2-inch 2 MP 4X Powered by DarkFighter IR Network Speed Dome

Two-inch 2 MP camera with pan, tilt and zoom (4x) ability
Efficient H.265+ compression technology to save bandwidth and storage
Clear imaging against strong back light due to 120 dB true WDR technology
Great night-time performance with up to 20 m enhanced IR
Water and dust resistant (IP66), and vandal proof (IK10)
Built-in microphone for real-time audio security (optional)

View Less

Data Sheet

Available models:

PTZ-N2204I-DE3(F)

PTZ-N2204I-DE3

Specification
Resources
Accessories

Data Sheet

Lens
FOVHorizontal field of view: 109° to 34° (Wide-Tele),Vertical field of view: 57° to 19° (Wide-Tele),Diagonal field of view: 135° to 39° (Wide-Tele)
Focal Length2.8 mm to 12 mm, 4× optical zoom
Zoom SpeedApprox. 2 s (optical lens, wide-tele)
Working Distance10 mm to 1500 mm (wide-tele)
Aperture RangeF1.6 to F2.7

Smart Features
Basic Event DetectionMotion Detection, Video Tampering Detection, Exception
Smart DetectionFace Detection, Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Object Removal Detection, Unattended Baggage Detection, Audio Exception Detection
Smart RecordANR (Automatic Network Replenishment), Dual-VCA
ROIMain stream, sub-stream, and third stream respectively support two fixed areas.

Network
Security MeasuresUser authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering
Network StorageBuilt-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR
ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
APIOpen-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform, support Hik-Connect
Simultaneous Live ViewUp to 20 channels
User/HostUp to 32 users,3 levels: Administrator, Operator and User
ClientiVMS-4200, HikCentral, HiLookVision
Web BrowserIE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51

Image Enhancement3D DNR, BLC, HLC, EIS, Regional Exposure, Regional Focus
Sub-Stream50Hz: 25fps (704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)
Max. Resolution1920 × 1080
Main Stream50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Third Stream50Hz: 25fps (704 × 576, 640 × 480, 352 × 288), 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)

Interface
Audio Input1-ch audio input (line in)
Audio Output1-ch audio output (line out)
Network Interface1 RJ45 10 M/100 M Ethernet, PoE
Built-in Microphone1 built-in microphone, picking up sounds in the radius up to 5 meters

Camera Module
Image Sensor1/3" progressive scan CMOS
Min. IlluminationColor: 0.005 Lux @(F1.6, AGC ON),B/W: 0.001 Lux @(F1.6, AGC ON),0 Lux with IR
White BalanceAuto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
GainAuto/Manual
Shutter Time50Hz: 1/1 s to 1/30,000 s,60Hz: 1/1 s to 1/30,000 s
Day & NightIR Cut Filter
Digital Zoom16×
Privacy Mask24 programmable privacy masks
Focus ModeAuto/Semi-automatic/Manual
WDR120 dB WDR

General
MaterialAluminum alloy, PC, PC+ABS
DimensionsΦ 130.7 mm × 101.7 mm (Φ 5.15" × 4.00")
WeightApprox. 0.53 kg (1.17 lb)
Protection LevelIP66 Standard, IK 10, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
Power12 VDC, 1.5 A (Max. 9.9 W, including max. 4.2 W for IR) PoE (802.3af), 36 to 57 VDC, 0.35 A (Max. 11.2 W, including max. 4.2 W for IR)
Working Temperature-20°C to 60°C (-4°F to 140°F)
Working Humidity≤ 90%

Supplement Light
IR Distance20 m
Smart IRSupport

PTZ
Movement Range (Pan)0° to 330°
Pan SpeedConfigurable, from 0.1°/s to 100°/s, ,Preset speed: 100°/s
Movement Range (Tilt)From 0° to 90°
Tilt SpeedConfigurable, from 0.1°/s to 100°/s,Preset Speed: 100°/s
Proportional ZoomSupport
Presets300
Power-off MemorySupport

