DS-U04

    4MP Web Camera

    • 4 MP CMOS
    • High quality imaging with 2560 × 1440 resolution
    • Min. illumination: 0.1 Lux @ (F1.2, AGC ON)
    • AGC for self-adaptive brightness
    • Built-in microphone with clear sound
    • Type A interface, supporting USB 2.0 protocol. Plug-and-play, no need to install driver software

    View Less
    View more

    Available models:

    DS-U04

    Specification

    • Camera
    • Image Sensor4 MP CMOS
    • Signal SystemPAL/NTSC
    • Resolution2560 (H) × 1440 (V)
    • Frame RateMJPG: 2560 × 1440 @ 25 fps 2048 × 1536 @ 30/25 fps 1920 × 1080 @ 30/25 fps 1280 × 960 @ 30/25 fps 1280 × 720 @ 30/25 fps 640 × 480 @ 30/25 fps 640 × 360 @ 30/25 fps YUV: 640 × 480 @ 25 fps 640 × 360 @ 25 fps
    • Min. Illumination0.1 Lux @ (F1.2, AGC ON)
    • Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
    • Lens3.6 mm fixed focal lens
    • Field of Viewhorizontal FOV: 80°, vertical FOV: 50°, diagonal FOV: 88°
    • Lens MountM8
    • Day & Night24/7 Color Imaging
    • Angle Adjustmentpan: 360°; tilt: -15° to 15°; ratation: 0°
    • Cable Length1.5 m
    • Depth of Field0.5 m to ∞
    • Audio
    • Audio Sampling Rate16 kHz
    • Interface
    • Video OutputUSB 2.0
    • Audio InBuilt-in mic
    • Operating SystemRecommended systems Windows 7/8/10/11 (resolution higher than 1080P is only available in Windows 8.1 and above version) Android 8.1 and above version Linux 4.14 and above version macOS 10.12 and above version Chrome OS
    • General
    • Operating Conditions-10 °C to 45 °C, Humidity: 90% or less (non-condensing)
    • Power SupplyDC5 V ± 5% (USB)
    • ConsumptionMax. 1.2 W
    • Dimension80.16 mm × 48.6 mm × 42.18 mm (3.16" × 1.91" × 1.66")
    • WeightApprox. 89 g (0.2 lb.)
    • Accessory
    • Packing ListCamera × 1 Quick Start Guide × 1
    *Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

    Specification

    Camera
    Image Sensor
    4 MP CMOS
    Signal System
    PAL/NTSC
    Resolution
    2560 (H) × 1440 (V)
    Frame Rate
    MJPG: 2560 × 1440 @ 25 fps 2048 × 1536 @ 30/25 fps 1920 × 1080 @ 30/25 fps 1280 × 960 @ 30/25 fps 1280 × 720 @ 30/25 fps 640 × 480 @ 30/25 fps 640 × 360 @ 30/25 fps YUV: 640 × 480 @ 25 fps 640 × 360 @ 25 fps
    Min. Illumination
    0.1 Lux @ (F1.2, AGC ON)
    Shutter Time
    PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
    Lens
    3.6 mm fixed focal lens
    Field of View
    horizontal FOV: 80°, vertical FOV: 50°, diagonal FOV: 88°
    Lens Mount
    M8
    Day & Night
    24/7 Color Imaging
    Angle Adjustment
    pan: 360°; tilt: -15° to 15°; ratation: 0°
    Cable Length
    1.5 m
    Depth of Field
    0.5 m to ∞
    Audio
    Audio Sampling Rate
    16 kHz
    Interface
    Video Output
    USB 2.0
    Audio In
    Built-in mic
    Operating System
    Recommended systems Windows 7/8/10/11 (resolution higher than 1080P is only available in Windows 8.1 and above version) Android 8.1 and above version Linux 4.14 and above version macOS 10.12 and above version Chrome OS
    General
    Operating Conditions
    -10 °C to 45 °C, Humidity: 90% or less (non-condensing)
    Power Supply
    DC5 V ± 5% (USB)
    Consumption
    Max. 1.2 W
    Dimension
    80.16 mm × 48.6 mm × 42.18 mm (3.16" × 1.91" × 1.66")
    Weight
    Approx. 89 g (0.2 lb.)
    Accessory
    Packing List
    Camera × 1 Quick Start Guide × 1
    For better user experience, we highly recommend you to update your device to the latest firmware asap.
    Specification
    Camera
    • Image Sensor4 MP CMOS
    • Signal SystemPAL/NTSC
    • Resolution2560 (H) × 1440 (V)
    • Frame RateMJPG: 2560 × 1440 @ 25 fps 2048 × 1536 @ 30/25 fps 1920 × 1080 @ 30/25 fps 1280 × 960 @ 30/25 fps 1280 × 720 @ 30/25 fps 640 × 480 @ 30/25 fps 640 × 360 @ 30/25 fps YUV: 640 × 480 @ 25 fps 640 × 360 @ 25 fps
    • Min. Illumination0.1 Lux @ (F1.2, AGC ON)
    • Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
    • Lens3.6 mm fixed focal lens
    • Field of Viewhorizontal FOV: 80°, vertical FOV: 50°, diagonal FOV: 88°
    • Lens MountM8
    • Day & Night24/7 Color Imaging
    • Angle Adjustmentpan: 360°; tilt: -15° to 15°; ratation: 0°
    • Cable Length1.5 m
    • Depth of Field0.5 m to ∞
    Audio
    • Audio Sampling Rate16 kHz
    Interface
    • Video OutputUSB 2.0
    • Audio InBuilt-in mic
    • Operating SystemRecommended systems Windows 7/8/10/11 (resolution higher than 1080P is only available in Windows 8.1 and above version) Android 8.1 and above version Linux 4.14 and above version macOS 10.12 and above version Chrome OS
    General
    • Operating Conditions-10 °C to 45 °C, Humidity: 90% or less (non-condensing)
    • Power SupplyDC5 V ± 5% (USB)
    • ConsumptionMax. 1.2 W
    • Dimension80.16 mm × 48.6 mm × 42.18 mm (3.16" × 1.91" × 1.66")
    • WeightApprox. 89 g (0.2 lb.)
    Accessory
    • Packing ListCamera × 1 Quick Start Guide × 1
    *Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.
    Firmware
    Firmware_V3.00.00_220608
    Applied to:
    DS-U04
    For better user experience, we highly recommend you to update your device to the latest firmware asap.
