2 MP Web Camera

  • High quality imaging with 1920 × 1080 resolution
  • Low distortion lens for reducing image distortion
  • Built-in dual-microphone with clear sound
  • USB Type-C interface, supporting USB 2.0 protocols
  • Plug-and-play, no need to install driver software
  • Support auto focus
View Less
View more

Available models:

DS-UC2

Specification

  • Camera
  • Image Sensor2 MP CMOS
  • Signal SystemPAL/NTSC
  • Max. Resolution1920 (H) × 1080 (V)
  • Min. Illumination0.1 Lux @ (F1.2, AGC ON)
  • Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
  • Day & Night24/7 Color Imaging
  • Angle Adjustmentpan: 0° to 360°; tilt: 0° to 90°; rotation: 0°
  • Digital Zoom1.5 ×
  • Lens
  • Lens Type3.6 mm fixed focal lens
  • Focal Length & FOVhorizontal FOV: 87°, vertical FOV: 55°, diagonal FOV: 95°
  • Lens MountM8
  • Object Distance Range5 cm to ∞
  • Image
  • Frame RateMJPG: 1920 × 1080 @ 30 fps/25 fps 1280 × 960 @ 30 fps/25 fps 1280 × 720 @ 30 fps/25 fps 640 × 480 @ 30 fps/25 fps 640 × 360 @ 30 fps/25 fps YUV2: 1920 × 1080 @ 5 fps 1280 × 960 @ 5 fps 1280 × 720 @ 10 fps 640 × 480 @ 30 fps 640 × 360 @ 30 fps
  • Wide Dynamic Range (WDR)Digital WDR
  • White BalanceAuto
  • Audio
  • Audio Sampling Rate16 kHz
  • Interface
  • Video OutputUSB 2.0
  • IndicatorWhite: Normally Working
  • Built-in Microphone2 built-in microphones, picking up sounds in the radius up to 3 meters
  • General
  • Operating Condition-10°C to 40°C (-40°F to 104°F), Humidity: 90% or less (non-condensing)
  • MaterialMetal
  • Dimension120 mm × 27.9 mm × 25.6 mm (4.72" × 1.10" × 1.01")
  • WeightApprox. 147 g (0.32 lb.)
  • Packing ListCamera × 1 USB Cable × 1 Quick Start Guide × 1
  • PowerDC 5V ± 5% (USB), Max. 2.5 W
  • Cable Length2 m
  • System RequirementRecommended systems Windows 7/8/10/11 Android 8.1 and above version Linux 4.14 and above version macOS 10.12 and above version Chrome OS

Specification

Specification
Camera
  • Image Sensor2 MP CMOS
  • Signal SystemPAL/NTSC
  • Max. Resolution1920 (H) × 1080 (V)
  • Min. Illumination0.1 Lux @ (F1.2, AGC ON)
  • Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
  • Day & Night24/7 Color Imaging
  • Angle Adjustmentpan: 0° to 360°; tilt: 0° to 90°; rotation: 0°
  • Digital Zoom1.5 ×
Lens
  • Lens Type3.6 mm fixed focal lens
  • Focal Length & FOVhorizontal FOV: 87°, vertical FOV: 55°, diagonal FOV: 95°
  • Lens MountM8
  • Object Distance Range5 cm to ∞
  • Frame RateMJPG: 1920 × 1080 @ 30 fps/25 fps 1280 × 960 @ 30 fps/25 fps 1280 × 720 @ 30 fps/25 fps 640 × 480 @ 30 fps/25 fps 640 × 360 @ 30 fps/25 fps YUV2: 1920 × 1080 @ 5 fps 1280 × 960 @ 5 fps 1280 × 720 @ 10 fps 640 × 480 @ 30 fps 640 × 360 @ 30 fps
  • Wide Dynamic Range (WDR)Digital WDR
  • White BalanceAuto
Audio
  • Audio Sampling Rate16 kHz
Interface
  • Video OutputUSB 2.0
  • IndicatorWhite: Normally Working
  • Built-in Microphone2 built-in microphones, picking up sounds in the radius up to 3 meters
General
  • Operating Condition-10°C to 40°C (-40°F to 104°F), Humidity: 90% or less (non-condensing)
  • MaterialMetal
  • Dimension120 mm × 27.9 mm × 25.6 mm (4.72" × 1.10" × 1.01")
  • WeightApprox. 147 g (0.32 lb.)
  • Packing ListCamera × 1 USB Cable × 1 Quick Start Guide × 1
  • PowerDC 5V ± 5% (USB), Max. 2.5 W
  • Cable Length2 m
  • System RequirementRecommended systems Windows 7/8/10/11 Android 8.1 and above version Linux 4.14 and above version macOS 10.12 and above version Chrome OS
