Operating Interface
WEB, HDMI
HDD Storage
1 2.5’’ 1 T HDD
Network Interface
1 optical interface 4 10/100M self-adaptive Ethernet interfaces, 2 100/1000M self-adaptive Ethernet interfaces
Analog Video Input
4-ch HDTVI video inputs
IP Video Input
Up to 12-ch 7 MP IP cameras connection
Audio Input
1-ch
Audio Output
1-ch
Alarm Input
2-ch
Alarm Output
2-ch
USB Interface
2 × USB 2.0
RS-232 Interface
2
RS-485 Interface
2
Indicator
UID indicator, Alarm indicator, Power indicator, Ready indicator
Memory
2 × 2 GB
TX1 Chip
2
Button
Power on/off, Reset
Power Supply
12 VDC/5A
Dimensions (W × D × H)
300 × 227.5 × 74.1 mm (11.8 × 9.0 × 2.9 inch)
Operating Temperature
-20 ºC to +55 ºC (-4 ºF to +131 ºF)
Operating Humidity
10% to 90%
Weight
3.6 kg (7.9 lb)
