Communication Interface
TCP/IP, RS-485 (For Secure Door Control Unit), Wiegand Output (W26/W34) and Input (Wiegand 26/34)
Working Temperature
-10 ° C to 55 ° C (14 ° F to 131 ° F)
Power Supply
12 VDC/2 A
Audio
1 Buzzer and 1 Loudspeaker
LED Indicator
Power/Status (Red/Green)
LCD Screen
2.4-inch (320 × 240 LCD-TFT Display Screen)
Fingerprint Capacity
Up to 3000 Fingerprints; Up to 10 Fingerprints for Each Person
Storage
Up to 3000 Valid Cards;Up to 100,000 Event Records; Up to 150,000 Attendance Records
Input Interface
Exit Button × 1, Door Sensor × 1 and Alarm Input × 1
Output Interface
Relay (Lock Output) × 1, and Alarm Output × 1
Operating System
Linux
Fingerprint Comparing Mode
1:1 and 1:N, N=3000
Card Reading Response Duration
< 1 s
Fingerprint Authentication Duration
< 1 s
FAR(False Accept Rate)
≤ 0.001 %
FRR (False Rejection Rate)
≤ 0.01 %
Fingerprint Recognizer
Optical Fingerprint Recognizer Module
External Card Reader
Standard Wiegand26/34
Card Reading Distance
0 to 5 cm
Keyboard
Keyboard (Back Light)
Reset Key
× 1
Wi-Fi
Support
Wiegand Interface
Output: Wiegand 26/34;Input: Wiegand 26/34
Transmission Rate
TCP/IP: 10/100Mbps, Self-adaptive;RS485: 19200 bps-N-8-1
USB
USB 2.0; Type A