Compression Standard
H.264+Support
H.265+Support
H.264 TypeBaseline Profile/Main Profile/High Profile
Video CompressionMain Stream: H.265+/H.265/H.264+/H.264,Sub-stream: H.265/H.264/MJPEG,Third Stream: H.265/H.264/MJPEG
H.265 TypeMain Profile
Video Bitrate32 Kbps to 16384 Kbps
Audio CompressionG.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
Audio Bitrate64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 160 Kbps(MP2L2)
SVCSupport

Lens

FOV

Horizontal field of view: 109° to 34° (Wide-Tele),Vertical field of view: 57° to 19° (Wide-Tele),Diagonal field of view: 135° to 39° (Wide-Tele)

Focal Length

2.8 mm to 12 mm, 4× optical zoom

Zoom Speed

Approx. 2 s (optical lens, wide-tele)

Working Distance

10 mm to 1500 mm (wide-tele)

Aperture Range

F1.6 to F2.7

Smart Features

Basic Event Detection

Motion Detection, Video Tampering Detection, Exception

Smart Detection

Face Detection, Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Object Removal Detection, Unattended Baggage Detection, Audio Exception Detection

Smart Record

ANR (Automatic Network Replenishment), Dual-VCA

ROI

Main stream, sub-stream, and third stream respectively support two fixed areas.

Network

Security Measures

User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering

Network Storage

Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR

Protocols

IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour

API

Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform, support Hik-Connect

Simultaneous Live View

Up to 20 channels

User/Host

Up to 32 users,3 levels: Administrator, Operator and User

Client

iVMS-4200, HikCentral, HiLookVision

Web Browser

IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51


Image Enhancement

3D DNR, BLC, HLC, EIS, Regional Exposure, Regional Focus

Sub-Stream

50Hz: 25fps (704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)

Max. Resolution

1920 × 1080

Main Stream

50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)

Third Stream

50Hz: 25fps (704 × 576, 640 × 480, 352 × 288), 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)

Interface

Audio Input

1-ch audio input (line in)

Audio Output

1-ch audio output (line out)

Network Interface

1 RJ45 10 M/100 M Ethernet, PoE

Built-in Microphone

1 built-in microphone, picking up sounds in the radius up to 5 meters

Camera Module

Image Sensor

1/3" progressive scan CMOS

Min. Illumination

Color: 0.005 Lux @(F1.6, AGC ON),B/W: 0.001 Lux @(F1.6, AGC ON),0 Lux with IR

White Balance

Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp

Gain

Auto/Manual

Shutter Time

50Hz: 1/1 s to 1/30,000 s,60Hz: 1/1 s to 1/30,000 s

Day & Night

IR Cut Filter

Digital Zoom

16×

Privacy Mask

24 programmable privacy masks

Focus Mode

Auto/Semi-automatic/Manual

WDR

120 dB WDR

General

Material

Aluminum alloy, PC, PC+ABS

Dimensions

Φ 130.7 mm × 101.7 mm (Φ 5.15" × 4.00")

Weight

Approx. 0.53 kg (1.17 lb)

Protection Level

IP66 Standard, IK 10, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection

Power

12 VDC, 1.5 A (Max. 9.9 W, including max. 4.2 W for IR) PoE (802.3af), 36 to 57 VDC, 0.35 A (Max. 11.2 W, including max. 4.2 W for IR)

Working Temperature

-20°C to 60°C (-4°F to 140°F)

Working Humidity

≤ 90%

Supplement Light

IR Distance

20 m

Smart IR

Support

PTZ

Movement Range (Pan)

0° to 330°

Pan Speed

Configurable, from 0.1°/s to 100°/s, ,Preset speed: 100°/s

Movement Range (Tilt)

From 0° to 90°

Tilt Speed

Configurable, from 0.1°/s to 100°/s,Preset Speed: 100°/s

Proportional Zoom

Support

Presets

300

Power-off Memory

Support

Compression Standard

H.264+

Support

H.265+

Support

H.264 Type

Baseline Profile/Main Profile/High Profile

Video Compression

Main Stream: H.265+/H.265/H.264+/H.264,Sub-stream: H.265/H.264/MJPEG,Third Stream: H.265/H.264/MJPEG

H.265 Type

Main Profile

Video Bitrate

32 Kbps to 16384 Kbps

Audio Compression

G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM

Audio Bitrate

64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 160 Kbps(MP2L2)

SVC

Support
