Single Input Transmitter

Small size design, which can be put into wired detector easily
868MHz two-way wireless communication
LED display, show the real status of device
With one tamper input and one PGM, can be used as zone input or alarm outpout
With 3.3V voltage output, can be used to power up external wired detector
Detection of device removal by accelerometer

View Less

Data Sheet

Available models:

DS-PM1-I1-WE

Specification
Resources
Accessories

Data Sheet

Hardware features
Serial port1
Power switch1
Alarm input1 Alarm, 1 Tamper
Alarm output1 PGM, AM/Output
3.3v Output1, up to 10mA

Electrical characteristics
Power supply3 CR123
Operation humidity10% to 90%
Operation temperature–10°C to 55°C
Power consumptionQuiescent current: 40.29 uA Max current: 47.85 mA Voltage: 3 VDC
Battery life spanUp to 5 years (standby time)

Wireless transmission
RF frequency868 MHz
RF methodTwo-way communication
RF modulation2GFSK
RF distance1700 m

Display
Indicator3: Alarm/Tamper(Red), Fault(Amber), Signal Strength(Green/Red)

General
Installation methodPut inside wireless ready detector
Dimension(WxHxD)102 mm × 41 mm × 20 mm
Weight35 g (without battery), 90 g (with battery)

Hardware features

Serial port

Power switch

Alarm input

1 Alarm, 1 Tamper

Alarm output

1 PGM, AM/Output

3.3v Output

1, up to 10mA

Electrical characteristics

Power supply

3 CR123

Operation humidity

10% to 90%

Operation temperature

–10°C to 55°C

Power consumption

Quiescent current: 40.29 uA Max current: 47.85 mA Voltage: 3 VDC

Battery life span

Up to 5 years (standby time)

Wireless transmission

RF frequency

868 MHz

RF method

Two-way communication

RF modulation

2GFSK

RF distance

1700 m

Display

Indicator

3: Alarm/Tamper(Red), Fault(Amber), Signal Strength(Green/Red)

General

Installation method

Put inside wireless ready detector

Dimension(WxHxD)

102 mm × 41 mm × 20 mm

Weight

35 g (without battery), 90 g (with battery)

Hardware features

Serial port1
Power switch1
Alarm input1 Alarm, 1 Tamper
Alarm output1 PGM, AM/Output
3.3v Output1, up to 10mA

Electrical characteristics

Power supply3 CR123
Operation humidity10% to 90%
Operation temperature–10°C to 55°C
Power consumptionQuiescent current: 40.29 uA Max current: 47.85 mA Voltage: 3 VDC
Battery life spanUp to 5 years (standby time)
