOV
2.8 mm, horizontal FOV: 106°, vertical FOV: 56°, diagonal FOV: 129° 3.6 mm, horizontal FOV: 83°, vertical FOV: 44°, diagonal FOV: 100° 6 mm, horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 64°
Lens Mount
M12
Illuminator
Supplement Light Type
White Light
Supplement Light Range
Up to 40 m
Smart Supplement Light
Yes
Image Parameters Switch
STD/HIGH-SAT/HIGHLIGHT
Image Settings
Brightness, Contrast, Mirror, Sharpness, Anti-Banding, AGC
Frame Rate
TVI: 1080p @ 25 fps/30 fps CVI: 1080p @ 25 fps/30 fps AHD: 1080p @ 25 fps/30 fps CVBS: PAL/NTSC
Day/Night Mode
Color
Wide Dynamic Range (WDR)
≥130 dB
Image Enhancement
BLC, HLC, Global, HLS
Privacy Mask
4 programmable privacy masks
Noise Reduction
3D DNR/2D DNR
White Balance
Auto
Interface
Video Output
Switchable TVI/AHD/CVI/CVBS
Audio
Line-in
Built-in Microphone
Yes
Event
Motion Detection
4 programmable motion areas
General
Power
12 VDC ± 25%, max. 6.3 W *You are recommended to use one power adapter to supply the power for one camera.
Material
Metal
Dimension
194.2 mm × 78 mm × 74.5 mm (7.65" × 3.07" × 2.93")
Weight
Approx. 527 g (1.16 lb.)
Operating Condition
-40°C to 50°C (-40°F to 122°F), Humidity: 90% or less (non-condensing)
Communication
HIKVISION-C
Language
English
Approval
Protection
IP67
For better user experience, we highly recommend you to update your device to the latest firmware asap.
Specification
Camera
  • Image Sensor2 MP CMOS
  • Max. Resolution1920 (H) × 1080 (V)
  • Min. Illumination0.0003 Lux @ (F1.0, AGC ON), 0 Lux with white light
  • Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
  • Day & Night24/7 Color Imaging
  • Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
  • Signal SystemPAL/NTSC
  • Slow ShutterMax. 16 times
  • Light AlarmSolid Light Alarm (White Light)
Lens
  • Lens Type2.8 mm, 3.6 mm, 6 mm fixed focal lens
  • Focal Length & FOV2.8 mm, horizontal FOV: 106°, vertical FOV: 56°, diagonal FOV: 129° 3.6 mm, horizontal FOV: 83°, vertical FOV: 44°, diagonal FOV: 100° 6 mm, horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 64°
  • Lens MountM12
Illuminator
  • Supplement Light TypeWhite Light
  • Supplement Light RangeUp to 40 m
  • Smart Supplement LightYes
  • Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
  • Image SettingsBrightness, Contrast, Mirror, Sharpness, Anti-Banding, AGC
  • Frame RateTVI: 1080p @ 25 fps/30 fps CVI: 1080p @ 25 fps/30 fps AHD: 1080p @ 25 fps/30 fps CVBS: PAL/NTSC
  • Day/Night ModeColor
  • Wide Dynamic Range (WDR)≥130 dB
  • Image EnhancementBLC, HLC, Global, HLS
  • Privacy Mask4 programmable privacy masks
  • Noise Reduction3D DNR/2D DNR
  • White BalanceAuto
Interface
  • Video OutputSwitchable TVI/AHD/CVI/CVBS
  • AudioLine-in
  • Built-in MicrophoneYes
Event
  • Motion Detection4 programmable motion areas
General
  • Power12 VDC ± 25%, max. 6.3 W *You are recommended to use one power adapter to supply the power for one camera.
  • MaterialMetal
  • Dimension194.2 mm × 78 mm × 74.5 mm (7.65" × 3.07" × 2.93")
  • WeightApprox. 527 g (1.16 lb.)
  • Operating Condition-40°C to 50°C (-40°F to 122°F), Humidity: 90% or less (non-condensing)
  • CommunicationHIKVISION-C
  • LanguageEnglish
Approval
  • ProtectionIP67
