1.3MP Mobile Bullet Camera

High quality imaging with 1.3 MP resolution
Clear imaging against strong back light due to 120 dB true WDR technology
Efficient H.265+ compression technology
Water and dust resistant (IP68) and vandal proof (IK10)
Advanced streaming technology that enables smooth live view and data self-correcting in poor network
3D DNR technology delivers clean and sharp images

View Less

Data Sheet

Available models:

DS-2XM6512G0-I/ND(2.8mm)(C)

DS-2XM6512G0-IM/ND(6mm)(C)

DS-2XM6512G0-IM/ND(4mm)(C)

DS-2XM6512G0-IM/ND(2.8mm)(C)

DS-2XM6512G0-IDM(6mm)(C)

DS-2XM6512G0-IDM(4mm)(C)

DS-2XM6512G0-IDM(2.8mm)(C)

DS-2XM6512G0-ID(6mm)(C)

DS-2XM6512G0-ID(4mm)(C)

DS-2XM6512G0-ID(2.8mm)(C)

DS-2XM6512G0-I/ND(6mm)(C)

DS-2XM6512G0-I/ND(4mm)(C)

DS-2XM6512G0-I(D)(M)(/ND)(C)

Specification
Resources
Accessories

Data Sheet

Camera
Image Sensor1/2.8″ Progressive Scan CMOS
Min. Illumination0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Speed 1 s to 1/100,000 s
Slow ShutterYes
Wide Dynamic Range120 dB
Day & NightIR Cut Filter
Angle Adjustment2.8 mm: pan: -15° to 15°, tilt: 15° to 30°, rotate: -90° to 90° 4 mm/6 mm: pan: -15° to 15°, tilt: 0° to 30°, rotate: -90° to 90°

Lens
Focal Length & FOV2.8 mm: horizontal FOV 104°, vertical FOV 56°, diagonal FOV 121° 4 mm: horizontal FOV 77°, vertical FOV 42°, diagonal FOV 91° 6 mm: horizontal FOV 50°, vertical FOV 27°, diagonal FOV 59°
Lens MountM12
Aperture2.8 mm/4 mm: F2.0; 6 mm: F1.6

Video
Max. Resolution1536 × 864
Main Stream50Hz: 50 fps (1536 × 864, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 60 fps (1536 × 864, 1280 × 720, 704 × 480, 640 × 480)
Sub-Stream50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240) 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240, 320 × 240)
Third Stream50Hz: 25fps (1536 × 864, 1280 ×720, 704 × 576, 640 × 480, 352 × 288, 320 × 240) 60Hz: 30fps (1536 × 864, 1280 ×720, 704 × 480, 640 × 480, 352 × 240, 320 × 240)
Video Compression Main Stream: H.265 /H.264 Sub-Stream: H.265 /H.264 / MJPEG Third Stream: H.265 /H.264
Video Bit Rate32 Kbps to 16 Mbps
H.264 TypeBaseLine Profile/Main Profile/High Profile
H.265 TypeMain Profile
Scalable Video Coding (SVC)H.264 and H.265 encoding

Audio
Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/MP3
Audio Bit Rate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/8Kbps-320Kbps(MP3)
Audio Sampling Rate8kHz/16kHz/32kHz/44.1kHz/48kHz
Environment Noise FilteringYes

Network
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Simultaneous Live View Up to 20 channels
APIONVIF (PROFILE S, PROFILE G), ISAPI
User/HostUp to 32 users 3 levels: Administrator, Operator and User
Network StorageMicroSD/SDHC/SDXC card (up to 128 GB), local storage and NAS (NFS,SMB/CIFS), ANR Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
ClientiVMS-4200, Hik-Connect, Hik-Central
Web BrowserPlug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11; Local service: Chrome 41.0+, Firefox 30.0-51

Image SettingsRotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night SwitchDay/Night/Auto/Schedule
Image EnhancementBLC, HLC, 3D DNR, Defog, EIS
DNR 3D DNR

Interface
Ethernet InterfaceWithout -M: 1 RJ45 10M/100M self-adaptive Ethernet port -M: 1 four-core M12 aviation plug
On-Board StorageNo
AudioNo
Alarm No
Reset KeyYes

Event
Basic Event Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart EventLine crossing detection, up to 4 lines configurable Intrusion detection, up to 4 regions configurable Region entrance detection, up to 4 regions configurable Region exiting detection, up to 4 regions configurable Unattended baggage detection, up to 4 regions configurable Object removal detection, up to 4 regions configurable Object detection: detects objects and upload images Scene change detection, defocus detection
LinkageUpload to FTP/NAS/memory card, notify monitoring center, send email, trigger recording, trigger capture

