6 Series 4MP 36X DarkFighter Network Speed Dome

1/1.8" Progressive Scan CMOS
High quality imaging with 4 MP resolution
Excellent low-light performance with DarkFighter technology
36× optical zoom and 16× digital zoom provide close up views over expansive areas
Supports rapid focus
Water and dust resistant (IP67) and vandal proof (IK10)
Supports face capture to detect, capture, grade, and select faces in motion
Supports road traffic to detect vehicles

View Less

Data Sheet

Available models:

DS-2DF6A436X-AELY(T5)

Specification
Resources
Accessories

Data Sheet

Camera
Image Sensor 1/1.8＂ progressive scan CMOS
Max. Resolution 2560 × 1440
Min. Illumination color: 0.001 Lux @ (F1.2, AGC ON), B/W: 0.0005 Lux @(F1.2，AGC ON), 0 Lux with IR
Shutter Speed 1/1 s to 1/30,000 s
Day & Night ICR
Zoom 16x digital
Slow Shutter yes
HLC yes
3D DNR yes
Optical Zoom 36x
DORI Detect (25 px/m): 2965.5 m Observe (63 px/m): 1176.8 m Recognize (125 px/m): 604.1 m Identify (250 px/m): 302.1 m

Lens
Focal Length 6.0 mm to 216 mm, 36× Optical
FOV Horizontal field of view: 56.6° to 1.7° (wide-tele), Vertical field of view: 33.7° to 0.9° (wide-tele), Diagonal field of view: 63.4° to 1.9° (wide-tele)
Focus Auto,semi-auto,manual,rapid focus
Aperture F1.2
Zoom Speed approx. 4.5 s

PTZ
Movement Range (Pan) 360°
Movement Range (Tilt) -20° to 90° (auto flip)
Pan Speed pan speed: configurable from 0.1° to 300°/s; preset speed: 540°/s
Tilt Speed tilt speed: configurable from 0.1° to 240°/s, preset speed 400°/s
Proportional Pan yes
Presets 300
Preset Freezing yes
Patrol Scan 8 patrols, up to 32 presets for each patrol
Pattern Scan 4 pattern scans, record time over 10 minutes for each scan
Park Action preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan
3D Positioning yes
PTZ Status Display yes
Scheduled Task preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan||dome reboot||dome adjust||aux output
Power-off Memory yes

Video
Main Stream 50 Hz: 25 fps (2560×1440, 1920×1080, 1280×960, 1280×720) 60 Hz: 30 fps (2560×1440, 1920×1080, 1280×960, 1280×720)
Sub-Stream 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Third Stream 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Video Compression H.265||H.264||MJPEG
Video Bit Rate 32 Kbps to 16384 Kbps
H.264 Type baseline profile||main profile||high profile
H.265 Type main profile
Scalable Video Coding (SVC) yes
Region of Interest (ROI) fixed region

Audio
Audio Compression G.711alaw||G.711ulaw||G.722.1||G.726||MP2L2||PCM
Audio Bit Rate 64 Kbps(G.711)/16 Kbps(G.722.1)/16 Kbps(G.726)/32~192 Kbps(MP2L2)

Network
Protocols IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, UDP, IGMP, ICMP, Bonjour
Simultaneous Live View Up to 20 channels
API Open-ended API|| ISAPI||Hikvision SDK||Third-party management platform||Ehome||ISUP||ONVIF (Profile S, Profile G, Profile T)
Smooth Streaming yes
User/Host Up to 32 users. 3 levels: Administrator, Operator and User
Security User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering
Network Storage NAS (NFS, SMB/ CIFS)||ANR
Client iVMS-4200||Hik-Connect||Hikcentral
Web Browser IE11, Chrome 57.0+, Firefox 52.0+, Safari 11+

Day/Night Switch day, night, auto, scheduled-switch
Wide Dynamic Range (WDR) 140 dB WDR
SNR ≥52dB
Defog yes
Image Stabilization EIS (Built-in gyroscope to improve EIS performance)
Image Enhancement BLC, HLC, 3D DNR
Privacy Mask up to 24 masks||polygon region ||mosaic mask ||mask color configurable
Regional Focus yes
Regional Exposure yes

Interface
Video Output 1.0V[p-p]/75Ω||PAL||NTSC||BNC connector
Ethernet Interface RJ45, self-adaptive 10M/100M Ethernet port
On-board Storage Built-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB; NAS (NFS, SMB/ CIFS), ANR
Audio 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%, 1 output (line out), line level, output impedance: 600 Ω
Alarm 7 alarm inputs, 2 alarm outputs
RS-485 HIKVISION, Pelco-P, Pelco-D, self-adaptive

Event
Basic Event motion detection||video tampering alarm||alarm input and output||exception
Smart Event intrusion detection||line crossing detection||region entrance detection||region exiting detection||parking detection||unattended baggage detection||object removal detection||vandal-proof alarm||audio exception detection
Linkage Alarm actions, such as Preset, Patrol Scan, Pattern Scan, Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc.
Smart Tracking manual tracking||event tracking||auto-tracking

Deep Learning Function
Face Capture Support detecting up to 30 faces at the same time. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face.
Road Traffic Support vehicle detection (license plate number,vehicle model, and vehicle color recognition)

General
Power 24 VAC±25% (Max. 45 W, including max. 6 W for heater), Hi-PoE (Max. 50 W, including max. 6 W for heater)
Dimension ⌀ 231.1 mm × 355.6 mm (⌀ 9.10" × 14")
Weight Approx. 6 kg (13.23 lb.)
Operating Condition Temperature: -40°C to 70°C (-40°F to 158°F)，Humidity: ≤ 95%
General Function mirror, password protection, watermark, IP address filter
Language 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

Approval
EMC FCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2019); KC (KN 32: 2015, KN 35: 2015)
Safety UL (UL 62368-1) CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2017), BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (SANS IEC60950-1)
Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection Lightning Protection, Surge Protection and Voltage Transient Protection,±6kV Line to Gnd, ±3kV Line to Line,IEC61000-4-5||IP67 Standard||IK10
Anti-Corrosion Protection NEMA 4X
