DS-2XM6222FWD-I(M)

EOL

Mobile Bullet Network Camera

High quality imaging with 2 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB WDR technology
High quality imaging with 2 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB WDR technology

View Less

Available models:

DS-2XM6222FWD-I(12mm)

DS-2XM6222FWD-I(2.8mm)

DS-2XM6222FWD-I(4mm)

DS-2XM6222FWD-I(6mm)

DS-2XM6222FWD-I(8mm)

DS-2XM6222FWD-IM(2.8mm)

DS-2XM6222FWD-IM(4mm)

DS-2XM6222FWD-IM(6mm)

DS-2XM6222FWD-IM(8mm)

Camera
Image Sensor1/2.7" Progressive Scan CMOS
Min. IlluminationColor: 0.018 lux @(F1.2 AGC ON),B/W: 0.006 lux @(F1.2 AGC ON), 0 lux with IR
Shutter Speed1/3 s to 1/100,000 s
Slow ShutterYes
Day &NightIR Cut Filter
Wide Dynamic Range120dB
Angle AdjustmentPan: -20° to 20°, tilt: -15° to 20°
DNR3D DNR

Lens
Lens2.8 mm, 4 mm, 6 mm, 8 mm, and 12 mm, optional
ApertureF2.0
FOV2.8 mm: horizontal FOV 115°, vertical FOV 62°, diagonal FOV 135°,4 mm: horizontal FOV 87°, vertical FOV 48°, diagonal FOV 102°,6 mm: horizontal FOV 60°, vertical FOV 32.4°, diagonal FOV 70°,8 mm: horizontal FOV 41°, vertical FOV 23.2°, diagonal FOV 47.6°,12 mm: horizontal FOV 26.5°, vertical FOV 15°, diagonal FOV 30.5°
Lens MountM12

Illuminator
IR Range10 to 30 m
Wavelength850nm

Video
Max. Resolution1920 × 1080
Main Stream50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub Stream50Hz: 25fps (704 × 576, 352 × 288, 640 × 480, 320 × 240),60Hz: 30fps (704 × 480, 352 × 240, 640 × 480, 320 × 240)
Third Stream50Hz: 25fps(1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 352 × 288, 640 × 480, 320 × 240),60Hz: 30fps(1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 352 × 240, 640 × 480, 320 × 240)
H.264 TypeBaseline Profile/Main Profile/High Profile
H.265 TypeMain Profile
Video Bit Rate32 Kbps to 16 Mbps
SVCYes

Smart Feature-Set
Behavior AnalysisLine crossing detection, intrusion detection, region entrance detection, region exit detection, unattended baggage detection, object removal detection
Region of InterestSupport 4 fixed regions for each stream, and dynamic face tracking

Image EnhancementBLC, 3D DNR, HLC, defog, EIS
Image SettingRotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Target CroppingYes
Day/Night SwitchAuto/Schedule
Picture OverlayLogo picture cab be overlaid on video with 128 × 128 24bit bmp format, region optional

Network
Network StorageSupport microSD/SDHC/SDXC card (128 GB) local storage and NAS (NFS,SMB/CIFS), ANR
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
APIONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live ViewUp to 6 channels
User/HostUp to 32 users,3 levels: Administrator, Operator and User
ClientiVMS-4200, Hik-Connect, iVMS-5200
Web BrowserIE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Alarm TriggerMotion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error

Interface
Communication InterfaceDS-2XM6222FWD-I: 1 RJ45 10M/100M self-adaptive Ethernet port,DS-2XM6222FWD-IM: 1 M12 aviation plug
On-board StorageBuilt-in micro SD/SDHC/SDXC slot, up to 128 GB

Battery
Operating condition-30 °C to +65 °C (-22 °F to +149 °F), Humidity 95% or less (non-condensing)

Compression Standard
H.264+Yes
H.265+Yes

Smart Feature-set
Face DetectionYes
Exception DetectionScene change detection, defocus detection

General
General FunctionOne-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
ResetYes
Power Supply12 VDC ±20%, PoE (802.3af, class 3),DS-2XM6222FWD-I: Coaxial power plug (Ø 5.5 mm) for DC input,DS-2XM6222FWD-IM: Molex plug for DC input
Power Consumption and Current12 VDC, 0.43 A, max. 4W,PoE (802.3af, 36V to 57V), 0.14 A to 0.09 A, max. 5.2 W
MaterialAluminum alloy
Dimensions78.8 × 81.6 × 64 mm (3.10" × 3.21" × 2.52")
WeightCamera: Approx. 330 g (0.7 lb.),With Package: Approx. 500 g (1.1 lb.)
Interface ProtectionIP67