General
Camera DimensionCamera: 163.7 × 122.6 × 65.1 mm (6.4" × 4.8" × 2.6") With package: 252 × 190 × 108 mm(9.9" × 7.5" × 4.3")
Camera WeightCamera: Approx. 850 g (1.9 lb.) With package: 1200 g (2.6 lb.)
Startup and Operating Conditions -40 °C to 70 °C (-40 °F to 158 °F).Humidity 95% or less (non-condensing)
General Function Anti-flicker, 3 streams, heartbeat, mirror, privacy mask
Power Consumption and Current-ID, -IDM: 24 VDC, 0.36 A, max. 8.6 W -I/ND, -IM/ND: PoE: (802.3af, 36 V to 57 V), 0.25 A to 0.15 A, max. 8.8 W
Power Supply -ID, -IDM: 24 VDC ± 25%, two-core terminal block, reverse polarity protection; -I/ND, -IM/ND: PoE: 802.3af, Type 1 Class 0

Camera

Image Sensor

1/2.8″ Progressive Scan CMOS

Min. Illumination

0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR

Shutter Speed

1 s to 1/100,000 s

Slow Shutter

Yes

Wide Dynamic Range

120 dB

Day & Night

IR Cut Filter

Angle Adjustment

2.8 mm: pan: -15° to 15°, tilt: 15° to 30°, rotate: -90° to 90° 4 mm/6 mm: pan: -15° to 15°, tilt: 0° to 30°, rotate: -90° to 90°

Lens

Focal Length & FOV

2.8 mm: horizontal FOV 104°, vertical FOV 56°, diagonal FOV 121° 4 mm: horizontal FOV 77°, vertical FOV 42°, diagonal FOV 91° 6 mm: horizontal FOV 50°, vertical FOV 27°, diagonal FOV 59°

Lens Mount

M12

Aperture

2.8 mm/4 mm: F2.0; 6 mm: F1.6

Video

Max. Resolution

1536 × 864

Main Stream

50Hz: 50 fps (1536 × 864, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 60 fps (1536 × 864, 1280 × 720, 704 × 480, 640 × 480)

Sub-Stream

50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240) 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240, 320 × 240)

Third Stream

50Hz: 25fps (1536 × 864, 1280 ×720, 704 × 576, 640 × 480, 352 × 288, 320 × 240) 60Hz: 30fps (1536 × 864, 1280 ×720, 704 × 480, 640 × 480, 352 × 240, 320 × 240)

Video Compression

Main Stream: H.265 /H.264 Sub-Stream: H.265 /H.264 / MJPEG Third Stream: H.265 /H.264

Video Bit Rate

32 Kbps to 16 Mbps

H.264 Type

BaseLine Profile/Main Profile/High Profile

H.265 Type

Main Profile

Scalable Video Coding (SVC)

H.264 and H.265 encoding

Audio

Audio Compression

G.711/G.722.1/G.726/MP2L2/PCM/MP3

Audio Bit Rate

64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/8Kbps-320Kbps(MP3)

Audio Sampling Rate

8kHz/16kHz/32kHz/44.1kHz/48kHz

Environment Noise Filtering

Yes

Network

Protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour

Simultaneous Live View

Up to 20 channels

API

ONVIF (PROFILE S, PROFILE G), ISAPI

User/Host

Up to 32 users 3 levels: Administrator, Operator and User

Network Storage

MicroSD/SDHC/SDXC card (up to 128 GB), local storage and NAS (NFS,SMB/CIFS), ANR Together with high-end Hikvision memory card, memory card encryption and health detection are supported.

Client

iVMS-4200, Hik-Connect, Hik-Central

Web Browser

Plug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11; Local service: Chrome 41.0+, Firefox 30.0-51


Image Settings

Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser

Day/Night Switch

Day/Night/Auto/Schedule

Image Enhancement

BLC, HLC, 3D DNR, Defog, EIS

DNR

3D DNR

Interface

Ethernet Interface

Without -M: 1 RJ45 10M/100M self-adaptive Ethernet port -M: 1 four-core M12 aviation plug

On-Board Storage

Audio

Alarm

Reset Key

Yes

Event

Basic Event

Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)

Smart Event

Line crossing detection, up to 4 lines configurable Intrusion detection, up to 4 regions configurable Region entrance detection, up to 4 regions configurable Region exiting detection, up to 4 regions configurable Unattended baggage detection, up to 4 regions configurable Object removal detection, up to 4 regions configurable Object detection: detects objects and upload images Scene change detection, defocus detection

Linkage

Upload to FTP/NAS/memory card, notify monitoring center, send email, trigger recording, trigger capture

General

Camera Dimension

Camera: 163.7 × 122.6 × 65.1 mm (6.4" × 4.8" × 2.6") With package: 252 × 190 × 108 mm(9.9" × 7.5" × 4.3")

Camera Weight

Camera: Approx. 850 g (1.9 lb.) With package: 1200 g (2.6 lb.)

