Display
7 inch Capacitive touch screen , resolution 1024（RGB）x 600
Network port
10/100M auto adapt,RJ45
WIFI
Built in WIFI，speeds150M，display wireless camera image
IP camera type
ONVIF，ACTi、Dahua IPC-HFW2100P、Hikvision,DS-2CD864-E13、Samsung SNZ-5200、Tiandy TD-NC9200S2、Kodak IPC120L、Honeywell HICC-2300T、Aipu-waton IP5000-BC-13MP/IRS06-13MP、fine-Tida IPC、FSJ BY-1080Q、WEISKY IPC camera etc. Customized welcome
Video input/output
1 channel BNC input & 1 channel BNC looped output, NTSC/PAL (Auto adapt)
Video Level Test
Video signals measured in IRE or mV
Video level meter
PEAK video signal level, SYNC signal level, Color bar chroma level measurement
Zoom Image
Support Analog camera and IP camera image zoom /move
Snapshot,Video record and playback
Image Screen snapshot, record ,save ,view and record and play back
HDMI output
1 channel HDMI output，support 1920*1080P
12V/2Apower output
Output DC12V/2A power for camera
5V power output
5V 2A power output，as a Power bank
PoE power output
48V PoE power output，Max power 24W
Audio test
1 channel audio signal input, test whether sound normal, 1 channel audio signal, to connect headphone
PTZ control
Support RS232/RS485 control, Baud 600-115200bps, Compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc
color bar generator
Output one channel PAL/NTSC color bar video signal for testing monitor or video cable.(red, green ,blue, white and black color )
UTP Cable tester
Test UTP cable connection status and display on the screen. Read the number on the screen
Data monitor
Captures and analyzes the command data from controlling device，also can send hexadecimal
Network test
IP address scan, link test, Ping test, Quickly search the connection IP camera and other device’s IP address
Cable scan
Search the cable by the audio signal
Operation setting
Capacitive touch screen, OSD menu，Chinese/English