Specification

Camera

Image Sensor

1/2.7" Progressive Scan CMOS

Min. Illumination

Color: 0.018 lux @(F1.2 AGC ON),B/W: 0.006 lux @(F1.2 AGC ON), 0 lux with IR

Shutter Speed

1/3 s to 1/100,000 s

Slow Shutter

Yes

Day &Night

IR Cut Filter

Wide Dynamic Range

120dB

Angle Adjustment

Pan: -20° to 20°, tilt: -15° to 20°

DNR

3D DNR

Lens

2.8 mm, 4 mm, 6 mm, 8 mm, and 12 mm, optional

Aperture

F2.0

FOV

2.8 mm: horizontal FOV 115°, vertical FOV 62°, diagonal FOV 135°,4 mm: horizontal FOV 87°, vertical FOV 48°, diagonal FOV 102°,6 mm: horizontal FOV 60°, vertical FOV 32.4°, diagonal FOV 70°,8 mm: horizontal FOV 41°, vertical FOV 23.2°, diagonal FOV 47.6°,12 mm: horizontal FOV 26.5°, vertical FOV 15°, diagonal FOV 30.5°

Lens Mount

M12

Illuminator

IR Range

10 to 30 m

Wavelength

850nm

Video

Max. Resolution

1920 × 1080

Main Stream

50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)

Sub Stream

50Hz: 25fps (704 × 576, 352 × 288, 640 × 480, 320 × 240),60Hz: 30fps (704 × 480, 352 × 240, 640 × 480, 320 × 240)

Third Stream

50Hz: 25fps(1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 352 × 288, 640 × 480, 320 × 240),60Hz: 30fps(1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 352 × 240, 640 × 480, 320 × 240)

H.264 Type

Baseline Profile/Main Profile/High Profile

H.265 Type

Main Profile

Video Bit Rate

32 Kbps to 16 Mbps

SVC

Yes

Smart Feature-Set

Behavior Analysis

Line crossing detection, intrusion detection, region entrance detection, region exit detection, unattended baggage detection, object removal detection

Region of Interest

Support 4 fixed regions for each stream, and dynamic face tracking


Image Enhancement

BLC, 3D DNR, HLC, defog, EIS

Image Setting

Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser

Target Cropping

Yes

Day/Night Switch

Auto/Schedule

Picture Overlay

Logo picture cab be overlaid on video with 128 × 128 24bit bmp format, region optional

Network

Network Storage

Support microSD/SDHC/SDXC card (128 GB) local storage and NAS (NFS,SMB/CIFS), ANR

Protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour

API

ONVIF (PROFILE S, PROFILE G), ISAPI

Simultaneous Live View

Up to 6 channels

User/Host

Up to 32 users,3 levels: Administrator, Operator and User

Client

iVMS-4200, Hik-Connect, iVMS-5200

Web Browser

IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+

Alarm Trigger

Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error

Interface

Communication Interface

DS-2XM6222FWD-I: 1 RJ45 10M/100M self-adaptive Ethernet port,DS-2XM6222FWD-IM: 1 M12 aviation plug

On-board Storage

Built-in micro SD/SDHC/SDXC slot, up to 128 GB

Battery

Operating condition

-30 °C to +65 °C (-22 °F to +149 °F), Humidity 95% or less (non-condensing)

Compression Standard

H.264+

Yes

H.265+

Yes

Smart Feature-set

Face Detection

Yes

Exception Detection

Scene change detection, defocus detection

General

General Function

One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter

Reset

Yes

Power Supply

12 VDC ±20%, PoE (802.3af, class 3),DS-2XM6222FWD-I: Coaxial power plug (Ø 5.5 mm) for DC input,DS-2XM6222FWD-IM: Molex plug for DC input

Power Consumption and Current

12 VDC, 0.43 A, max. 4W,PoE (802.3af, 36V to 57V), 0.14 A to 0.09 A, max. 5.2 W

Material

Aluminum alloy

Dimensions

78.8 × 81.6 × 64 mm (3.10" × 3.21" × 2.52")

Weight

Camera: Approx. 330 g (0.7 lb.),With Package: Approx. 500 g (1.1 lb.)

Interface Protection

IP67
