10 inch Touch Android IP Main Station

  • 10.1-inch IPS touch screen with resolution: 1280 × 800
  • Up to 128 network cameras can be added to the device
  • Built-in SIP private server, up to 10000 video intercom devices can be added
  • Supports more than 2 speakers and microphones: Connects to external earphone (3.5mm), external goose neck microphone
  • Displays operation pages via HDMI
  • Power supply: standard PoE & 12 VDC
  • Video intercom and access control functions

Available models:

DS-KM9503

Specification

  • System parameters
  • Operating systemAndroid 7.1
  • ROM8 GB
  • RAM2 GB
  • CPUEmbedded processor
  • Display parameters
  • Screen size10.1-inch
  • Operation methodCapacitive touch screen
  • TypeIPS
  • Resolution1280 × 800
  • Video parameters
  • Resolution2 MP
  • FOVHorizontal: 64.1°, Vertical: 48.1°, Diagonal: 80.2°
  • WDR/
  • Supplement light/
  • Video compression standardH.264
  • Audio parameters
  • Audio compression standardG.711U、G.711A
  • Audio inputBuilt-in omnidirectional microphone, external speaker, external goose neck microphone, external earphone (3.5 mm)
  • Audio outputBuilt-in loudspeaker, external speaker, external voice box or earphone (3.5 mm)
  • Audio compression bitrate64 Kbps
  • Audio qualityNoise suppression and echo cancellation
  • Volume adjustmentAdjustable via software
  • Capacity
  • Notice capacity128
  • Linked doorphone capacity10000
  • Network parameters
  • Communication protocolTCP/IP, SIP, RTSP
  • Wired network2 10/100/1000 M self-adaptive Ethernet
  • Wi-Fi standard/
  • 3G/4G standard/
  • Zigbee/
  • Device interfaces
  • Alarm input2
  • Network interface2
  • TAMPER0
  • RS-4851
  • USB3
  • TF cardMax to 128 G
  • Lock control2 Relay output
  • General
  • Button3 touch buttons
  • InstallationTable mounting & wall mounting
  • Indicator3
  • Without package: 1.285 kg With package: 2.305 kg
  • Protective level/
  • Working humidity10% to 90%
  • Dimensions292 mm × 166 mm × 31 mm (11.5" × 6.5" × 1.2")
  • LanguageEnglish, French, Portuguese (Europe), Spanish (Europe), Russian, German, Italian, Polish, Arabic, Turkish, Vietnamese, Hungarian, Dutch, Romanian, Czech, Bulgarian, Ukrainian, Croatian, Serbian, Lithuanian, Estonian, Latvian, Norwegian, Greek, Danish
  • Battery/
  • Power supplyStandard PoE (LAN1) 12 VDC
  • Application environmentIndoor
  • Power consumption≤ 12 W
