8-ch 1U 8 PoE 4K NVR

  • Up to 8-ch IP camera inputs
  • H.265+/H.265/H.264+/H.264 video formats
  • Up to 1-ch @ 8MP or 5-ch @ 1080P decoding capacity
  • Up to 80 Mbps incoming bandwidth

View Less
View more
Data Sheet
Sales Inquiry

Available models:

HWN-4108MH-8P(C)
HWN-4108MH-8P(D)
HWN-4108MH-8P
Data Sheet

Specification

  • Video and Audio
  • IP Video Input8-ch
  • HDMI OutputHDMI：1-ch, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,VGA：1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
  • VGA Output1920*1080/60Hz，1280*1024/60Hz，1280*720/60Hz
  • Incoming Bandwidth80 Mbps
  • Outgoing Bandwidth80 Mbps
  • Audio Output1-ch, RCA (Linear, 1 KΩ)
  • Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 k Ω)
  • Decoding
  • Decoding FormatH.265+,H.265,H.264+,H.264
  • Decoding Capability4-ch@1080p
  • Synchronous playback8-ch
  • Recording Resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
  • Network
  • Network ProtocolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
  • Network Interface1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
  • PoE
  • Interface8, RJ-45 10/100 Mbps self-adaptive Ethernet interface
  • Power≤ 75W
  • StandardIEEE 802.3 af/at
  • RAID
  • RAID TypeNo
  • Auxiliary Interface
  • SATA1 SATA interface
  • CapacityUp to 8TB capacity for each disk
  • USB Interface2 × USB 2.0
  • General
  • Power Supply48 VDC, 1.8 A
  • Consumption≤ 10 W
  • Working Temperature-10 to +55º C (+14 to +131º F)
  • Working Humidity10 to 90 %
  • Chassis1U
  • Dimension (W × D × H)265 × 225 × 48 mm (10.2" × 8.9" × 1.9")
  • Weight≤ 1 kg (2.2 lb)
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specification

Video and Audio
IP Video Input
8-ch
HDMI Output
HDMI：1-ch, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,VGA：1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output
1920*1080/60Hz，1280*1024/60Hz，1280*720/60Hz
Incoming Bandwidth
80 Mbps
Outgoing Bandwidth
80 Mbps
Audio Output
1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio
1-ch, RCA (2.0 Vp-p, 1 k Ω)
Decoding
Decoding Format
H.265+,H.265,H.264+,H.264
Decoding Capability
4-ch@1080p
Synchronous playback
8-ch
Recording Resolution
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
Network
Network Protocol
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Network Interface
1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
PoE
Interface
8, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power
≤ 75W
Standard
IEEE 802.3 af/at
RAID
RAID Type
No
Auxiliary Interface
SATA
1 SATA interface
Capacity
Up to 8TB capacity for each disk
USB Interface
2 × USB 2.0
General
Power Supply
48 VDC, 1.8 A
Consumption
≤ 10 W
Working Temperature
-10 to +55º C (+14 to +131º F)
Working Humidity
10 to 90 %
Chassis
1U
Dimension (W × D × H)
265 × 225 × 48 mm (10.2" × 8.9" × 1.9")
Weight
≤ 1 kg (2.2 lb)
For better user experience, we highly recommend you to update your device to the latest firmware asap.
Specification
Video and Audio
  • IP Video Input8-ch
  • HDMI OutputHDMI：1-ch, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,VGA：1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
  • VGA Output1920*1080/60Hz，1280*1024/60Hz，1280*720/60Hz
  • Incoming Bandwidth80 Mbps
  • Outgoing Bandwidth80 Mbps
  • Audio Output1-ch, RCA (Linear, 1 KΩ)
  • Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 k Ω)
Decoding
  • Decoding FormatH.265+,H.265,H.264+,H.264
  • Decoding Capability4-ch@1080p
  • Synchronous playback8-ch
  • Recording Resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
Network
  • Network ProtocolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
  • Network Interface1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
PoE
  • Interface8, RJ-45 10/100 Mbps self-adaptive Ethernet interface
  • Power≤ 75W
  • StandardIEEE 802.3 af/at
RAID
  • RAID TypeNo
Auxiliary Interface
  • SATA1 SATA interface
  • CapacityUp to 8TB capacity for each disk
  • USB Interface2 × USB 2.0
General
  • Power Supply48 VDC, 1.8 A
  • Consumption≤ 10 W
  • Working Temperature-10 to +55º C (+14 to +131º F)
  • Working Humidity10 to 90 %
  • Chassis1U
  • Dimension (W × D × H)265 × 225 × 48 mm (10.2" × 8.9" × 1.9")
  • Weight≤ 1 kg (2.2 lb)
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Resources

For better user experience, we highly recommend you to update your device to the latest firmware asap.
Firmware_V4.75.207_240604
K9B2_V4.75.207build240604_ReleaseNotes
Applied to:
HWN-4108MH-8P(C)
Firmware_V4.83.006_240910
K21B2_V4.83.006 build240910_ReleaseNotes
Applied to:
HWN-4108MH-8P(D)