Startup and Operating Conditions

-40 °C to 70 °C (-40 °F to 158 °F).Humidity 95% or less (non-condensing)

General Function

Anti-flicker, 3 streams, heartbeat, mirror, privacy mask

Power Consumption and Current

-ID, -IDM: 24 VDC, 0.36 A, max. 8.6 W -I/ND, -IM/ND: PoE: (802.3af, 36 V to 57 V), 0.25 A to 0.15 A, max. 8.8 W

Power Supply

-ID, -IDM: 24 VDC ± 25%, two-core terminal block, reverse polarity protection; -I/ND, -IM/ND: PoE: 802.3af, Type 1 Class 0

Camera

Image Sensor1/2.8″ Progressive Scan CMOS
Min. Illumination0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Speed 1 s to 1/100,000 s
Slow ShutterYes
Wide Dynamic Range120 dB
Day & NightIR Cut Filter
Angle Adjustment2.8 mm: pan: -15° to 15°, tilt: 15° to 30°, rotate: -90° to 90° 4 mm/6 mm: pan: -15° to 15°, tilt: 0° to 30°, rotate: -90° to 90°

Lens

Focal Length & FOV2.8 mm: horizontal FOV 104°, vertical FOV 56°, diagonal FOV 121° 4 mm: horizontal FOV 77°, vertical FOV 42°, diagonal FOV 91° 6 mm: horizontal FOV 50°, vertical FOV 27°, diagonal FOV 59°
Lens MountM12
Aperture2.8 mm/4 mm: F2.0; 6 mm: F1.6

Video

Max. Resolution1536 × 864
Main Stream50Hz: 50 fps (1536 × 864, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 60 fps (1536 × 864, 1280 × 720, 704 × 480, 640 × 480)
Sub-Stream50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240) 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240, 320 × 240)
Third Stream50Hz: 25fps (1536 × 864, 1280 ×720, 704 × 576, 640 × 480, 352 × 288, 320 × 240) 60Hz: 30fps (1536 × 864, 1280 ×720, 704 × 480, 640 × 480, 352 × 240, 320 × 240)
Video Compression Main Stream: H.265 /H.264 Sub-Stream: H.265 /H.264 / MJPEG Third Stream: H.265 /H.264
Video Bit Rate32 Kbps to 16 Mbps
H.264 TypeBaseLine Profile/Main Profile/High Profile
H.265 TypeMain Profile
Scalable Video Coding (SVC)H.264 and H.265 encoding

Audio

Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/MP3
Audio Bit Rate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/8Kbps-320Kbps(MP3)
Audio Sampling Rate8kHz/16kHz/32kHz/44.1kHz/48kHz
Environment Noise FilteringYes

Network

ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Simultaneous Live View Up to 20 channels
APIONVIF (PROFILE S, PROFILE G), ISAPI
User/HostUp to 32 users 3 levels: Administrator, Operator and User
Network StorageMicroSD/SDHC/SDXC card (up to 128 GB), local storage and NAS (NFS,SMB/CIFS), ANR Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
ClientiVMS-4200, Hik-Connect, Hik-Central
Web BrowserPlug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11; Local service: Chrome 41.0+, Firefox 30.0-51


Image SettingsRotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night SwitchDay/Night/Auto/Schedule
Image EnhancementBLC, HLC, 3D DNR, Defog, EIS
DNR 3D DNR

Interface

Ethernet InterfaceWithout -M: 1 RJ45 10M/100M self-adaptive Ethernet port -M: 1 four-core M12 aviation plug
On-Board StorageNo
AudioNo
Alarm No
Reset KeyYes

Event

Basic Event Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart EventLine crossing detection, up to 4 lines configurable Intrusion detection, up to 4 regions configurable Region entrance detection, up to 4 regions configurable Region exiting detection, up to 4 regions configurable Unattended baggage detection, up to 4 regions configurable Object removal detection, up to 4 regions configurable Object detection: detects objects and upload images Scene change detection, defocus detection
LinkageUpload to FTP/NAS/memory card, notify monitoring center, send email, trigger recording, trigger capture

General

Camera DimensionCamera: 163.7 × 122.6 × 65.1 mm (6.4" × 4.8" × 2.6") With package: 252 × 190 × 108 mm(9.9" × 7.5" × 4.3")
Camera WeightCamera: Approx. 850 g (1.9 lb.) With package: 1200 g (2.6 lb.)
Startup and Operating Conditions -40 °C to 70 °C (-40 °F to 158 °F).Humidity 95% or less (non-condensing)
General Function Anti-flicker, 3 streams, heartbeat, mirror, privacy mask
Power Consumption and Current-ID, -IDM: 24 VDC, 0.36 A, max. 8.6 W -I/ND, -IM/ND: PoE: (802.3af, 36 V to 57 V), 0.25 A to 0.15 A, max. 8.8 W
Power Supply -ID, -IDM: 24 VDC ± 25%, two-core terminal block, reverse polarity protection; -I/ND, -IM/ND: PoE: 802.3af, Type 1 Class 0
